Matrix CXV User manual
CXV
2
ENGLISH
SAVE THESE INSTRUCTIONS
When using Matrix Cycles, basic precautions should always be followed, including the
following: Read all instructions before using this equipment. It is the responsibility of the
owner to ensure that all users of this equipment are adequately informed of all warnings and
precautions.
This equipment is for indoor use only. This training equipment is a Class S product designed
for use in a commercial environment such as a fitness facility.
DANGER!
TO REDUCE THE RISK OF ELECTRICAL SHOCK:
Always unplug the equipment from the electrical outlet before cleaning, performing
maintenance and putting on or taking o parts.
WARNING!
TO REDUCE THE RISK OF BURNS, FIRE, ELECTRICAL SHOCK OR
INJURY TO PERSONS:
• Use this indoor cycle for its intended purpose as described in this manual. Do not use
attachments that have not been recommended by the manufacturer.
• Never operate the indoor cycle if it is not working properly, or if it has been damaged.
Contact Customer Tech Support or the authorized dealers for examination and repair.
• Do not use the indoor cycle without proper footwear. NEVER operate the indoor cycle with
bare feet.
• Do not wear any clothing that might catch on any moving parts of this indoor cycle.
• Keep hands and feet clear at all times from moving parts to avoid injury. Never turn the
pedal cranks by hand.
• Do not dismount the indoor cycle until the pedals are at a complete STOP.
• Do not insert any object, hands or feet into any openings, or expose hands, arms or feet to
the drive mechanism or other potentially moving part of the indoor cycle.
• Do not use any equipment that is damaged or has worn or broken parts. Use only
replacement parts supplied by Customer Tech Support or the authorized dealers.
• Do not operate where aerosol (spray) products are being used or when oxygen is being
administered.
• Close supervision is necessary when used near children.
• This equipment is not intended for use by persons with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the equipment by a person responsible for
their safety.
• Ensure that adjustment levers (seat fore-and-aft) are properly secured and do not interfere
with range of motion during exercise.
• When adjusting the seat with one hand, while lifting and then locking the lever. Ensure
clamp is fully engaged prior to use.
• Incorrect or excessive exercise may result in serious injury or death. If you experience any
kind of pain, including but not limited to chest pains, nausea, dizziness, or shortness of
breath, stop exercising immediately and consult your physician before continuing.
• Do not jump on the unit.
• At no time should more than one person be on unit while in operation.
• This unit should not be used by persons weighing more than specified in the PRODUCT
SPECIFICATIONS SECTION. Failure to comply will void the warranty.
• Keep power cord away from heated surfaces. Do not carry this unit by its supply cord or
use the cord as a handle.
• Disconnect all power before servicing or moving the equipment. To clean, wipe surfaces
down with soap and slightly damp cloth only; never use solvents. (See MAINTENANCE)
• Never operate the unit if it has a damaged cord or plug, if it is not working properly, if it
has been dropped or damaged, or immersed in water. Return the unit to a service center
for examination and repair.
• To avoid the risk of electric shock, this piece of equipment must only be connected to a
circuit with non-looped (isolated) ground.
• To disconnect, turn all controls to the o position, then remove plug from outlet.
• Do not remove the console covers unless instructed by Customer Tech Support. Service
should only be done by an authorized service technician.
• Do not use other attachments that are not recommended by the manufacturer. Attachments
may cause injury.
• To clean, wipe surfaces down with soap and slightly damp cloth only; never use solvents.
(See MAINTENANCE)
• At NO time should pets or children under the age of 14 be closer to the unit than 10 feet.
• At NO time should children under the age of 14 use the unit.
• Children over the age of 14 should not use the unit without adult supervision.
• Heart rate monitoring systems may be inaccurate.
• Use the stationary training equipment in a supervised environment.
CAUTION!
CONSULT A PHYSICIAN BEFORE USINGTHIS EQUIPMENT. READ OWNER’S MANUAL BEFORE USE.
• It is essential that this equipment is used only indoors, in a climate controlled room. If this equipment has been exposed to colder temperatures or high moisture
climates, it is strongly recommended that the equipment is warmed up to room temperature and allowed time to dry out before first time use.
IMPORTANT PRECAUTIONS
3
ENGLISH
UNPACKING
Unpack the equipment where you will be using it. Place the carton
on a level flat surface. It is recommended that you place a protective
covering on your floor. Never open box when it is on its side.
IMPORTANT NOTES
During each assembly step, ensure that ALL nuts
and bolts are in place and partially threaded.
Several parts have been pre-lubricated to aid in assembly
and usage. Please do not wipe this o. If you have diculty,
a light application of lithium grease is recommended.
WARNING!
There are several areas during the assembly process that special
attention must be paid. It is very important to follow the assembly
instructions correctly and to make sure all parts are firmly tightened.
If the assembly instructions are not followed correctly, the
equipment could have parts that are not tightened and will seem
loose and may cause irritating noises. To prevent damage to the
equipment, assembly instructions must be reviewed and followed.
NEED HELP?
If you have questions or if there are any missing
parts, contact Customer Tech Support.
ASSEMBLY
TOOLS REQUIRED:
F3 mm Allen Wrench
F5 mm Allen Wrench
F10 mm Allen Wrench
FFlat Wrench (15mm/17mm 325L)
FPhillips Screwdriver
PARTS INCLUDED:
F1 Main Frame
F1 Front Stabilizer Tube
F1 Rear Stabilizer Tube
F1 Handlebar Set
F1 Transport Handle
F1 Bicycle Saddle
F2 Pedals
F1 Console
F1 Hardware Kit
ATTENTION WARNING
SIÈGE : TENEZ-VOUS À UNE MAIN EN
RÉGLANT LA HAUTEUR. ASSUREZ-VOUS
QUE LA FIXATION EST BIEN EN PLACE
AVANT DE COMMENCER.
UTILISEZ L’APPAREIL D’ENTRAÎNEMENT
FIXE DANS UN ENVIRONNEMENT
SUPERVISÉ SOUS LA SURVEILLANCE
DIRECTE D’UN INSTRUCTEUR FORMÉ.
INSTALLEZ ET UTILISEZ LE VÉLO
D'APPARTEMENT SUR UNE
SURFACE PLANE SOLIDE.
SEAT : HOLD WITH ONE HAND WHILE
ADJUSTING HEIGHT. ENSURE CLAMP
IS FULLY ENGAGED PRIOR TO USE.
USE THE STATIONARY TRAINING
EQUIPMENT IN A SUPERVISED
ENVIRONMENT UNDER THE DIRECT
SUPERVISION OF A TRAINED
INSTRUCTOR.
SET UP AND OPERATE THE
STATIONARY EXERCISE BICYCLE
ON A SOLID LEVEL
SURFACE.
FRAME SERIAL NUMBER
CONSOLE SERIAL NUMBER
MODEL: CXV MATRIX VIRTUAL TRAINING CYCLE
* Use the information above when calling for service.
4
ENGLISH
SADDLE
HORIZONTAL SADDLE
ADJUSTMENT LEVER
SADDLE HEIGHT
ADJUSTMENT LEVER
MAIN FRAME
SERVICE PANEL
FLYWHEEL
TRANSPORT HANDLE
REAR STABILIZER TUBE
ASSEMBLY
HANDLEBARS
PHONE HOLDER
CONSOLE
WATER BOTTLE HOLDER
CRANK
PEDALS
FRONT STABILIZER TUBE
TRANSPORT WHEELS
LEVELERS
5
ENGLISH
E
F
E
D
A
B
C
B
LEFT
PEDAL
2Hardware Qty
D Bolt (M6x50L) 1
3Hardware Qty
E
F
Bolt (M6x55-20L)
Bolt (M8x40L)
2
4
1Hardware Qty
A
B
C
Bolt (M12x25L)
Flat Washer (M12)
Bolt (M12x70L)
2
4
2
Torque Value
78 Nm / 58 ft-lb.
Torque Value
10 Nm / 7.4 ft-lb
Remove and save for step 4
ASSEMBLY
6
ENGLISH
H
H
E
G
H
ASSEMBLY
Loosen top 2 inside screws
Remove bottom 2 inside
screws and save for step 6
Remove outside screws
and save for step 7
H
Torque Value
12 Nm / 8.8 ft-lb.
H
4Hardware Qty
E
G
H
Bolt (M6x55-20L)
Bolt (M8x40-20L)
Metal plate
2
4
1
From step 3
Route wires using
provided cable ties
7Hardware Qty
H Screw (M5x12L) 5
6Hardware Qty
H Screw (M5x12L) 4
From step 5
From step 5
5Hardware Qty
H Screw (M5x12L) 9
7
ENGLISH
H
ASSEMBLY COMPLETE
8Hardware Qty
H Screw (M5x12L) 8
3 mm
9
ASSEMBLY
8
ENGLISH
CONSOLE DESCRIPTION
The Matrix machine is inspected before it is packaged. Carefully unpack the unit
and dispose of the box material. Note: There is a thin protective sheet of clear
plastic on the overlay of the console that should be removed before use.
The console has a fully integrated touch screen display. All information required for workouts is explained
on-screen. Exploration of the interface is highly encouraged. The information explaining how to program
for various workouts will give an explanation about the contents of each screen on the console.
A) GO: One Touch Start.
B) PAUSE: Displayed on-screen during workout. Pauses workout. Pause duration can be set in manager
or engineering mode. Press stop to end workout and show workout summary data.
C) USB 2.0 PORT: Device charging (output rating 5V /2A), device media, and software updates.
D) HEADPHONE JACK: Outputs audio from console to connected 3.5mm headphones.
E) ENERGY SAVER LIGHT: Indicates if machine is in energy saver mode.
F) MOTION SENSOR: Wave your hand over the sensor to wake the console.
G) RFID SENSOR: Wireless login access location.
* Supported standards with carrier frequency of 13.56 MHz include; ISO 14443 A, ISO 15693, ISO
14443 B, Sony Felica, Inside Contact-less (HID iClass), and LEGIC RF.
C F DEAG
CONSOLE OPERATION
9
ENGLISH
CONSOLE OPERATION
LOGIN SCREEN
GO SCREEN
• Touch to begin working out immediately. Or...
• Select a specific workout of your choice
PROGRAM SETUP
1) After selecting a WORKOUT, adjust the program settings appropriately
and/or begin your exercise using the default program settings.
2) Adjust your program settings.
3) Press START WORKOUT to begin your workout.
* Supported standards with carrier frequency of 13.56 MHz include; ISO 14443 A, ISO 15693, ISO 14443 B, Sony Felica, Inside Contact-less (HID iClass), and LEGIC RF.
LOGIN SCREEN
• Touch the LOGIN button to sign-in with your XID.
• Touch the GUEST button to workout anonymously.
• Touch the REGISTER button to create a new XID.
• For help or more information, touch .
• To change language, touch .
USER SIGN-IN
1) Enter your XID and PASSCODE and touch .
2) To log in using RFID, touch the RFID tag to the symbol
located on the bottom left of the console.*
REGISTER A NEW USER
1) Don’t have an xID account? Registration is easy.
2) Follow the on-screen prompts to create your free account.
3) Review your information and select the I ACCEPT THE TERMS
AND CONDITIONS box to review the Terms and Conditions.
4) Touch to complete registration. Your account
is now active and you are signed-in.
10
ENGLISH
GO SCREEN
HOME SCREEN
Change WORKOUT STATISTICS displayed at the bottom of the screen
Return to the home screen whenever you’re using an app
Adjust VOLUME and pair a BLUETOOTH device and/or ANT+ device
Increase or decrease the resistance level
Use the keypad to set resistance level. Press to confirm change
Change resistance level back to previous setting
Pause your workout. Touch to resume. After resuming, resistance
level will be reset. While paused, touch to end workout
Increase or decrease the duration of your workout
Enter cool down mode. Cool down lasts for a few minutes while reducing
the workout intensity, allowing your body to recover from your workout
Lock the screen in order to prevent accidental screen touches from being
implemented. Touch it again to unlock the screen and allow screen touches
HOME SCREEN
PROGRAM SETUP
Note: Workouts and features vary based on model type,
console configurations and software versions.
CONSOLE OPERATION
Table of contents
Other Matrix Fitness Equipment manuals
Matrix
Matrix MX-S40 User manual
Matrix
Matrix AURA Series User manual
Matrix
Matrix G7-S75-02 User manual
Matrix
Matrix MAGNUM SERIES User manual
Matrix
Matrix C50 User manual
Matrix
Matrix G3 STRENGTH User manual
Matrix
Matrix CXC User manual
Matrix
Matrix MG-A93 User manual
Matrix
Matrix VARSITY VY-D47-05 User manual
Matrix
Matrix MAGNUM SERIES User manual
Matrix
Matrix MAGNUM SERIES User manual
Matrix
Matrix G3-FW80 User manual
Matrix
Matrix AURA Series User manual
Matrix
Matrix VARSITY Series User manual
Matrix
Matrix A50 User manual
Matrix
Matrix TF30 User manual
Matrix
Matrix A30 User manual
Matrix
Matrix MAGNUM SERIES User manual
Matrix
Matrix MX-S73 User manual
Matrix
Matrix VS-S12 User manual
