Manhattan 158015 User manual

EXPRESSCARD

TO PC CARD

ADAPTER

USER

MANUAL

Model 158015

MAN-158015-UM-0308-01

Thank you for purchasing the MANHATTAN®ExpressCard to PC Card

Adapter, Model 158015.

This convenient adapter, which easily ts in any ExpressCard/34 or

ExpressCard/54 slot, lets you extend the life of Type I and Type II PC

cards instead of replacing them with newer and more expensive

ExpressCard formats — particularly convenient should an ExpressCard

fail. Installation of the adapter is quick and simple, so you’ll also soon

be enjoying the benets of these features:

• Easily share PC cards — no special cables, connectors or power

supplies are required

• Plug and Play installation; hot-swappable; Windows compatible

• Lifetime Warranty

Package Contents

• ExpressCard to PC Card Adapter

• User manual

INSTALLATION

1. Treat the ExpressCard to PC Card Adapter and your cardbus host

adapter as a single (combined) unit, and insert the unit into an

available ExpressCard/34 or ExpressCard/54 slot on your notebook

computer.

2. The applicable device driver will install automatically.

NOTE: Depending on your operating system, the installation wizard

may display a brief series of self-explanatory prompts and/or status

windows. Simply click/respond as needed.

2

SPECIFICATIONS

Standards and Certications

• CE

• FCC

• WEEE

• PC Card Standard 7.1

• PCI ExpressCard Specication, revision 1.0a

General

• Supports data transfer rates up to 2.5 Gbps (ExpressCard maximum)

limited by PC card application

• ExpressCard/34 form factor

• Compliant with PCI ExpressCard 1.0a and PC Card 7.1 standards

• Supports Type I and Type II PC cards

• 32-bit PC Cardbus compliant

• Windows 2000/XP/Vista 32/64-bit compatible

• Texas Instruments chipset

Physical

• Dimensions, overall: 127 x 63.5 x 9.5 mm (5 x 2.5 x 0.375 in.)

• Weight: 39.6 g (1.4 oz.)

3

3

Copyright © MANHATTAN

All products mentioned are trademarks or registered trademarks of their respective owners.

www.manhattan-products.com

MANHATTAN®offers a complete line

of PC Components, Peripherals, Cables and Accessories.

Ask your local computer dealer for more information

or visit us online at
