Harmony® Smart Keyboard

Setup Guide

Package contents

1. Harmony Smart Keyboard

Enables text entry, navigation of

computers and control of home

entertainment devices

2. Harmony Hub

Controls devices via IR, Bluetooth or

included USB receivers

3. 2 USB receivers

Enables text entry and navigation

on compatible USB devices

(see Connection section)

4. Power adapter

Provides power to the Harmony Hub

5. IR mini blaster*

Extends IR coverage when used in

combination with the Harmony Hub

6. USB extender*

Helps to plug USB receiver into hard-to-

reach USB slots

* Included in package, usage optional depending on setup.

3 6

Thank you for purchasing the Harmony Keyboard!

Be sure to read this guide in full to better understand how to set up and use your

Harmony Keyboard.

The Harmony Hub is the center of your Harmony system—always keep it powered on!

• The hub receives commands from the keyboard and smartphone app

• The hub sends commands to your AV devices in the form of Bluetooth® and infrared

signals, as well as through the USB receiver

• The keyboard and Harmony Hub can pair with up to two USB receivers at the same

time. To maximize the number of devices you can control, use Bluetooth pairing

whenever possible.

Visit www.logitech.com/support/harmony-keyboard for a quick video overview of the

setup process.

3 4

1. Harmony Hub

2. USB receiver

3. Smartphone app

4. Harmony Smart Keyboard

Harmony Hub to synchronize all devices

How it works

Harmony App

• Universal remote control on your smartphone

• Customization of gestures and Favorites for each smartphone

• Connection to Harmony Hub via Wi-Fi

Harmony Keyboard

• Integrated buttons to launch Harmony Activities, navigate

DVR, control volume, and play media

• Integrated touchpad for computer navigation

• Connection with the Harmony Hub via RF to send text

and Harmony commands

Bluetooth enabled devices

The hub can connect with up to 3

Bluetooth enabled devices such as

AppleTV®, Macs®, PS3®, and some PCs.

Infrared (IR) enabled AV devices

The hub emits standard infrared signals to

control your entertainment devices, such

as TV, cable/satellite box, AV receiver, etc.

IR signals from the hub and IR mini blasters reﬂect

o walls, cabinet interiors, and other surfaces before

reaching your devices—direct line of sight is generally

not required.

IP enabled streaming devices

The hub can connect via Wi-Fi with

some devices such as Roku® that enable

navigation and text entry via the same

Wi-Fi network.

USB enabled devices

The included USB receivers plug into any

available USB port on computers, Xbox

360®, and PS3* devices to enable typing

and navigation.

*Note that PS3 requires a USB connection for typing

and navigation, and a Bluetooth connection to power it

on and o.

Let’s get started

For more detailed instructions and product info, please visit www.logitech.com/support/

harmony-keyboard

STEP 1

Position the Harmony Hub

Devices on open shelves*

Place the hub on one of the shelves in an

unobstructed location.

Devices in closed cabinet*

Place the hub inside the cabinet and the

IR mini blaster on top to control your TV.

*IR signals from the hub and IR mini blasters reﬂect o walls, cabinet interiors and other surfaces before reaching your

devices—direct line of sight is generally not required.

STEP 2

Power up your Harmony Hub

Once plugged in, the hub takes approx. 30

seconds to power up.

STEP 3

Install the setup app

• Visit the Apple App Store or Google Play

and install the Harmony App.

• Launch the app, select the Setup New

Remote button, and follow setup

instructions.

If you have an iPhone 4, iPad 1 or iPad 2, or an Android

device that does not support Bluetooth, please visit

setup.myharmony.com on a computer to connect the hub

to your Wi-Fi network before beginning Step 3 of setup.

Connecting to a PC or Mac

If your computer is Bluetooth compatible

•Select ‘Bluetooth’ for your computer connection method during setup using the

Harmony App.

•Start the Bluetooth pairing process on your computer to pair the Harmony Hub

with your computer.

If your computer has an available USB port

•Follow the onscreen instructions during setup.

•Power on your computer.

•Plug in one of the two included USB receivers when instructed to do so.

•Conﬁrm the connection on Harmony App.

Connecting to other devices

AppleTV

•Power on your AppleTV

•Select ‘Bluetooth connection’ for your AppleTV during setup.

•Start the Bluetooth pairing process on your AppleTV to pair the hub with your

AppleTV.

Xbox 360

•Power on your Xbox.

•Plug in one of the two included USB receivers when instructed to do so.

•Select the connected USB receiver for your Xbox during setup.

•Conﬁrm the connection on the Harmony App.

Roku

•Ensure Roku is powered on and connected to your home network.

•Select ‘Wi-Fi connection’ for your Roku during setup.

•The hub will scan your network for Roku and automatically connect to it

once found.

PlayStation 3

•PlayStation 3 requires a Bluetooth connection to power on and o, and a USB

connection for text entry and navigation.

•Power on your PlayStation.

•Follow instructions to connect via Bluetooth.

•Follow USB receiver connection instructions on the Harmony App.

What the buttons do

1. Functions as a left mouse click.

2. Harmony Activity buttons provide one touch access to computer connected TV, Watch

TV, and Watch a Movie Activities. O will turn o all devices used in the current Activity.

3. On/o switch turns the keyboard on or o.

4. Cable/satellite box functions used to access program guides, DVR recordings, etc.

5. The Windows key also functions as the ‘Menu’ button on devices such as PS3 and Xbox,

and as the Command key on Mac computers.

6. When used in combination with Fn key, the color keys can be used to navigate PS3,

Xbox, and some cable/satellite box and DVR menus.

7. Computer Page Up/Down or set top box Channel Up/Down when used in combination

with Fn key.

2 3
