Linksys WTR54GS Operation manual

Model No.

Product Data

Wireless

WTR54GS

A Wireless Network In Your Pocket!

Shares a wired or wireless

Internet connection with

SpeedBooster, Wireless-G

and -B devices, and an

Ethernet wired PC

High security: Wi-Fi Pro-

tected Access™ (WPA),

wireless MAC address fil-

tering, powerful SPI firewall

Create temporary, per-

sonal, wireless access in your

hotel room or a coffee shop

hotspot -- pushbutton easy

Travel-friendly

design with built-

in power supply

and antenna

The Linksys Wireless-G Travel Router with SpeedBooster lets

you carry a wireless network wherever you go. There's a

built-in access point, which lets you connect SpeedBooster-

enhanced and regular Wireless-G and Wireless-B devices to

the network. There's also an Ethernet port to connect your

wired PC. The Router function ties it together and lets your

PCs share a wired or wireless Internet connection.

The travel-friendly form factor includes a built-in power sup-

ply and antenna -- it even comes with a travel case! Cre-

ate a temporary, personal, wireless access "bubble" in your

hotel room. Just plug the Router directly into the wall, and

connect the hotel's fast Internet service cable. Then use the

Router's push button setup feature to easily connect and

configure your wireless devices -- push the button on the

Router and on your other SecureEasySetup-enabled wireless

device to automatically create an encryption-secured

wireless connection. You can also create a shared-access

bubble attached to a wireless Internet connection to use

multiple devices on a single hotspot account in a coffee

shop or airport lounge.

To protect your data and privacy, the Wireless-G Broadband

Router can encode all wireless transmissions with WEP or

extra-strength WPA Personal encryption. The Router can

serve as a DHCP Server, has a powerful SPI firewall to protect

your PCs against intruders and most known Internet attacks,

and supports VPN pass-through. Configuration is a snap

with the web browser-based configuration utility.

The Linksys Wireless-G Travel Router with SpeedBooster lets

you bring the convenience of wireless networking every-

where you go.

Travel Router with SpeedBooster

Wireless-G

Model No.

Product Data

Model No.

Linksys

A Division of Cisco Systems, Inc.

18582 Teller Avenue

Irvine, CA 92612 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional Offices

throughout the world. For a complete list of local

Linksys Sales and Technical Support contacts, visit

our Worldwide Web Site at www.linksys.com.

WTR54GS

Package Contents

• Wireless-G Travel Router

•TravelRoutercase

• Setup CD-Rom with Symantec Internet

Security

• Ethernet Network Cable

• Registration Card

Wireless-G

Minimum Requirements

• 200 MHz or Faster Processor

• 64 MB or RAM

• Internet Explorer 4.0 or Netscape Navigator

4.7 or Higher for Web-based configuration

• Windows 98SE, Me, 2000, or XP

•NetworkAdapter

Specifications

Model Number WTR54GS

Standards IEEE 802.3, IEEE 802.3u, IEEE 802.11b, IEEE 802.11g

Ports/Buttons Internet: One 10/100 RJ-45 Port

LAN: One 10/100 RJ-45 Port

One Power slide

One Reset Button, One SES Button

Cabling Type UTP CAT 5

LEDs Power, Wireless, Internet, Ethernet

Transmit Power 802.11g: 12.5 dBm Typical @Normal Temp Range (+/-1.5dBm);

802.11b: 16.5dBm@Normal Temp Range (+/-1.5dBm)

Receiver Sensitivity 11Mbps @ 90 dBm; 54Mbps @ -65dBm typical

UPnP able/cert able

Security features Stateful Packet Inspection (SPI) Firewall, Internet Policy

WEP key bits Wi-Fi Protected Access™ (WPA), WEP, Wireless MAC Filtering

Environmental

Dimensions 2.87" x 4.21" x 1.22"

W x H x D (73 mm x 107 mm x 31 mm)

Weight 5.22 oz. (0.148 kg)

Power Built-in 100~240v AC

Certifications FCC, IC-03, Wi-Fi (802.11b, 802.11g), WPA

Operating Temp. 32ºF to 104F (0ºC to 40ºC)

Storage Temp. -4ºF to 158ºF (-20ºC to 70ºC)

Operating Humidity 20~85% Non-condensing

Storage Humidity 10~90% Non-condensing

Warranty 3-Years

WTR54GS-DS-50708 KL

Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2005

Travel Router with SpeedBooster

Features

• Complies with 802.11g and

802.11b (2.4GHz) Standards

• High security with Wi-Fi Pro-

tected Access™ (WPA/WPA2

Personal)

• SpeedBooster technology

increases wireless perfor-

mance by up to 35%

• Supports universal bridging

• Compact travel size router

with built-in antenna and

power adapter

• Supports Secure Easy Setup
