DEMO MANUAL DC1886B

DESCRIPTION

LTC4232 and LTC4232-1:

5A Integrated

Hot Swap Controller

Demonstration circuit 1886B features the LTC4232 and

the LTC4232-1 5A integrated Hot Swap™ controllers. The

LTC4232 is ideally suited for demanding power distribution

control in 2.9V to 15V applications for hot board inser-

tion protection, high side power switching, and electronic

circuit breaker functions. The LTC4232 provides a rich set

of features to support Hot Swap applications including:

• 2%accurateundervoltageandovervoltagecomparators

• Thermal protection

• Adjustable inrush current control

• Adjustable, 10% accurate current limit with program-

mable cutout time

• Foldback current limiting

• Programmable output voltage ramp rate

• Configurable auto-retry or latchoff on overcurrent faults

• Power good and fault outputs

• Debounce time during supply turn-on

PERFORMANCE SUMMARY

The LTC4232 debounce time is100ms,whiletheLTC4232-1

is 16ms. Both are available in a 16-lead 5mm × 3mm DFN

package. The LTC4232 is showcased on demonstration

circuit1886B-A.TheLTC4232-1 is installed onDC1886B-B.

Both demo boards are configured for 12V application. By

changing a few passive components, 2.9V to 15V applica-

tions can be easily evaluated.

The LTC4232 has limited output voltage slew rate with

a typical value of 300V/s, while the LTC4232-1 does not

have a special circuit to limit this parameter. The natural

(maximum) gate voltage slew rate (SN) of the LTC4232-1

is defined by the internal MOSFET CRSS (reverse transfer

capacitance) value and gate driver current capability. It is

48000V/s as a typical value.

Design files for this circuit board are available at

http://www.linear.com/demo/DC1886B

L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks and

Hot Swap is a trademark of Linear Technology Corporation. All other trademarks are the

property of their respective owners.

(TA= 25°C)

SYMBOL PARAMETER CONDITIONS MIN TYP MAX UNITS

VDD Board Input Supply Range Min Is UV, Max Is OV 9.2 12 15.1 V

dVGATE/dt GATE Pin Turn-On Ramp Rate LTC4232

LTC4232-1 with 10nF GATE Capacitor

0.15

1.7

0.3

2.4

0.55

3.5

V/ms

RON MOSFET + Sense Resistor On-Resistance 15 33 50 mΩ

ILIM(TH) Current Limit Threshold VFB = 1.23V, No RSET

VFB = 0V

VFB = 1.23V, RSET = 20k

5.0

1.2

2.6

5.6

1.5

2.9

6.1

1.8

3.3

VTH OV, UV, FB Pin Threshold Voltage VIN Rising 1.21 1.235 1.26 V

VUV(RTH) UV Pin Reset Threshold Voltage VUV Falling 0.55 0.62 0.7 V

VFB(HYST) FB Pin Power Good Hysteresis 10 20 30 mV

tD(AUTO-RETRY) Auto-Retry Turn-On Delay (Internal) LTC4232

LTC4232-1

100

150

TADJUST Timer Period for ADJUSTABLE Option LTC4232

LTC4232-1

9.5

0.95

12.3

1.23

16.8

1.68

dc1886bfa

DEMO MANUAL DC1886B

JUMPERS AND LEDS

Figure 1. Proper Measurement Equipment Setup

Two demo board jumpers, JP1 and JP2, allow selection

of controller operation:

• JP1 TIMER DURATION: Set to FIXED 2ms position for

the internal 2ms timer period (FIXED 2ms not recom-

mended for LTC4232-1 during auto-retry) or ADJUST-

ABLE determined by TIMER capacitor C1 (12ms for

LTC4232 and 1.2ms for LTC4232-1). (Default position:

ADJUSTABLE)

• JP2 AUTORETRY: Set to ON for auto-retry or OFF for

latchoff on overcurrent fault. (Default position: OFF)

When selecting AUTORETRY option for the circuit with a

predominantly resistive load, particularly for LTC4232-1,

pay special attention to the power MOSFET thermal con-

dition. The initial low current limit (due to the foldback

characteristic) can power the load only during a very short

time, and the MOSFET will experience the maximum cur-

rent limit for almost all of the remaining power up period.

This may exceed the MOSFET SOA, if allowed to autoretry.

Four LEDs indicate the state of the hot swap circuit. Red

LEDs, D3 and D5, provide fault status and low output

voltage (it is a NOT power good signal). Two green LEDs,

D2 and D4, signal the presence of valid input and output

voltages.

dc1886bfa

DEMO MANUAL DC1886B

QUICK START PROCEDURE

Demonstration circuit 1886B is easy to set up to evaluate

the performance of the LTC4232 or LTC4232-1. Refer to

Figure 1 for the proper measurement equipment setup

and follow the procedure below.

1. Place jumpers in the following positions:

JP1 TIMER DURATION FIXED 2ms

JP2 AUTORETRY OFF

2. With power off, connect 12V power supply terminals

to the VDD (E1) and GND (E3) turrets.

3. Turn on the 12V power supply and verify the output

voltage between the VOUT (E2) and GND (E4) turrets.

Two green LEDs, D2 and D4 should light up.

4. Check the current limit using an electronic or resis-

tive load. It should be in the range of 5A to 6.1A if an

overcurrent condition occurs while the output is high

(after powering up properly). If the output is shorted

initially, the load current will be limited in the range of

1.2A to 1.8A due to the foldback characteristic. Current

may be monitored on the IMON turret. The IMON signal

scale is 0.4V/A.

An overcurrent condition is indicated by the red LED

FLT(D3) and red LED PG (D5).

5. Check the output voltage slew rate with an oscilloscope,

without a load connected. It should take from 22ms

to 80ms for LTC4232, and from 3.0ms to 7.0ms for

LTC4232-1.

6. For DC1886B-A (LTC4232) use a 2000μF capacitive

load to demonstrate that power up mode completes

successfully. Use a current probe to verify that inrush

current is limited initially by the foldback characteristic

and later by the low output voltage slew rate.

7. For DC1886B-A use a 6000μF capacitive load to dem-

onstrate that the part not only enters into the current

limit state but operates in this state until the timer period

expires. It is not a successful power up.

8. For DC18886B-B use a 800μF capacitive load to demon-

strate a successful power up mode. The controller will

operate in current limit almost all of the timer period.

9. For DC1886B-B use a 3000μF capacitive load to

demonstrate an unsuccessful power up transient. The

operating point does not leave current limit during the

whole timer period. It will then time out and turn off.

dc1886bfa

DEMO MANUAL DC1886B

PARTS LIST

ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER

Required Circuit Components

1 0 CIN1, COUT2 CAP., SANYO\16X25\H OPT

2 1 COUT1 CAP., TANT, 22µF 25V, 20%, 7343 AVX, TPSD226M025R0200

3 1 C2 CAP., X5R, 1µF 25V, 0603 AVX, 06033D105KAT2A

4 1 D1 DIODE, 400W TRANSIENT VOLTAGE

SUPPRESSOR, SMA-DIODE

DIODES INC., SMAJ22A-13-F

5 2 D2, D4 LED, GREEN, LED-ROHM-SML-010FT ROHM, SML-010FTT86L

6 2 D3, D5 LED, RED, LED-ROHM-SML-010VT ROHM, SML-010VTT86L

7 4 E1, E2, E3, E4 TURRET, TEST PIN, 0.094" MILL-MAX, 2501-2-00-80-00-00-07-0

8 8 E5-E12 TURRET, TEST PIN, 0.064" MILL-MAX, 2308-2-00-80-00-00-07-0

9 2 JP1, JP2 JMP, HD1X3, 0.079CC SULLIN, NRPN031PAEN-RC

10 1 RMON RES., CHIP, 20k, 1/8W, 5%, 0805 YAGEO, RC0805JR-0720KL

11 0 RSET RES., CHIP, 0805 OPT

12 4 R1, R2, R3, R5 RES., CHIP, 3.3k, 1/16W, 5%, 0603 YAGEO, RC0603JR-073K3L

13 1 R4 RES., CHIP, 150k, 1/16W, 5%, 0603 YAGEO, RC0603JR-07150KL

14 3 R6, R7, R8 RES., CHIP, 20k, 1/16W, 5%, 0603 YAGEO, RC0603JR-0720KL

15 1 R9 RES., CHIP, 140k, 1/16W, 5%, 0603 YAGEO, RC0603JR-07140KL

16 1 R10 RES., CHIP, 226k, 1/16W, 5%, 0603 YAGEO, RC0603JR-07226KL

17 2 SHUNT, 0.079" CENTER SAMTEC, 2SN-BK-G

DC1886B-A Required Circuit Components

1 DC1886B-GENERAL BOM

1 C1 CAP., X5R, 1µF 25V, 0603 AVX, 06033D105KAT2A

0 CGS, CGATE CAP., 0603 OPT

0 RGATE RES., 0603 OPT

1 U1 I.C., LTC4232IDHC, DFN16DHC LINEAR TECH., LTC4232IDHC

DC1886B-B Required Circuit Components

1 DC1886B-GENERAL BOM

1 C1 CAP., X5R, 0.1µF 25V, 0603 AVX, 06033D104KAT2A

0 CGS CAP., X7R, 3300pF 100V, 5%, 0603 AVX, 06031C332JAT2A

1 CGATE CAP., X7R, 0.01µF 100V, 5%, 0603 AVX, 06031C103JAT2A

1 RGATE RES., CHIP, 100k, 1/10W, 1% 0603 NIC, NRC06F1003TRF

1 U1 I.C., LTC4232IDHC-1, DFN16DHC LINEAR TECH., LTC4232IDHC-1

dc1886bfa

DEMO MANUAL DC1886B
