Lytespan®Track Lighting System 8180WH

Page 1 of 2 Tron 36 Magnetic

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lightolier a Genlyte Thomas Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and ﬁnish.

Features

1. Transformer Housing: Die-cast aluminum. Fitter twists onto track and locks

on.

2. Movable Brass Contact: Extends for connection to 2nd circuit in Advent

Lytespan Track.

3. Polarity Keyway

4. Push Tab: Molded polycarbonate. Detaches unit.

5. Housing: .032” aluminum.

6. Lamp Holder: .032” aluminum.

7. Trunion Mounting:Tensioned with internal spring washer and vibration-

resistant nut. 90° vertical adjustment.

8. Snap-In Socket: Molded high heat resistance polymer. Eliminates need to

attach leads to lamp terminals.

9. Pivot Mounting: Tensioned; 350° stop for horizontal rotation.

10. Yoke: .187” extruded aluminum.

11. Louver/Filter Holder Accessory: Fits securely over the ﬁxture housing

with spring clips. Serves to hold spread lens, ﬁlters or louver.

Electrical/Dimming

Low voltage magnetic transformer designed to ﬁt a compact die-cast housing

scaled to complement the track. Snap-in Socket, pre-wired with sleeved No. 18

braided SF-1 leads. Use only dimmers specially rated for inductive loads (low

voltage ﬁxtures equipped with magnetic transformers) such as Lightolier

Lytemode and Scenist systems and Lightolier dimmers carrying the sufﬁx VA.

Options & Accessory

Accessories (Order Separately): 4 3/4” Dia. Series Color Filters, Heat Filters,

Spread Lenses and Louver (See Lightolier Speciﬁcation Sheets AF, AF2AS and

AL4CC) Maximum of two accessories may be used.

Finish

All painted ﬁnishes baked enamel.

Labels

UL; I.B.E.W.

Ordering Information

Catalog No. Finishes Mounting Lamps

8180WH Matte White All Lytespan Track Systems 25W-50W PAR36 12V

8180BK Matte Black

7653 Matte White Louver/Filter

7654 Matte Black Holder

Lytespan®Track Lighting System 8180WH

Page 2 of 2 Tron 36 Magnetic

Lightolier a Genlyte Thomas Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and ﬁnish.

Job Information Type:

360 2,000

25W PAR36

WFL 25°x37°

2' 90 0.9' 1.3'

3' 40 1.3' 2.0'

4' 23 1.8' 2.7'

5' 14 2.2' 3.3'

2' 1.2' 58 1.2' 1.5'

3' 1.7' 26 1.8' 2.3'

4' 2.3' 15 2.4' 3.1'

5' 2.9' 9 3.0' 3.9'

2' 2.0' 32 1.9' 1.9'

3' 3.0' 14 2.8' 2.8'

4' 4.0' 8 3.7' 3.8'

5' 5.0' 5 4.7' 4.7'

1' 1.7' 45 2.1' 1.3'

2' 3.5' 11 4.2' 2.7'

3' 5.2' 5 6.2' 4.0'

4' 6.9' 3 8.3' 5.4'

8' 258 0.3' 0.7'

12' 115 0.5' 1.0'

16' 84 0.7' 1.4'

20' 41 0.9' 1.7'

7' 4.0' 219 0.4' 8.7'

10' 5.8' 107 0.6' 1.0'

13' 7.5' 63 0.8' 1.3'

16' 9.2' 42 0.9' 1.6'

5' 5.0' 233 0.4' 0.6'

7' 7.0' 119 0.6' 0.9'

9' 9.0' 72 0.8' 1.1'

11' 11.0' 48 1.0' 1.4'

2' 5.2' 229 0.5' 0.5'

3' 6.9' 129 0.7' 0.7'

4' 8.7' 83 0.9' 0.9'

5' 10.4' 57 1.0' 1.0'

16,500 2,000

25W P AR36

VNSP (T-H) 2.5°

2' 40 2.1' 2.1'

3' 18 3.1' 3.1'

4' 10 4.2' 4.2'

5' 6 5.2' 5.2'

2' 1.2' 26 3.1' 2.4'

3' 1.7' 12 4.6' 3.6'

4' 2.3' 6 6.1' 4.8'

5' 2.9' 4 7.6' 6.0'

2' 2.0' 14 5.7' 2.9'

3' 3.0' 6 8.5' 4.4'

4' 4.0' 4 11.4' 5.9'

5' 5.0' 2 14.3' 7.4'

1' 1.7' 20 22.3' 2.1'

2' 3.5' 5 44.5' 4.2'

3' 5.2' 2 66.8' 6.2'

4' 6.9' 1 89.1' 8.3'

160 2,000

25W PAR36

VWFL 55°

DFC L W DC FC L W DC FC L W DC FC L W

Beam Spread Beam Center Rated

50% Max. CP C.P. Candelas Life-Hrs

8,000 4,000

35W PAR36

NSP (T-H) 8°

7' 163 1.0' 1.0'

10' 60 1.4' 1.4'

13' 47 1.8' 1.8'

16' 31 2.2' 2.2'

6' 3.5' 144 1.1' 1.0'

9' 5.2' 64 1.7' 1.5'

12' 6.9' 36 2.2' 1.9'

15' 8.7' 23 2.8' 2.4'

4' 4.0' 177 1.1' 0.8'

6' 6.0' 79 1.7' 1.2'

8' 8.0' 44 2.2' 1.6'

10' 10.0' 28 2.8' 2.8'

2' 3.5' 250 1.1' 0.6'

3' 5.2' 111 1.7' 0.8'

4' 6.9' 63 2.3' 1.1'

5' 8.7' 40 2.8' 1.4'

10' 250 0.9' 0.9'

15' 111 1.3' 1.3'

20' 63 1.7' 1.7'

25' 40 2.2' 2.2'

8' 4.6' 254 0.9' 0.8'

12' 6.9' 113 1.4' 1.2'

16' 9.2' 63 1.9' 1.6'

20' 11.5' 41 2.3' 2.0'

6' 6.0' 246 1.0' 0.7'

9' 9.0' 109 1.6' 1.1'

12' 12.0' 61 2.1' 1.5'

15' 15.0' 39 2.6' 1.9'

4' 6.9' 195 1.4' 0.7'

6' 10.4' 87 2.1' 1.0'

8' 13.9' 49 2.8' 1.4'

10' 17.3' 31 3.5' 1.7'

25,000 4,000

35W PAR36

VNSP (T-H) 5°

3' 100 1.6' 1.6'

5' 36 2.7' 2.7'

7' 18 3.8' 3.8'

9' 11 4.8' 4.6'

3' 1.7' 65 2.2' 1.9'

5' 2.9' 23 3.7' 3.1'

7' 4.0' 12 5.1' 4.3'

9' 5.2' 7 6.6' 5.6'

2' 2.0' 80 2.3' 1.5'

3' 3.0' 35 3.5' 2.3'

4' 4.0' 20 4.6' 3.0'

5' 5.0' 13 5.8' 3.8'

1' 1.7 113 2.7' 1.1'

2' 3.5' 28 5.5' 2.1'

3' 5.2' 13 8.2' 3.2'

4' 6.9' 7 10.9' 4.3'

900 4,000

35W PAR36

WFL (T-H) 30°

40,000 4,000

50W PAR36

VNSP (T-H) 5°

15' 178 1.3' 1.3'

20' 100 1.7' 1.7'

25' 64 2.2' 2.2'

30' 44 2.6' 2.6'

10' 5.8' 260 1.2' 1.0'

15' 8.7' 115 1.7' 1.5'

20' 11.5' 65 2.3' 2.0'

25' 14.4' 42 2.9' 2.5'

8' 8.0' 221 1.4' 1.0'

12' 12.0' 98 2.1' 1.5'

16' 16.0' 55 2.0' 2.0'

20' 20.0' 35 3.5' 2.5'

5' 8.7' 200 1.8' 0.9'

8' 13.9' 78 2.8' 1.4'

11' 19.1' 41 3.9' 1.9'

14' 24.2' 26 4.9' 2.4'

6' 97 1.4' 1.4'

8' 55 1.8' 1.8'

10' 35 2.3' 2.3'

12' 24 2.7' 2.7'

5' 2.9' 91 1.5' 1.3'

7' 4.0' 46 2.1' 1.8'

9' 5.2' 28 2.7' 2.4'

11' 6.4' 19 3.4' 2.0'

3' 3.0' 137 1.4' 1.0'

5' 5.0' 49 2.3' 1.6'

7' 7.0' 25 3.2' 2.3'

9' 9.0' 15 4.2' 2.9'

2' 3.5' 109 1.9' 0.9'

3' 5.2' 49 2.8' 1.4'

4' 6.9' 27 3.8' 1.8'

5' 8.7' 18 4.7' 2.3'

3,500 4,000

36W PAR36

NSP (T-H) 13°

8' 172 1.1' 1.1'

12' 76 1.7' 1.7'

16' 43 2.2' 2.2'

20' 28 2.8' 2.6'

7' 4.0' 146 1.3' 1.1'

10' 5.8' 71 1.9' 1.6'

13' 7.5' 42 2.4' 2.1'

16' 9.2' 28 3.0' 2.6'

5' 5.0' 156 1.4' 1.0'

7' 7.0' 79 2.0' 1.4'

9' 9.0' 48 2.5' 1.8'

11' 11.0' 32 3.1' 2.2'

3' 5.2' 153 1.7' 0.8'

4' 6.9' 86 2.3' 1.1'

5' 8.7' 55 2.8' 1.4'

6' 10.4' 38 3.4' 1.7'

11,000 4,000

50W PAR36

NSP (T-H) 8°

240 2,000

50W PAR36

VWFL 55°

2' 60 2.1' 2.1'

3' 27 3.1' 3.1'

4' 15 4.2' 4.2'

5' 10 5.2' 5.2'

2' 1.2' 39 3.1' 2.4'

3' 1.7' 17 4.6' 3.6'

4' 2.3' 10 6.1' 4.8'

5' 2.9' 6 7.6' 6.0'

2' 2.0' 21 5.7' 2.9'

3' 3.0' 9 8.6' 4.4'

4' 4.0' 5 11.4' 5.9'

5' 5.0' 3 14.3' 7.4'

1' 1.7' 30 22.3' 2.1'

2' 3.5' 8 44.5' 4.2'

3' 5.2' 3 66.8' 6.2'

4' 6.9' 2 89.1' 6.3'

3' 144 1.6' 1.6'

5' 52 2.7' 2.7'

7' 27 3.8' 3.8'

9' 16 4.8' 4.8'

3' 1.7' 94 2.2' 1.9'

5' 2.9' 34 3.7' 3.1'

7' 4.0' 17 5.1' 4.3'

9' 5.2' 10 6.6' 5.6'

2' 2.0' 115 2.3' 1.5'

3' 3.0' 51 3.5' 2.3'

4' 4.0' 29 4.6' 3.0'

5' 5.0' 18 5.8' 3.8'

1' 1.7' 163 2.7' 1.1'

2' 3.5' 41 5.5' 2.1'

3' 5.2' 18 8.2' 3.2'

4' 6.9' 10 10.9' 4.3'

1,300 4,000

50W PAR36

WFL (T-H) 30°

10' 315 0.7' 1.3'

15' 140 1.0' 2.0'

20' 79 1.4' 2.6'

25' 50 1.7' 3.3'

8' 4.6' 320 0.7' 1.2'

12' 6.9' 147 1.1' 1.8'

16' 9.2' 60 1.5' 2.4'

20' 11.5' 51 1.9' 3.0'

6' 6.0' 309 0.8' 1.1'

9' 9.0' 137 1.3' 1.7'

12' 12.0' 77 1.7' 2.2'

15' 15.0' 49 2.1' 2.8'

4' 6.9' 246 1.1' 1.0'

6' 10.4' 109 1.7' 1.6'

8' 13.9' 62 2.2' 2.1'

10' 17.3' 39 2.8' 2.6'

31,500 2,000

75W PAR36

VNSP 4°x7.5°

Lighting Data

DFC L

LAMP 0˚ AIMING ANGLE A=30˚ AIMING ANGLE A=45˚ AIMING ANGLE A=60˚ AIMING ANGLE

Aiming Angle 0˚ 30˚, 45˚ or 60˚ Horizontal 30˚, 45˚ or 60˚ Vertical

LBeam Length

WBeam Width

CDistance to center beam

DDistance

AAiming Angle

FC Footcandles

Land Ware the outer points where the candle

power drops to 50% of the maximum. FC are the

initial footcandles at the center of the beam.
