Lightolier SL301A User manual

Spectral Architectural Lighting SL301A

Page 1 of 2 Fluted Sconce 3 Fluted Forms 1-150W T3 Incandescent Halogen

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lightolier a Genlyte Thomas Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902

Features

1. Form: Unique sculped curved anodized corrugated aluminum form. These

natural materials create a new form of elegance in their simplicity and the

manner in which light is reflected off the fluted surface. Fastened over a tex-

tured black painted steel frame and back plate.

2. Optic: Wide spaced specular aluminum reflector with frosted glass protec-

tive cover.

3. Electrical Design: Steel mounting plate and mounting assembly.

Mounting

Mounting: Black backplate mounts to a standard octagonal box.

Electrical

Voltage: 120 volts incandescent operation.

Lampholder: Double ended base.

Ordering Guide (complete unit only)

Cat. No. Lamp (clear halogen) Volt Finish

SL301A 1-150W T3 (clear) 120V Anodized Aluminum

Finish

Anodized corrugated aluminum sheet with precise flutes. All painted parts are

with powder coat paint process.

Labels

UL “c/us” Listed.

Fixture conforms to Americans with Disabilities Act (ADA) Federal

Regulations—Protruding Objects.

Spectral Architectural Lighting SL301A

Page 2 of 2 Fluted Sconce 3 Fluted Forms 1-150W T3 Incandescent Halogen

Lightolier a Genlyte Thomas Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902

Job Information Type:
