Lexmark C746 User manual

Print quality guide

If the solutions here do not correct the problem, then contact customer support. You may have a printer part that requires

adjustment or replacement.

Characters have jagged or uneven edges

If you are using downloaded fonts, verify that the fonts are supported by the printer, the host computer, and the software

program.

Clipped images

Try one or more of the following:

CHECK THE GUIDES

Move the width and length guides in the tray to the correct positions for the paper size loaded.

CHECK THE PAPER SIZE SETTING

Make sure the paper size setting matches the paper loaded in the tray:

1From the printer control panel Paper menu, check the Paper Size setting.

2Before sending the job to print, specify the correct size setting:

•For Windows users, specify the size from Print Properties.

•For Macintosh users, specify the size from the Page Setup dialog.

Gray background on prints

ABCDE

Try one or more of the following:

Print quality guide

Page 1 of 13

CHECK THE BACKGROUND DARKNESS OR REMOVAL SETTING

•Adjust the darkness to a lighter setting.

•Increase the background removal setting.

MAKE SURE THERE IS NO WORN OR DEFECTIVE PRINT OR TONER CARTRIDGE

Replace the worn or defective cartridge.

Incorrect margins

ABCD

These are possible solutions. Try one or more of the following:

CHECK THE PAPER GUIDES

Move the guides in the tray to the correct positions for the paper size loaded.

CHECK THE PAPER SIZE SETTING

Make sure the paper size setting matches the paper loaded in the tray:

1From the printer control panel Paper menu, check the Paper Size setting.

2Before sending the job to print, specify the correct size setting:

•For Windows users, specify the size from Print Properties.

•For Macintosh users, specify the size from the Page Setup dialog.

Light colored line, white line, or incorrectly colored line appears on prints

ABCDE

Try one or more of the following:

MAKE SURE THERE IS NO DEFECTIVE PRINT OR TONER CARTRIDGE

Replace the worn or defective cartridge.

Print quality guide

Page 2 of 13

For more information, see the instruction sheet that came with the replacement part.

MAKE SURE THE TRANSFER MODULE IS NOT DEFECTIVE

Replace the defective transfer module.

For more information, see the instruction sheet that came with the replacement part.

Paper curl

Try one or more of the following:

CHECK THE PAPER TYPE AND WEIGHT SETTINGS

Make sure the paper type and weight settings match the paper loaded in the tray or feeder:

1From the printer control panel Paper menu, check the Paper Type and Paper Weight settings.

2Before sending the print job, specify the correct paper type setting:

•For Windows users, specify the paper type from Print Properties.

•For Macintosh users, specify the paper type from the Print dialog.

LOAD PAPER FROM AFRESH PACKAGE

Paper absorbs moisture due to high humidity. Store paper in its original wrapper until you use it.

Print irregularities

Try one or more of the following:

LOAD PAPER FROM AFRESH PACKAGE

The paper may have absorbed moisture due to high humidity. Store paper in its original wrapper until you use it.

CHECK THE PAPER TYPE AND WEIGHT SETTINGS

Make sure the paper type and weight settings match the paper loaded in the tray or feeder:

1From the Paper menu on the printer control panel, check the Paper Type and Paper Weight settings.

2Before sending the print job, specify the correct paper type setting:

•For Windows users, specify the paper type from Print Properties.

•For Macintosh users, specify the paper type from the Print dialog.

Print quality guide

Page 3 of 13

AVOID TEXTURED PAPER WITH ROUGH FINISHES

MAKE SURE THERE IS NO DEFECTIVE PRINT OR TONER CARTRIDGE

Replace the worn or defective cartridge.

MAKE SURE THE TRANSFER MODULE IS NOT DEFECTIVE

Replace the defective transfer module.

For more information, see the instruction sheet that came with the replacement part.

MAKE SURE THE FUSER IS NOT DEFECTIVE

Replace the defective fuser.

For more information, see the instruction sheet that came with the replacement part.

Print is too dark

Try one or more of the following:

CHECK THE DARKNESS, BRIGHTNESS, AND CONTRAST SETTINGS

•From the Quality menu on the printer control panel, select a lower value for these settings.

•For Windows users, change these settings from Print Properties.

•For Macintosh users:

1Choose File > Print.

2From the print options pop-up menu, choose Printer Features.

3Choose a lower value for the Toner Darkness, Brightness, and Contrast settings.

LOAD PAPER FROM AFRESH PACKAGE

The paper may have absorbed moisture due to high humidity. Store paper in its original wrapper until you use it.

Print quality guide

Page 4 of 13

AVOID TEXTURED PAPER WITH ROUGH FINISHES

CHECK THE PAPER TYPE SETTING

Make sure the paper type setting matches the paper loaded in the tray or feeder:

•From the Paper menu on printer control panel, check the Paper Type setting.

•For Windows users, check this setting from Print Properties.

•For Macintosh users, check this setting from the Print dialog.

Print is too light

Try one or more of the following:

CHECK THE DARKNESS, BRIGHTNESS, AND CONTRAST SETTINGS

The Toner Darkness setting may be too light, the Brightness setting may be too light, or the Contrast setting may be too low.

•Change these settings from the printer control panel Quality menu.

•For Windows users, change these settings from Print Properties

•For Macintosh users:

1Choose File > Print.

2From the print options pop-up menu, choose Printer Features.

3Choose a higher value for the Toner Darkness, Brightness, and Contrast settings.

LOAD PAPER FROM AFRESH PACKAGE

The paper may have absorbed moisture from high humidity. Store paper in its original wrapper until you use it.

AVOID TEXTURED PAPER WITH ROUGH FINISHES

CHECK THE PAPER TYPE SETTING

Make sure the Paper Type setting matches the paper loaded in the tray or feeder:

•From the printer control panel Paper menu, check the Paper Type setting.

•For Windows users, check this setting from Print Properties.

•For Macintosh users, check this setting from the Print dialog.

Print quality guide

Page 5 of 13

MAKE SURE THE PRINT OR TONER CARTRIDGE IS NOT LOW ON TONER

1Remove the cartridge.

Warning—Potential Damage: Be careful not to touch the photoconductor drum. Doing so may affect the print quality of

future print jobs.

2Firmly shake the cartridge side-to-side and front-to-back several times to redistribute the toner.

3Reinsert the cartridge.

Note: If print quality does not improve, then replace the cartridge of the color that is not printing.

CONTACT CUSTOMER SUPPORT

If the problem continues, then the printer may need to be serviced.

Printer is printing blank pages

Try one or more of the following:

MAKE SURE THERE IS NO PACKING MATERIAL LEFT ON THE PRINT OR TONER CARTRIDGE

Remove the cartridge and make sure the packing material is properly removed. Reinstall the cartridge.

MAKE SURE THE PRINT OR TONER CARTRIDGE IS NOT LOW ON TONER

1Remove the cartridge.

Warning—Potential Damage: Be careful not to touch the photoconductor drum. Doing so may affect the print quality of

future print jobs.

2Firmly shake the cartridge side-to-side and front-to-back several times to redistribute the toner.

3Reinsert the cartridge.

Note: If print quality does not improve, then replace the cartridge of the color that is not printing.

CONTACT CUSTOMER SUPPORT

If the problem continues, then the printer may need to be serviced.

Print quality guide

Page 6 of 13

Repeating defects appear on prints

)

Try one or more of the following:

REPLACE THE PRINT OR TONER CARTRIDGE

Replace the cartridge of the color with the repeating defect, if the defects occur in the following instances:

•Every 33 mm (1.30 in.) of the page

•Every 35.3 mm (1.39 in.) of the page

REPLACE THE PHOTOCONDUCTOR

Replace the photoconductor of the color with the repeating defect, if the defects occur in the following instances:

•Every 28.3 mm (1.11 in.) of the page

•Every 72.4 mm (2.85 in.) of the page

REPLACE THE FUSER

Replace the fuser if print defects occur in the following instances:

•Every 47.4 mm (1.87 in.) of the page

•Every 94.8 mm (3.73 in.) of the page

•Every 113 mm (4.45 in.) of the page

Shadow images appear on prints

Print quality guide

Page 7 of 13

CHECK THE PAPER TYPE AND WEIGHT SETTINGS

Make sure the paper type and weight settings match the paper loaded in the tray:

1From the Paper menu on the printer control panel, check the Paper Type and Paper Weight settings.

2Before sending the job to print, specify the correct paper type setting:

•For Windows users, specify the paper type from Print Properties.

•For Macintosh users, specify the paper type from the Print dialog.

MAKE SURE THE PHOTOCONDUCTOR IS NOT DEFECTIVE

Replace the defective photoconductor.

MAKE SURE THE PRINT OR TONER CARTRIDGE IS NOT LOW ON TONER

1Remove the cartridge.

Warning—Potential Damage: Be careful not to touch the photoconductor drum. Doing so may affect the print quality of

future print jobs.

2Firmly shake the cartridge side-to-side and front-to-back several times to redistribute the toner.

3Reinsert the cartridge.

Note: If print quality does not improve, then replace the cartridge.

CONTACT CUSTOMER SUPPORT

If the problem continues, the printer may need to be serviced.

Skewed print

CHECK THE PAPER GUIDES

Move the guides in the tray to the correct positions for the paper size loaded.

CHECK THE PAPER

Make sure you are using paper that meets the printer specifications.

Solid color or black pages appear on prints

Print quality guide

Page 8 of 13

MAKE SURE THE PHOTOCONDUCTOR IS NOT DEFECTIVE AND IS INSTALLED CORRECTLY

Remove and then reinstall the photoconductor. If the problem continues, then the photoconductor may need to be replaced.

MAKE SURE THE PRINT OR TONER CARTRIDGES ARE INSTALLED CORRECTLY, ARE NOT DEFECTIVE, AND

NOT LOW ON TONER

•Remove the cartridges, shake each cartridge from side to side to redistribute the toner, and then reinstall them.

Warning—Potential Damage: Be careful not to touch the photoconductor drum. Doing so may affect the print quality of

future print jobs.

•Reinsert the cartridges.

Note: If the quality does not improve, then replace the cartridges.

CONTACT CUSTOMER SUPPORT

If the problem continues, then the printer may need to be serviced.

Streaked horizontal lines appear on prints

ABCDE

Try one or more of the following:

SELECT ANOTHER TRAY OR FEEDER

•From the printer control panel, navigate to:

Paper Menu > Default Source > select a tray or feeder > Submit

•For Windows users, select the paper source from Print Properties.

•For Macintosh users, select the paper source from the Print dialog and pop‑up menus.

MAKE SURE THERE IS NO WORN, DEFECTIVE, OR EMPTY PRINT OR TONER CARTRIDGE

Replace the worn, defective, or empty cartridge.

Print quality guide

Page 9 of 13

Streaked vertical lines appear on prints

ABCDE

Try one or more of the following:

SELECT ANOTHER TRAY OR FEEDER

•From the printer control panel, navigate to:

Paper Menu > Default Source > select a tray or feeder > Submit

•For Windows users, select the paper source from Print Properties.

•For Macintosh users, select the paper source from the Print dialog and pop‑up menus.

MAKE SURE THERE IS NO WORN, DEFECTIVE, OR EMPTY PRINT OR TONER CARTRIDGE

Replace the worn, defective, or empty cartridge.

MAKE SURE THE TRANSFER MODULE IS NOT WORN OR DEFECTIVE

Replace the worn or defective transfer module.

Toner fog or background shading appears on the page

Try one or more of the following:

MAKE SURE THE PRINT OR TONER CARTRIDGE IS INSTALLED CORRECTLY OR IS NOT DEFECTIVE

Reinstall or replace the defective print or toner cartridge.

MAKE SURE THE TRANSFER MODULE IS NOT WORN OR DEFECTIVE

Replace the worn or defective transfer module.

MAKE SURE THE PHOTOCONDUCTOR IS NOT WORN OR DEFECTIVE

Replace the worn or defective photoconductor.

MAKE SURE THE FUSER IS NOT WORN OR DEFECTIVE

Replace the worn or defective fuser.

Print quality guide

Page 10 of 13

Other manuals for C746

This manual suits for next models

Table of contents

Other Lexmark Printer manuals

Lexmark

Lexmark C925 User manual

Lexmark

Lexmark C746 Configuration guide

Lexmark

Lexmark MS810n User manual

Lexmark

Lexmark CS310n User manual

Lexmark

Lexmark 522n - C Color Laser Printer User manual

Lexmark

Lexmark Multifunction Laser Installation and maintenance instructions

Lexmark

Lexmark 5056-xxx Instruction Manual

Lexmark

Lexmark C520 Series User manual

Lexmark

Lexmark C720 SERIES Technical manual

Lexmark

Lexmark 322n - E B/W Laser Printer Operating instructions

Lexmark

Lexmark C 540n User manual

Lexmark

Lexmark T420 User manual

Lexmark

Lexmark 25A0450 - C 736N Color Laser Printer User manual

Lexmark

Lexmark 20R1700 User manual

Lexmark

Lexmark W820n User manual

Lexmark

Lexmark MS310 4514-220 User manual

Lexmark

Lexmark 34A0050 User manual

Lexmark

Lexmark M1145 User manual

Lexmark

Lexmark Z52 User manual

Lexmark

Lexmark 22W0000 - P 350 Color Inkjet Printer User manual

Lexmark

Lexmark 34S0309 - E 260dtn B/W Laser Printer User manual

Lexmark

Lexmark 22Z0000 User manual

Lexmark

Lexmark Optra C710 User manual

Lexmark

Lexmark 5400 Series User manual

Popular Printer manuals by other brands

Canon

Canon i70 Series quick start guide

Evolis

Evolis Elypso user guide

Kyocera

Kyocera FS-9530DN specification

Canon

Canon LASER SHOT LBP-1210 Specifications

Samsung

Samsung BIXOLON SRP-350plusF user manual

Canon

Canon PIXMA PRO-1 Series Getting started

Canon

Canon PIXMA G3560 Online manual

Dell

Dell Color Laser Printer 2130cn user guide

Tektronix

Tektronix Phaser 840 user guide

Epson

Epson ET-7750 Programming guide

Canon

Canon CLBR 460ps Service manual

Eltron

Eltron P210 Guide manual

Ricoh

Ricoh MD-P1 Service manual

Epson

Epson SC-F7100 series user guide

Epson

Epson Stylus C40UX Service manual

Canon

Canon imagePASS-A2 Service guide

Canon

Canon S820D user guide

IRA3D

IRA3D POETRY4 Original instructions
