Lexmark C746 User manual

Moving guide

Before moving the printer

CAUTION—POTENTIAL INJURY: The printer weight is greater than 18 kg (40 lb) and requires two or more trained

personnel to lift it safely.

CAUTION—POTENTIAL INJURY: Before moving the printer, follow these guidelines to avoid personal injury or printer

damage:

•Turn the printer off using the power switch, and then unplug the power cord from the wall outlet.

•Disconnect all cords and cables from the printer before moving it.

•Lift the printer off of the optional drawer and set it aside instead of trying to lift the drawer and printer at the same time.

Note: Use the handholds located on both sides of the printer to lift it off the optional drawer.

Warning—Potential Damage: Damage to the printer caused by improper moving is not covered by the printer warranty.

Selecting a location for the printer

CAUTION—POTENTIAL INJURY: The printer weight is greater than 18 kg (40 lb) and requires two or more trained

personnel to lift it safely.

When selecting a location for the printer, leave enough room to open trays, covers, and doors. If you plan to install any options,

then leave enough room for them also. It is important to:

•Set up the printer near a properly grounded and easily accessible electrical outlet.

•Make sure airflow in the room meets the latest revision of the ASHRAE 62 standard or the CEN Technical Committee 156

standard.

•Provide a flat, sturdy, and stable surface.

•Keep the printer:

–Clean, dry, and free of dust.

–Away from stray staples and paper clips.

–Away from the direct airflow of air conditioners, heaters, or ventilators.

–Free from direct sunlight and humidity extremes.

•Observe the recommended temperatures and avoid fluctuations:

Ambient temperature 15.6-32.2°C (60-90°F)

Storage temperature -40° to 40°C (-40 to 104°F)

•Allow the following recommended amount of space around the printer for proper ventilation:

Moving guide

Page 1 of 2

1Right side 100 mm (3.9 in.)

2Front 400 mm (15.7 in.)

3Left side 150 mm (5.9 in.)

4Rear 100 mm (3.9 in.)

5Top 150 mm (5.9 in.)

Moving the printer to another location

The printer and options can be safely moved to another location by following these precautions:

•Any cart used to move the printer must have a surface able to support the full footprint of the printer. Any cart used to move

the options must have a surface able to support the dimensions of the options.

•Keep the printer in an upright position.

•Avoid severe jarring movements.

Shipping the printer

When shipping the printer, use the original packaging or call the place of purchase for a relocation kit.

Moving guide

Page 2 of 2
