LevelOne GEU-0522 User manual

GEU-0522

5 Port Gigabit Switch

Quick Installation Guide

English

Deutsch

Español

Français

Italiano

Português

Package Contents

Open the shipping carton of the Switch and carefully

unpack its contents.

The carton should contain the following items:

• One 5 Port Gigabit Ethernet Switch

•One power adapter

ENGLISH

Installation

LED Indicator

Connecting Equipment

Step1. Inspect the Power Adapter carefully, and make sure

that it is properly connected to a power source.

Step2. Plug-in the Power Adapter to the Switch.

Step3. Connect your network devices with the switch by

using Ethernet cable. (e.g. Cat-5e)

LED Indicator

Status

Meaning

Power

Power is on.

Off

Power is off.

Link/Act

Port is connected

Blinking

Transmitting / Receiving data

Off

Port is not connected

Deutsch

Installation

LED-Anzeige

Anschluss der Geräte

Schritt1. Bitte prüfen Sie die korrekte Verbindung des

Netzteils mit der Steckdose.

Schritt2. Verbinden Sie das Netzteil mit dem Switch.

Schritt3. Verbinden Sie weitere Geräte mit dem Switch

unter Verwendung von Ethernet-Kabeln (z.B.:

Cat.5e)

LED-Anzeige

Status

Bedeutung

Power

Power ist an.

Off

Power ist aus.

Link/Aktivität

Port ist verbunden.

Blinken

Senden/Empfangen von Daten.

Off

Port is not connected

Français

Installation physique

Indicateur DEL

Branchement de l'équipement

Étape1. Inspectez soigneusement l'adaptateur secteur et

assurez-vous qu'il est correctement connecté à

une source d'alimentation.

Étape2. Branchez l'adaptateur secteur sur le switch.

Étape3. Connectez vos périphériques réseau au switch en

utilisant un câble Ethernet. (Par exemple, Cat-5e)

Indicateur DEL

État

Signification

Alimentation

Marche

Sous tension.

Arrêt

Hors tension.

Lien/Act

Marche

Le port est connecté

Clignotant

Transmission/Réception de

données en cours

Arrêt

Le port n'est pas connecté

Español

Instalación física

Indicadores LED

Procedimiento de conexión del equipo

Paso1. Inspeccione el adaptador de corriente con cuidado,

y asegúrese de que está correctamente conectado

a una fuente de energía.

Paso2. Conecte el adaptador de corriente al Switch.

Paso3. Conecte sus dispositivos de red con el switch

mediante el uso de cable Ethernet.(Por ejemplo,

Cat-5e)

Indicadores

LED

Estado

Significado

Potencia

Encendido

El dispositivo está encendido.

Apagado

El dispositivo está apagado.

Estado de

conexíón

Encendido

El Puerto está conectado.

Intermitente

Transmitiendo / Recibiendo

datos

Apagado

El Puerto no está conectado

Italiano

Installazione fisica

Indicatore LED

Equipaggiamento diconnessione

Βήμα1. Controllare l'alimentatore con attenzione e

assicurarsi che sia correttamente collegata alla

sorgente elettrica.

Βήμα2. Collegare l'alimentatore allo switch.

Βήμα3. Collegare il proprio dispositivo di rete allo switch

con un cavo Ethernet (ad es. Cat.5e)

Indicatore LED

Stato

Significato

Alimentazione

Acceso

Alimentato

Spento

Non alimentato

Collegamento/attività

Acceso

La porta è connessa

Lampeggio

Trasmissione /ricezione

data

Spento

La porta non è connessa

Português

Instalação física

LED indicador

Conectando Equipamento

Passo1. Verifique o adaptadorde energia

cuidadosamente, e assegure-se detê-lo

conectado à tomada corretamente.

Passo2. Conecte o adaptador de energia ao Switch.

Passo3. Conecte seus dispositivos de rede no Switch

utilizando cabos ethernet. (ex. Cat-05e)

LED indicador

Status

Significado

Power

Ligar

Ligado.

Desligar

Desligado.

Link/Ativ

Ligar

Porta conectada

Piscando

Transmitindo / Recebendo dados

Desligar

Porta não conectada
