Letterbox Sentry TG1 User manual
LETTERBOX SENTRY
TG1 / FG1
Letterbox Security Device
USER MANUAL
©2021 Letterbox Sentry Ltd.
Under the copyright laws, this manual may not be copied, in whole or part,
without the written consent of the copyright holder.
Every effort has been made to ensure the accuracy of this manual. The
instructions and descriptions are accurate at the time of publication. However,
succeeding versions of the equipment and manuals are subject to change
without notice.
Letterbox Sentry Ltd assumes no liability for damages incurred directly or
indirectly from errors, omissions or discrepancies between the equipment
described and the manual.
If you have any comments or suggestions about this manual, our products, or
general feedback please contact Letterbox Sentry Ltd at the following
address:
Letterbox Sentry Ltd
Eagle Park –Unit 23
Haslams Lane
Derby DE21 4TS
Visit our website at http://www.letterboxsentry.co.uk
Letterbox SentryTM is a registered trademark of Letterbox Sentry Ltd.
Disposal & Recycling
This electronic device should not be mixed with general
household waste. For proper treatment, recovery and
recycling, please take this product to designated
collection points where it will be accepted free of
charge.
Disposal of this product correctly will help save valuable
resources and prevent any potential negative effects on human health and the
environment, which could otherwise arise from inappropriate waste handling.
2LETTERBOX SENTRY TG1/FG1 (revision. 1.0)
1 - Introduction ..…………………………………………………………. 3
Features………………..……………………………………………… 3
What is in the box ……………………..………………………… 4
2 - Functional Identification ….....……………………….……….. 5
Front panel ………………………………..……………………….. 5
Rear panel ……………………………….…………………….…… 7
Catch for locking pin ………………….……………….………. 7
3 - Power ..…………………………………………………………………. 8
Installing batteries ……………….…………………………….. 8
Battery replacement ………………………………………….. 8
DC Power Adaptor (FG1 Only) …………….……..………. 9
4 - Installation ..……………… ……………………………………….. 10
Guidance & Safety………………………………………………. 10
Tools required …….………..……………………………………. 10
Fitting the Letterbox Sentry –TG1 …….………………. 11
Fitting the Letterbox Sentry –FG1 …………………….. 12
5 - Setup ………...……………………….………………………………. 14
Setting the Time ………………………..……………………… 14
Setting the Lock Time …………..…………………………… 15
Setting the Unlock Time …………….…………………….. 16
6 - Alarms & Warnings …………………………………………….. 17
Tamper Alarm …………………………………………………… 17
Accelerant Sensor Alarm …………………………………… 17
Warnings …………………………………………………………… 18
EU Declaration of Conformity ……………………………………. 19-20
Contents
3LETTERBOX SENTRY TG1/FG1 (revision. 1.0)
Thank you for purchasing the LETTERBOX SENTRY TG1 / FG1 letterbox security
device. Please read this Owner’s Manual carefully in order to maximise the
operation of this unit.
After you have finished reading this manual, please keep it in a safe place for
future reference.
You can also download a digital copy of this manual from the Letterbox
SentryTM website (http://letterboxsentry.co.uk).
Features
When secured to the internal flap of the letterbox, the unit will give the
homeowner piece of mind by providing the following features.
•Scheduled lock and unlock times
Setting the Letterbox SentryTM to lock and unlock your letterbox
automatically at desired times, protecting your home during the hours
when you are not expecting legitimate mail. Stopping unwanted objects
from being posted into your property and prevents ‘key fishing’crime.
•Anti-Tamper alarm
If the letterbox is locked and an attempt is made to force it open, the
unit will detect a shock force and sound the inbuilt alarm. In addition, if
the unit is unable to lock due to items keeping it open, the inbuilt alarm
will sound if anyone attempts to fully open it.
•Accelerant detection alarm and automatic locking (FG1 only)
The FG1 unit has an integrated vapour sensor which will detect
flammable accelerants and other objects such as lit matches and
fireworks, locking the letterbox and setting off the inbuilt alarm to warn
the homeowner.
1 –Introduction
4LETTERBOX SENTRY TG1/FG1 (revision. 1.0)
What’s in the box
The Letterbox SentryTM comes in two Variants:
•TG1 - battery powered variant, or
•FG1 - with built in accelerant sensor & DC power adaptor
TG1
•TG1 Unit
•User manual
•6 x AA Alkaline batteries
•Fixing template
•Locking pin catch
•2 x M6 x 12mm Round Clutch Head One Way Slot Drive Machine
Screw
•2 x Plain Stainless-Steel Countersunk Head Self Tapping Screw, N°6
x 1/2in Long/13mm Long
FG1 (Accelerant sensing unit)
•FG1 Unit
•User manual
•6 x AA Alkaline batteries
•Fixing template
•Locking pin catch
•2 x M6 x 12mm Round Clutch Head One Way Slot Drive Machine
Screw
•2 x Plain Stainless-Steel Countersunk Head Self Tapping Screw, N°6
x 1/2in Long/13mm Long
•9V 2A DC power adapter
•Adhesive cable ties for the power cable.
1 –Introduction
5LETTERBOX SENTRY TG1/FG1 (revision. 1.0)
Front panel (TG1 & FG1)
1Battery cover
The unit takes 6 x AA alkaline batteries.
2Display
Shows a variety of information, including current time, lock time, unlock
time and any warnings, such as low battery and any alarms. The display is
turned off by default after 8 seconds and activated by a button press.
3BATT LED (Red)
The red LED will flash every 15 seconds when the batteries in the unit are
running low. It also briefly flashes when the unit’s lock button is pressed.
4PWR LED (Green)
The green LED periodically flashed to show that power is good and the
unit is operational. It also flashes rapidly when the unit is in alarm and
continues a 2 second flash to indicate an alarm activation.
5Unlock / + Button
A short press unlocks the letterbox. Pressing and holding the unlock
button for 4 seconds will allow the unit’s unlock time to be modified. It is
also used for adjusting time values.
2 –Functional Identification
6LETTERBOX SENTRY TG1/FG1 (revision. 1.0)
Front panel (TG1 & FG1)
6Sounder
Generates an alarm sound for 2 minutes when either the tamper alarm or
accelerant sensor alarm (FG1 only) is triggered and beeps every 5 minutes
if the batteries are running low or the DC adaptor is unplugged on the FG1
model.
7DC Power Socket (FG1 Only)
This allows for the DC power adaptor (supplied) to be connected to the
FG1 accelerant sensor model. The FG1 requires DC power to operate
correctly.
8Right Arrow Button
A short press will display the unit’s current time. Pressing and holding the
button for 4 seconds allows the unit’s internal clock to be modified. It is
also used to move the cursor when modifying the lock, unlock and clock
times.
9Lock / - Button
A short press locks the letterbox. Pressing and holding the lock button for
4 seconds allows the unit’s lock time to be modified. It is also used for
adjusting time values.
10 Left Arrow Button
This button is used to move the cursor when modifying the lock, unlock
and clock times.
11 Locking pin
This engages and disengages with the catch to lock and unlock the
letterbox.
2 –Functional Identification
7LETTERBOX SENTRY TG1/FG1 (revision. 1.0)
Rear panel (TG1 & FG1)
1. Threaded fixing holes - for security screws
2. Accelerant / Vapour sensor (FG1 Only)
3. Locking pin
Catch for locking pin
1. Screw holes - for fixing to the door
2. Locking pin locating holes –provided at different offsets to cater for
varying letterbox flap depths. Choose the hole that best aligns with the
locking pin (see installation section).
2 –Functional Identification
8LETTERBOX SENTRY TG1/FG1 (revision. 1.0)
Powering the unit
Power sources
Both the TG1 and FG1 units require 6 AA alkaline batteries (supplied) to be
installed, in addition the FG1 unit requires the connection of the supplied DC
adaptor to provide power for the vapour sensing function of that unit.
Installing AA batteries (TG1 & FG1)
Remove the battery compartment cover on the front of the unit by removing
the two cross head screws. Remove the battery carrier and load the 6 AA
batteries into the carrier, being careful to install the batteries in the correct
orientation. Replace the loaded battery carrier into the battery compartment
ensuring that the contacts align with the ones on the unit. Replace the battery
compartment cover and fix in place with the two screws.
Battery Replacement
When the BATT red LED flashes every 15 seconds and the sounder ‘chirps’
every 5 minutes, this indicates that the unit’s batteries need replacing. Replace
all 6 batteries with good quality, high-capacity Alkaline batteries as described
previously.
Once replaced, press the right arrow to display the unit’s time, and confirm
that the time is correct, if not follow the procedure to set the unit’s time
detailed in this manual.
Once the battery carrier has been removed, the unit will go into hibernate.
You must replace the batteries within 5 minutes, otherwise the unit’s real
time clock will reset.
When replacing the batteries, ensure that they are replaced with
high-capacity Alkaline AA batteries purchased from a trusted supplier.
IMPORTANT
3 –Power
9LETTERBOX SENTRY TG1/FG1 (revision. 1.0)
DC Adaptor (FG1 Only)
Plug in the supplied DC power adaptor into a nearby AC outlet and insert the
connector into the DC socket on the side of the FG1 unit, then turn the
connector clockwise to lock it in place.
If a mains power socket is not close enough, only a single socket mains
extension should be used.
To remove the DC plug from the unit, first turn the connector anti-clockwise
to unlock it before pulling it out of the unit.
In the event that the FG1 unit does not have DC power supplied, its vapour
sensing functionality will be turned off, however the unit will continue to
operate on its installed batteries, locking and unlocking at its scheduled
times.
When replacing the batteries, ensure that they are replaced with good
quality, high-capacity Alkaline AA batteries.
Do not install the battery cells backwards, do not charge, disassemble, short
circuit, put in a fire or mix with used or other battery types as this may lead
to explosion or leaking, causing injury.
Do not short circuit the battery pack.
Never use any power adaptor other than the Letterbox SentryTM supplied
adaptor. Use of a different adaptor could cause malfunction, fire or electric
shock.
Children should be supervised to ensure that they do not play with the unit or
the flex.
IMPORTANT
CAUTION
3 –Power
