Lenovo K910L User manual
Lenovo K910L
Quick Start Guide v1.0
Read this guide carefully before using your phone.
For more information about Lenovo Mobile Phone functions,
Regulatory Notices and other useful manuals, go to
http://support.lenovo.com/.
Type: CMOS
Pixels: 13.0 MP (back) + 5.0 MP (front)
GPS
Model: Lenovo K910L System: Android 4.3
Battery: 3000 mAh (Built-in battery)
Wireless communication
Display
Model and system
Power and battery
CPU and capacity
① Size and weight
Camera
①Based on actual measurements.
Size: 5.5 inches Screen: Multi-touch display
Resolution: 1080 × 1920 LCD type: IPS
CPU: Qualcom 8974 Quad core 2.2 GHz
Capacity: 16 GB
Height: 149 mm Width: 77 mm Depth: 7.9 mm
Weight: 147 g
Bluetooth 4.0 WLAN WCDMA, GSM
Technical specifications
First glance
1
6 5
107 108
1011
3
109
105
4
1010
2
Microphone
Flashlight
Micro USB
Speaker
Front camera
Power on/off
Volume key
Back camera Earphone jack
SIM card slot 5
10
Receiver 2
6
3
78
11
9
4
1
A Micro SIM card provided by your carrier is required in order to use
cellular services. Install the Micro SIM card as shown.
Installing the Micro SIM card
Step 1. Insert the Micro SIM eject tool into the hole on the Micro SIM
card tray.
Step 2. Pull out the Micro SIM card tray and place the Micro SIM
card in the tray.
Step 3. Carefully replace the tray.
Only Micro SIM cards work with your phone.
DO NOT insert or remove the Micro SIM card while your phone is
turned on. Doing so may permanently damage your Micro SIM card
or phone.
SIM
Method 1. Connect your phone to a power outlet using the included
cable and USB power adapter.
Method 2. Charge the battery using a computer.
Low battery Fully charged Charging
For more information about battery safety, see the Important Product
Information Guide.
Charge the battery as shown.
2
1
Charging the battery
Printed in China
Legal notices
Lenovo and the Lenovo logo are trademarks of Lenovo in the
United States, other countries, or both.
Other company, product, or service names may be trademarks
or service marks of others.
First Edition (December 2013)
© Copyright Lenovo 2013.
5SC9A6MXBS
Learn more
For more information about Lenovo Mobile Phone functions,
Regulatory Notices and other useful manuals, go to
http://support.lenovo.com/.
