1

User’s Manual

Model: Lenovo K860

Read this manual carefully

before operating the handset

Lenovo Mobile Phone

English

English

English

English

English

English

English

English

English

English

English

English

English

English

English

English

English

English

English

2

Technical Parameters

Product: WCDMA digital mobile phone

Model: Lenovo K860

System: Android 4.0

Size: Approximately143.6*74.5*9.5mm

Weight: Approximately192g (including battery)

Standby time: Max 214 hours*

Battery capacity：2250 mAh

SAR: 0.789W/kg@1g (HEAD) 0.903W/kg@1g (BODY).

*may vary depending on local signal strength

3

Procedure Initial Setup Procedure

Charging the phone

Inserting the SIM card

Inserting the

memory card

4

Port Assignment and Button Layout

Power key

Front Camera

Audio jack

Date/Power jack

MIC

Display Screen

Volume key

Back camera

Flash light

Speaker

MIC

5

Applications Overview

Browser

Browses websites. The web browser in

this unit can access the Internet via the

WIFI network for business and personal

use.

Email

Receives/Sends and views mails by

linking directly to your mailbox.

Gallery

Browses and edits images. In an image

full-screen page it supports slideshow

functions and such operations as,

Share,Set as, and Details.

People

Allows you to add or delete contacts

and edit or delete particulars of a

contact.

Calendar

Creates new events, toggles the day

view, the week view and the month

view, and enables the event reminder

function.

6

Gravity sensor and multi-touch

Auto roate screen according to the rotation of the device.You can

lock the K860 screen in the current direction screen rotation lock

downward. To unlock the screen dirction: Menu - Settings - Display -

Auto-roate screen.

Use the K860 in the landscape or portrait mode

After launching one application, you can rotate the screen to your

preferred direction.

7

Use the multi-touch function

The multi-touch function nables you to perform various operations on

the screen.

Open an application

Open an application: Tap the

icon of this application on the

screen.By clicking home key

, you can return to the

home screen.

Scroll

Scroll the screen by

dragging up or down on the

content.

Zoom in or out

You can zoom in or out a map

or web page while viewing

it.To do so, just move your

two fingers apart or together.

8

Precautions and Tips for K860

Never drop, strike, scratch, twist, knock, vibrate or push the K860 or

place any heavy objects on it.

Gently touch the K860.

Keep the K860 away from any magnetic substances, mobile phones

in conversation, electrical appliances or speakers.

Avoid exposing the K860 to extreme temperatures (lower than 5°C or

higher than 35°C).

Do not place the K860 in a damp environment.

Do not use corrosive detergents or solvents to clean your K860. Just

wipe the K860 screen with a damp, soft, lint-free cloth to clear

fingerprints off it.

CAUTION

RISK OF EXPLOSION IF BATTERY IS

REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES

ACCORDING TO THE INSTRUCTIONS

Hereby, Lenovo, declares that this K860 is in compliance with the

essential requirements and other relevant provisions of Directive

1999/5/EC.

This device is a 2.4 GHz wideband transmission system (transceiver),

intended for use in all EU member states and EFTA countries, except

in France and Italy where restrictive use applies.

In Italy the end-user should apply for a license at the national

9

spectrum authorities in order to obtain authorization to use the device

for setting up outdoor radio links and/or for supplying public access to

telecommunications and/or network services.

This device may not be used for setting up outdoor radio links in

France and in some areas the RF output power may be limited to 10

mW EIRP in the frequency range of 2454 –2483.5 MHz. For detailed

information the end-user should contact the national spectrum

authority in France.

This device have been tested to comply with the Sound Pressure

Level requirement laid down in the applicable EN 50332-1and/or EN

50332-2 standards. Permanent hearing loss may occur if earphones

or headphones are used at high volume for prolonged periods of

time.

CAUTION: Permanent hearing loss may occur if

earphones or headphones are use at high volume for

prolonged periods of time.

10

Panduan Penggunaan

Model: Lenovo K860

Baca panduan ini dengan baik sebelum

menggunakan ponsel

Ponsel Lenovo

Bahasa

Indonesia

Bahasa

Indonesia
