La Crosse Technology 308-1910 User manual

Model: 308-1910 www.lacrossetechnology.com/support Page | 1

Model: 308-1910

Instruction Manual

DC: 081315

WIRELESS THERMOMETER

Outdoor

Temp.

ºF/ºC

Indoor

Temp.

ºF/ºC

Time

12/24hr

Battery

Compartment

2-“AAA”

Buttons

Battery

compartment

Slide down to

remove battery

cover.

2 “AA” batteries

TX191

Temperature

Sensor

Model: 308-1910 www.lacrossetechnology.com/support Page | 2

Get Started

Step 1: Insert 2 fresh AA, LR6 1.5 volt batteries into the TX191 sensor

according to the polarity marked in the battery compartment.

The red LED will flash when transmitting.

Step 2: Insert 2 fresh AAA, LR3 1.5 volt Alkaline batteries into the

wireless thermometer according to the polarity markings.

Tip: If the outdoor temperature is not displayed after 3 minutes, remove

batteries from the outdoor sensor. Insert batteries in the outdoor sensor.

Hold the UP ▲ button for 3 seconds on the station to search for sensor.

Set Time (hours, minutes)

1. Hold the TIME button to enter time set mode.

2. Press the UP ▲ or DOWN ▼ button to adjust values.

3. Press the TIME button to confirm adjustments and move to next

item.

Settings order:

1. Hour

2. Minutes

Press TIME to exit, or wait 20 seconds without pressing buttons to return

to the normal time display.

Fahrenheit/Celsius

Press the °F/°C button to select Celsius or Fahrenheit

temperature display.

12/24 Hour Time Format

Press the UP ▲/12/24h button to select 12 hour or 24 hour

time format.

Alarm Time Set

Note: Setting the alarm time is one step. Turning the alarm ON or OFF is

a separate step.

Hold the ALARM button to enter alarm set mode. The letters “AL”

will show between the hours and minutes

Press the UP ▲ or DOWN ▼ button to adjust values.

TIME UP ▲ DOWN ▼

UP ▲

12/24h

°F/°C

Model: 308-1910 www.lacrossetechnology.com/support Page | 3

Press the ALARM button to confirm adjustments and move to next

item.

In alarm mode, press the ALARM button to turn the alarm ON and

OFF.

Settings order:

1. Hour

2. Minutes

Press ALARM to exit, or wait 20 seconds without pressing buttons to

return to the normal time display.

Activate/Deactivate the Alarm

From Time mode, press and release the ALARM button once to switch

to Alarm mode. The letters “AL” will appear between the hours and the

minutes.

Press the ALARM button to turn the alarm ON. The bell icon

will show above the seconds.

Press the ALARM button again to turn the alarm OFF.

The bell icon will disappear.

Snooze (Temporarily silences alarm)

When the alarm sounds, press the SNOOZE button to

silence the alarm for 5 minutes.

The alarm icon will flash.

The snooze function can be repeated.

Press any button except SNOOZE to turn the alarm off for 24 hours.

View/Reset MAX/MIN Readings

1. Press the MAX/MIN button once to view the maximum

indoor and outdoor temperature.

2. Press the MAX/MIN button again to view the minimum indoor

and outdoor temperature.

3. Hold the MAX/MIN button to for 3 seconds to reset all MAX/MIN

temperatures.

Outdoor Temperature Reception Icon & Search

The outdoor reception icon will flash for 3 minutes during initial

setup.

After three minutes the icon will flash about every minute as

it updates.

Hold the UP ▲ button for 3 seconds to search for

the outdoor sensor.

Outdoor

Reception

Icon

ALARM UP ▲ DOWN ▼

SNOOZE

Alarm

Icon

UP ▲

MAX/MIN

Model: 308-1910 www.lacrossetechnology.com/support Page | 4

Restart

If the outdoor temperature shows dashes, remove batteries from the

wireless thermometer & outdoor sensor. Press any button on the

wireless thermometer 20 times. After 15 minutes, return to getting

started.

Low Battery Icon

The low battery icon will show above the outdoor

temperature when it is time to change batteries in the

outdoor sensor.

Position Outdoor Sensor

Mount the outdoor sensor on a north-facing wall or in any well

shaded area. Under an eave or deck rail is preferred.

The maximum transmitting range to the wireless thermometer is

over 200 feet (60 meters) in open air, not including walls.

Specifications

Range:

Indoor Range: 32°F to 122°F (0°C to + 50°C)

Outdoor Range: -30°F to 140°F (-34.4°C to + 60°C)

Transmission: 200 feet (60 meters) open air.

Power:

Wireless Thermometer: 2-AAA LR3 alkaline batteries (not included)

TX191 Sensor: 2-AA LR6 alkaline batteries (not included)

Battery Life:

Wireless Thermometer: Battery life is over 12 months when using

reputable battery brands

TX191 Sensor: Battery life is over 12 months when using

reputable battery brands

Dimensions:

Wireless Thermometer: 4.134” H x 2.717” W x 1.454” D

(105 H x 69.01 W x 36.93 D mm)

TX191 Sensor: 4.49 H x 1.57 W x .944 D in

(114 X 40 X 24mm)

Low Battery

Icon

Model: 308-1910 www.lacrossetechnology.com/support Page | 5

Care and Maintenance

Do not mix old and new batteries

Do not mix Alkaline, Standard, Lithium or Rechargeable

Batteries

Always purchase the correct size and grade of battery most suitable

for the intended use.

Replace all batteries of a set at the same time.

Clean the battery contacts and also those of the device prior to

battery installation.

Ensure the batteries are installed correctly with regard to polarity

(+and -).

Remove batteries from equipment with is not to be used for an

extended period of time.

Remove used batteries promptly.

Warranty and Support Information

La Crosse Technology, Ltd. provides a 1-year limited time warranty (from

date of purchase) on this product relating to manufacturing defects in

materials & workmanship.

View full warranty details online at:

www.lacrossechnology.com/warranty_info.pdf

For warranty work, technical support or other information contact:

La Crosse Technology, Ltd

2830 26th Street S.

La Crosse, WI 54601

Contact Support:

1-608-782-1610

Online Product Support:

www.lacrossetechnology.com/support

Product Registration:

www.lacrossetechnology.com/support/register

Protected under U.S. Patents:

5,978,738 | 6,076,044 | RE43903

Model: 308-1910 www.lacrossetechnology.com/support Page | 6

FCC Statement

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

This device must not be co-located or operating in conjunction with any

other antenna or transmitter.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including

interference that may cause undesired operation.

Caution!

The manufacturer is not responsible for any radio or TV interference

caused by unauthorized modifications to this equipment. Such

modifications could void the user authority to operate the equipment.

even in part, or duplicated or processed using electronic, mechanical or

chemical process without the written permission of the publisher.

This booklet may contain errors or misprints. The information it contains

is regularly checked and corrections are included in subsequent editions.

We disclaim any responsibility for any technical error or printing error, or

their consequences.

All trademarks and patents are recognized.
