Kyocera FS-C5020N User manual

Product

Guide

FS-C5020N and FS-C5030N

FS-C5020N and FS-C5030N Product Guide

Published April 2005

Specifications subject to change without notice.

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Just the Facts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Key Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Productivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

KX Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Print System Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . .39

Counters, Yields, and Volume Rating . . . . . . . . . . . . . .47

Trademarks and Disclaimers . . . . . . . . . . . . . . . . . . . . .49

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

- 3 -

- 4 -

This page intentionally blank

FS-C5020N

and FS-C5030N

Product Guide

Introduction

Building on the success of the FS-C5016N, Kyocera adds

two new high quality, highly reliable, fully functional, Full-

Color printers targeting the

demands for workgroup

corporate color printing. Meet

the all new FS-C5020N and the

FS-C5030N Print Systems.

Serious Business - Serious Color

These affordable, 16 and 24ppm full-color tandem

process ECOSYS™ workgroup printers are capable of

imaging at 600 dpi for crisp colorful A4 size corporate

documents - for about 12 cents a page in full-color. In

addition, the fast PowerPC 750CXr and 750FX CPUs,

process documents quickly for maximum productivity

and minimum wait time. Plus, standard 10/100BaseTX

and convenient KX driver installation, makes the

FS-C5020N and FS-C5030N an easy addition to

corporate networks

- 5 -

With the transition of distributed documents from monochrome to color

continuing to expand at a fast pace, colour printers have become

increasingly attractive to a broader array of decision makers in the

corporate world - in some cases, even taking the place of older

monochrome models. And with color presentations and bulletins

continuing to become standard practice, the market is primed to accept

products like the FS-C5020N and FS-C5030N Full-Color Tandem

Process Printers. The award-winning FS-C5016N was designed to do

just that. With the release of the FS-C5020 and FS-C5030N, Kyocera

plans to build upon that success.

Now add the fact that Kyocera has a printer at about twelve cents

per page full-color and you’ve got a dynamic printer solution that will

grab everyone’s attention! Take a look!

No other competitor comes close to the cost savings these compact

printers produce over their lifetime. No other printer on the market will

positively impact a company’s bottom line like the FS-C5020N and the

FS-C5030N.

- 6 -

FS-C5020N and FS-C5030N Product Guide

System Overview

5% Colour Cost Pare Page All Consum ables

10.0¢ 12.0¢ 14.0¢ 16.0¢ 18.0¢ 20.0¢

FS-C5020N

FS-C5030N

HP LJ-4650

Konica M inolta M agiCo lo ur 3300

Xerox P haser 8400N

Xerox P haser 6250N

Lexmark C762N

Bro ther HL-4200CN

HP LJ-3700

XeroxDocuPrint C1618

HP LJ-3550n

M agiCo lo ur 5430DL

AUD May 26, 2005

Developed with ECOSYS technology and color printing needs in mind:

The FS-C5020N and FS-C5030N have a small footprint, fast colour

speed, and low CPP. The FS-C5020/30 are designed to meet the

colour output demands in today’s office environment. Consider the

following features:

¡Fast Monochrome and Full-Colour Printing

¡FS-C5020N: 16ppm

¡FS-C5030N: 24ppm

¡Standard 10/100BaseTX network interface

¡Ability to image onto paper sizes ranging from A5 to

A4 and on paper weights ranging from 60gsm up to 200gsm - from

the 100 Sheet Multi-Purpose Paper Tray

¡High performance PowerPC CPUs for faster processing

¡FS-C5020N: PowerPC750CXr

¡FS-C5030N: PowerPC750FX

¡High-Yield 200K Maintenance Kits

¡High Print Quality of 600DPI with 256 gradation levels along with

Kyocera’s Multi-Bit Technology

¡Optional 20GB Hard Disk Drive for faster document

processing, and storage of fonts, PRESCRIBE forms, and frequently

used documents

¡Low Cost Per Print (CPP) for both Colour and Monochrome output

providing a low TCO

Collectively, these capabilities make the FS-C5020N and FS-C5030N

affordable, easy to use, efficient, and productive workgroup Colour Print

Systems. Let’s take a closer look . . . . .

- 7 -

FS-C5020N and FS-C5030N Product Guide

System Overview

- 8 -

FS-C5020N and FS-C5030N Product Guide

This page intentionally blank

Technology

¡Type: Desktop Full-Colour/Monochrome Printers

¡Imaging System: 4 Drum Tandem

¡Colour Technology: Advanced Beam Array

¡Primary Transfer: Intermediate Transfer Belt

¡Secondary Transfer: Roller

¡Fusing: Oil-Less Heat/Pressure

¡Controller: PowerPC

¡FS-C5020N: PowerPC750CXr

¡FS-C5030N: PowerPC750FX

¡Print Resolution: Multi Bit 600 DPI (2 and 4 bit modes)

¡Gradation Levels: 256

¡Service: 200K MK-510 or MK-520 Maintenance Kit

Includes: Drum, Developer Kit, Transfer Unit, Feed Unit,

Fuser Kit, Two Ozone Filters, Roller Feed Set

¡C, M, Y, K Toner Cartridge Yield: 8K

¡Toner Type: Polymerized

¡HDD: Optional 20GB

¡Maximum Monthly Volume:

¡FS-C5020N: 85K

¡FS-C5030N: 100K

Memory Management

¡Optional 20GB HDD

¡128MB RAM (1024MB Max with 100 pin DDR DIMMs)

¡One Compact Flash Card Slot

¡One KUIO-LV Slot

Speeds

¡Warm up: FS-C5020N: 80 Seconds, FS-C5030N: 80 Seconds

FS-C5020N

FPOT Color/Mono 16 Sec

A4 (Color/Mono) 16/16 PPM

Legal (Color/Mono) 14/14 PPM

Thick (Color/Mono) 7/7 PPM

OHP (Color/Mono) 7/7 PPM

Duplex (A4) 16 PPM

Duplex A4 Efficiency 100%

Duplex (legal) 14 PPM

Duplex Legal Efficiency 100%

- 9 -

FS-C5020N and FS-C5030N Product Guide

FS-C5016NJust the Facts

FS-C5030N

FPOT Color/Mono 12 Sec

A4 (Color/Mono) 24/24 PPM

Legal (Color/Mono) 21/21 PPM

Thick (Color/Mono) 12/12 PPM

OHP (Color/Mono) 12/12 PPM

Duplex (A4) 24 PPM

Duplex A4 Efficiency 100%

Duplex (legal) 20 PPM

Duplex Legal Efficiency 95%

Paper Handling

¡Std. 500 Sheet Paper Drawer

Paper Size: A4, A5, B5, Letter, Legal.

Custom: 148mm x 210mm - 216mm x 356mm

Paper Weights: 60gsm to 105gsm

Paper Types: Plain, Recycled, Thick

¡Std. 100 Sheet Multi-Purpose Tray

Paper Size: A4, A5, B5, Letter, Legal,

Custom: 70mm x 148mm - 216mm x 297mm

Paper Weights: 60gsm to 200gsm

Paper Types: Plain, Recycled, Transparencies, Adhesive-Backed

Labels, Envelopes, Cardstock, PostCards

¡Std./Max. Paper Supply: 600/2,100 Sheets

¡Std./Max. Paper Sources: 2/5 Drawers

¡Opt. 500 Sheet Paper Drawer (Up to 3) (PF-60)

Paper Size: A4, A5, B5, Letter, Legal, Custom

Paper Weights: 60gsm to 105gsm

¡Opt. Automatic Duplex Unit (DU-301)

Paper Weights: 60gsm to 105gsm

¡Opt. Envelope Feeder (EF-60)

Up to 40mm or 1.5” Height Capacity

¡Face-Up Tray: (PT-300)

250 sheet for printer

100 sheets for Duplexer (DU-301)

Connectivity & Interface

¡Std. 10/100 BaseTX

¡Std. Hi-Speed USB 2.0

¡Std. Bi-Directional Parallel (IEEE 1284 Nibble/ECP mode)

¡Std. KUIO-LV (one slot for HDD or one of the following:)

¡Opt. IC159-WLAN IEEE 802.11b (Wireless)

¡Opt. IB-11 Serial

Page Description Languages

¡KPDL3 (Postscript 3 Emulation)

¡PCL 6 (PCL 5c/PCL XL)

¡PRESCRIBE

Fonts

¡136 KPDL PostScript

¡80 PCL 5c/PCL XL Outlines

¡1 Bitmap

FS-C5020N and FS-C5030N Product Guide

FS-C5016N

- 10 -

Just the Facts
