Konica Minolta PagePro 1350W User manual

PagePro™1350W

WarrantyExchange

Guide

1760669-001A

Trademarks

KONICA MINOLTA and the KONICA MINOLTA logo are trademarks or registered

trademarks of KONICA MINOLTA HOLDINGS, INC.

PagePro is a trademark or registered trademark of KONICA MINOLTA BUSINESS

TECHNOLOGIES, INC. All other trademarks are the property of their respective

owners.

be copied, in whole or part, nor transferred to any other media or language, without

written permission of KONICA MINOLTA BUSINESS TECHNOLOGIES, INC.

Manual Notice

KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. reserves the right to make

changes to this manual and to the equipment described herein without notice.

Considerable effort has been made to ensure that this manual is free of inaccuracies

and omissions. However, KONICA MINOLTA BUSINESS TECHNOLOGIES, INC.

makes no warranty of any kind including, but not limited to, any implied warranties of

merchantability and fitness for a particular purpose with regard to this manual.

KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. assumes no responsibility for,

or liability for, errors contained in this manual or for incidental, special, or

consequential damages arising out of the furnishing of this manual, or the use of this

manual in operating the equipment, or in connection with the performance of the

equipment when so operated.

Introduction 1

Introduction

Thank you for contacting a technical support representative to obtain

information about returning your printer for warranty exchange. Follow these

instructions very carefully.

If you need additional assistance, refer to the General Information Guide

(included with the original printer) or printer.konicaminolta.com for worldwide

sources of service and support.

Attention

Failure to follow these instructions could result in voiding your

warranty.

Exchange Procedure

Each of these steps is explained in detail in this guide.

1Unpack the exchange printer. See page 2.

2Prepare the original printer—turn it off, unplug the

power cord, and remove the interface cables and

media.

See page 3.

3Move the imaging cartridge from the original printer to

the exchange printer. See page 4.

4Finish setting up the exchange printer—fill the tray with

media, plug it in, attach the interface cables, and turn it

on.

See page 6.

5Repack the original printer, and call the shipper for

pickup. See page 8.

Unpack the Exchange Printer2

Unpack the Exchange Printer

Attention

Use caution when unpacking the exchange printer, so the packaging

(including the tape) can be used to repack the printer to be returned.

Exchange

1Unpack the exchange printer.

Exchange

2Remove the tape from the outside of the exchange printer.

A B

Prepare the Original Printer 3

Prepare the Original Printer

Exchange

3Open the media tray on the exchange printer and remove the

remaining tape and packing materials.

Original

1Turn off the original printer, unplug the power cord, and remove

the interface cable(s).

A B

Move the Imaging Cartridge4

Move the Imaging Cartridge

Original

2Remove the media from the original printer’s tray and then slide

in the output tray.

Original

1Remove the imaging cartridge (which includes both the toner

cartridge and the drum cartridge) from the original printer.

A B

Move the Imaging Cartridge 5

Exchange

2Insert the imaging cartridge in the exchange printer.

A B

Finish Setting Up the Exchange Printer6

Finish Setting Up the Exchange Printer

Exchange

1Fill the media tray with paper and then pull out the output tray.

Finish Setting Up the Exchange Printer 7

Exchange

2Plug in the power cord, connect the interface cable(s), and then

turn on the printer.

A B

Repack the Original Printer8

Repack the Original Printer

Original

1Insert the packing materials

inside the original printer.

" After inserting the

packing materials,

slide the media guides

against them to hold

them in place.

Original

2Replace the packing tape

on the front of the original

printer, and then close the

media tray.

Original

3Replace the packing tape on the outside of the original printer.
