Kogan KAMN27RQ1LA User manual
27" CURVED FREESYNC
HDR GAMING MONITOR
(2560 x 1440 144Hz)
KAMN27RQ1LA
• Read all instructions before using the appliance and retain for reference.
• Unplug the monitor before cleaning it.
• Use a clean, slightly dampened cloth to wipe the main monitor body.
• To c l e a n t h e s c r e e n : t u r n i t o f f , u n p l u g i t a n d w a i t f o r i t t o c o o l c o m p l e t e l y, t h e n
wipe it with a dry microfibre cloth.
• Do not use cleaning alcohol, ammonia-based liquids or other harsh cleaners.
• This monitor is designed with ventilation holes on the back of the casing. Do not
cover or block them.
• Do not insert any object or spray any liquid into the vents.
• Avoid placing the monitor near heaters, stoves, fireplaces or other sources of heat,
as well as in rooms lacking adequate ventilation.
• Do not position the monitor in unsafe locations. If the monitor falls, it may be
damaged and may injure nearby people.
• Unplug the monitor if it is not going to be used for an extended period.
• Do not place heavy objects on the monitor, its power cord or any connected cable.
• Do not open the back panel of the monitor, as it contains a high-voltage current
even when not plugged in.
The terms HDMI and HDMI High-Definition Multimedia Interface,
and the HDMI Logo are trademarks or registered trademarks of
HDMI Licensing Administrator, Inc. in the United States and other
countries.
SAFETY & WARNINGS
Monitor
Stand Arm
Stand Base
Screws (x4)
VESA Connectors (x4)
DisplayPort Cable
Power Adapter
User Guide
COMPONENTS
Monitor Controls
1.
Menu/Enter Button:
Press to display the OSD menu or enter sub-menus.
2.
Down Button:
Press to move down in the menu.
3.
Up Button:
Press to move up in the menu.
4.
Exit Button:
Press to exit.
5.
Power Button:
Press to turn the monitor on/off.
6.
LED Indicator:
Changes colour to indicate status.
Monitor Ports
7. Audio Output
8. DisplayPort Connector
9. HDMI Connector
10. Power Connector
OVERVIEW
Indicator Light
• A solid blue light indicates power is on and the monitor is operating normally.
• A flashing blue light indicates no video source is detected.
If no video source is detected, ensure your computer is on and all video cables are fully
inserted and/or connected.
Attention: Curved panel is fragile. Keep the foam underneath the monitor while
assembling the stand.
1. Open the packaging, remove the stand pole and base, and lock them with a screw.
Then remove the shaft assembly and attach it to the stand with two screws.
2. Remove the upper foam with the monitor laying on the lower piece. Insert the base
assembly into the rotating shaft of the monitor.
The base assembly can be removed by pulling the quick release button upwards by
hand.
ASSEMBLY
1. Open the package, take out the product with foam still attached, and gently place
it on a desktop or table. Remove the extra parts and the foam covering the back
of the monitor. Press the release button to remove the stand plate. If the monitor
was already attached to the stand, remove the stand.
2. Remove the original screws from the opening in the back of the monitor as per (1)
below.
Follow the directions received with your mount, stand, or accessory to connect. Use
the included 4 screws when mounting the monitor.
3. Follow the directions received with your mount, stand or accessory and install the
monitor on the wall or fixture as desired.
VESA MOUNT
Removable Rear Panel
This monitor features a removable rear panel that covers the input ports. It may be easier to
remove this panel before attempting to connect or remove cables from the monitor.
Power Cable
Connect the included power cable to the monitor power port, then connect the other end
into a power outlet.
CONNECTIVITY
Rear Panel
Earphones
You c an c on ne ct e ar ph on es or another audio dev ice to th e 3. 5m m output o n the mon itor.
You may need to set the Kogan monitor as your PC’s sound output device.
HDMI
Connect a device HDMI output such as a computer, DVD/Blu-ray player or console to the
monitor via an HDMI cable.
DisplayPort
Connect a DisplayPort output to the monitor via a DisplayPort cable.
