Kodak HERO User manual
User Guide
2.2/4.2 all-in-one printer
OK
abc
2
ghi
4
pqrs
78
tuv
0
wxyz
9
jkl
5
mno
6
1
def
3
4.2
2
EN-GB
1Printer Overview
Your KODAK All-in-One Printer combines ease-of-use and affordable inks to provide
high-quality pictures and documents.
Components
1 Paper guard 5 Control panel (HERO 2.2 Printer shown)
2 Paper input tray 6 Output tray
3ADF tray extender 7 Output tray extender
4 Right paper-edge guide* 8 ADF paper edge guides
*Left paper-edge guide not shown. When you
move one guide, both guides move.
9Automatic document feeder (ADF)
2
6
7
9
4
5
8
3
1
Printer Overview
3
EN-GB
10 Scanner lid 17 Kodak service number
11 Scanner glass 18 Duplexer
12 Memory card slot 19 Power cord connection port
13 Wi-Fi connectivity LED 20 USB port
14 Power button 21 Line in phone port
15 Access door 22 Ext out phone port
16 Print head with ink cartridges installed
10
1112
13
14
15
16
19 20
21
22 18
17
Printer Overview
4
EN-GB
Control panel — HERO 2.2 Printer
Feature Description
1 LCD Displays pictures, messages and
menus
2 Home button Displays the main menu
3 Navigation buttons Used to navigate menus and scroll
through pictures
4 OK button Selects a menu item, accepts
a setting and continues with the
current operation
5 Numeric keypad Used to dial a phone number or
a Quick Dial number for faxing;
to enter information and Quick
Dial settings into the fax phone
book; to specify a quantity for
making copies; and to enter
information for authenticating
access to a network
6 Cancel button Stops the current operation and
returns to the menu
7 Start button Begins copying, scanning, printing,
maintenance tasks and file transfer
8 Back button Displays the previous screen
4
3
6
5
7
1 2
8
Printer Overview
5
EN-GB
Control panel — HERO 4.2 Printer
Feature Description
1 LCD touch screen Displays icons, pictures,
messages, help, and menus
2 Back button Displays the previous screen
3 Home button Displays the main menu
4 Help button Displays context-sensitive
help
5 Start button Begins copying, scanning,
printing,faxing, maintenance
tasks and file transfer
6 Cancel button Stops the current operation,
returns to the previous menu
and closes the Help screen
43
65
1 2
Printer Overview
6
EN-GB
Home Centre Software
KODAK Home Centre Software is installed with your KODAK All-in-One Printer Software,
unless you choose otherwise. The Home Centre icon will appear on your desktop.
Paper
For the best photo printing results, use KODAK Photo Papers. For the best document
printing results, use KODAK Document Papers or a paper with the COLOURLOK Technology
logo on the package.
For more information about paper, see the Extended User Guide at
www.kodak.com/go/hero2_2manuals or www.kodak.com/go/hero4_2manuals.
Loading photo paper
For information about loading plain paper, see the Extended User Guide at
www.kodak.com/go/hero2_2manuals or www.kodak.com/go/hero4_2manuals.
The paper input tray capacity is 20 sheets of photo paper.
1Remove any paper from the tray.
2Insert the paper (short side first) into the paper
input tray with the logo side facing toward
the tray and the glossy side toward you.
IMPORTANT:
If the paper is loaded with the wrong
side up, the image quality will be
affected.
3Move the paper-edge guides until they touch the
paper.
7
EN-GB
2Basic Functions
Loading originals
You can place originals for copying, scanning, or faxing on the scanner glass or in the
automatic document feeder (ADF).
Using the scanner glass
1
If needed, remove originals from the ADF.
2Lift the scanner lid and place the document or picture face down in the front right-hand
corner.
3Close the scanner lid.
Basic Functions
8
EN-GB
Using the Automatic Document Feeder (ADF)
You can load up to 25 originals (16 to 24 lb / 60 to 90 gsm plain paper) from B5, Executive,
LTR, and A4 sizes in the ADF.
IMPORTANT:
Do not load photographs, cards, or paper stock heavier than
24 lb / 90 gsm in the ADF
.
1If needed, remove originals from the scanner glass.
2Move the ADF paper edge guides outwards.
3Fan and stack the originals, then insert them face up in the ADF.
4Move the ADF paper edge guides until they touch the paper.
ADF paper edge guides
Basic Functions
9
EN-GB
Printing
Print from anywhere using your smartphone, tablet, or computer using Google Cloud
Print™ enabled apps*, or send documents to your printer using any email service with
KODAK Email Print*. For more information, see the Extended User Guide at
www.kodak.com/go/hero2_2manuals or www.kodak.com/go/hero4_2manuals.
Printing documents
To print a document from your computer:
1Open the document.
2Select File > Print.
3In the Print window, select your KODAK Printer.
4Choose the pages to print, number of copies etc., then click OK (on a computer with
WINDOWS OS) or Print (on a computer with MAC OS).
Printing pictures
You can print pictures with your all-in-one printer from a memory card, iPhone / iPod
Touch / iPad (may not be available with all models), BLACKBERRY, or ANDROID Device;
for information on mobile printing, go to www.kodak.com/go/mobile.
You can also print pictures using Home Centre Software from your computer with
WINDOWS OS. Home Centre Software lets you edit and enhance your pictures quickly.
On a computer with either MAC OS or WINDOWS OS, you can print pictures from any
picture-editing or photo-management software.
*A GOOGLE Account is required. The device and printer must be connected to the Internet. Subject
to service availability.
Basic Functions
10
EN-GB
Printing pictures from a memory card
For more information about printing, see the Extended User Guide at
www.kodak.com/go/hero2_2manuals or www.kodak.com/go/hero4_2manuals.
HERO 2.2 Printer HERO 4.2 Printer
1Insert the memory card into the
memory card slot.
2Press or to select the picture
you want to print.
3Press OK to select each same-size
picture you want to print.
4Press .
1Insert the memory card into the
memory card slot.
2Touch or to display the picture
you want to print.
3Touch OK to select each picture you
want to print.
4Select a print size.
aPress , touch , then touch
Print Size. (Only one size can be
used per print job.)
bTouch the picture size to print.
5Press .
memory card slot
