KitchenAid KSRV22FV User guide

Side by Side Refrigerator

PRODUCT MODEL NUMBERS PRODUCT DIMENSIONS

KSRV22FV

Electrical: A 115 Volt, 60 Hz., AC only 15- or

20-amp fused, grounded electrical supply is

required. It is recommended that a separate circuit

serving only your refrigerator be provided. Use an

outlet that cannot be turned off by a switch. Do not

use an extension cord.

NOTE: Before performing any type of installation,

cleaning, or removing a light bulb, turn the control

(Thermostat, Refrigerator or Freezer control

depending on the model) to OFF and then

disconnect the refrigerator from the electrical

source. When you are finished, reconnect the

refrigerator to the electrical source and reset the

control (Thermostat, Refrigerator or Freezer

control depending on the model) to the desired

setting.

Water: A cold water line with water pressure

between 30 and 120 psi (207 and 827 kPa) is

required for the water dispenser and ice maker.

Important: The pressure of the water supply

coming out of a reverse osmosis system going to

the water inlet valve of the refrigerator needs to be

between 30 and 120 psi (207 and 827 kPa).

If a reverse osmosis water filtration system is

connected to your cold water supply, the water

pressure to the reverse osmosis system needs to

be a minimum of 40 to 60 psi (276 to 414 kPa).

Because Whirlpool Corporation policy includes a continuous commitment to improve

our products, we reserve the right to change materials and specifications without notice.

Dimensions are for planning purposes only. For complete details, see Installation

Instructions packed with product. Specifications subject to change without notice.

Ref. W10167098

07-16-08

overall

top of

cabinet

not incl.

handle

Depth Cab. Width Door Width Cab. Height Overall Height

Model "A" "B" "C" "D" "E"

KSRV22FV 32-1/8" 32-3/4" 33-1/8" 65-7/8" 66-3/8"

(81.60 cm) (83.19 cm) (84.14 cm) (167.32 cm) (168.60 cm)

Dimensions “D” and “E”

include rollers extended 3/4"

(1.9 cm).

LOCATION REQUIREMENTS

" (1.25 cm)

2" (5.08 cm)

To ensure proper ventilation for your refrigerator, allow for 1/2”(1.25 cm) space on

each side and at the top. When installing your refrigerator next to a fixed wall, leave

2”(5.08 cm) minimum on each side (depending on your model) to allow for the

door to swing open. If your refrigerator has an ice maker, allow extra space at the

back for the water line connections.

NOTE: Do not install the refrigerator near an oven, radiator, or other heat source, nor

in a location where the temperature will fall below 55°F (13°C).
