Kingston Technology DataTraveler 6000 User manual

User Manual

DataTraveler 6000

Find the language and latest documentation for DT6000 here.

............For instructions in English

. . . . . . . . . . . . . . . . . . Para instrucciones en Español

.........Für Anleitungen in Deutsch

. . . . . . . . . . . . . . . . . . Pour des instructions en Français

. . . . . . . . . . . . . . . . . . Per le istruzioni in Italiano

. . . . . . . . . . . . . . . . . . Japanese

Document No. 48000191-001.A00

DataTraveler®6000

Page 1 of 21

DataTraveler®6000 User Manual

Document No. 48000191-001.A00

DataTraveler®6000

Page 2 of 21

Table of contents

TOC

About this manual

This user manual applies to the DataTraveler®6000 (referred to simply as DT6000 from this

point forward) based on the factory image with no implemented customisations.

What’s new?

Kingston’s DT6000 Secure USB device features two removable disk volumes. The first is a

read-only data partition that houses the application files and folders, including documentation;

the second is a secure data partition that is protected by a complex user-defined password.

System requirements

PC platform

•Pentium III processor or equivalent (or

faster)

•15MB free disk space

•USB 2.0

•Two consecutive drive letters after the

last physical drive*

Supported PC operating systems

•Windows®7

•Windows®Vista SP1, SP2

•Windows®XP SP2, SP3

Mac platform

•15MB free disk space

•USB 2.0

Supported operating systems

•Mac OS X 10.5.x

•Mac OS X 10.6.x

Document No. 48000191-001.A00

DataTraveler®6000

Page 3 of 21

Recommendations

To ensure there is ample power provided to the DT6000 device, insert it directly into a USB

port on your notebook or desktop. Avoid connecting the DT6000 to any peripheral device(s)

that may feature a USB port, such as a keyboard or USB-powered hub.

*Note: See Drive Letter Conflict’ on page 20.

Setup (Windows environment)

1. Insert the DT6000 into an available USB port on

your notebook or desktop and wait for Windows

to detect it.

•Windows XP users will receive a Found

New Hardware’ notification as seen in Figure

2.1.

•Windows Vista/7 users will receive a device

driver notification as seen in Figure 2.2.

Once the new hardware detection is complete,

Windows will prompt you to begin the initialisation

process.

•Windows XP users will see an AutoPlay

window similar to the one in Figure 2.3.

•Windows Vista/7 users will see a different

AutoPlay window.

2. Select the option Run

DT6000_Launcher.exe’.

If Windows does not AutoPlay, you can browse to

the removable disk drive (Figure 2.4) and manually

execute the DT6000_Launcher program. This will

also start the initialisation process.

Figure 2.1 – Found New Hardware

(Windows XP)

Figure 2.2 – Device Driver Installation

(Windows Vista/7)

Document No. 48000191-001.A00

DataTraveler®6000

Page 4 of 21

Figure 2.4 – DT6000 contents

Figure 2.3 – AutoPlay window

(Note: Menu options in the AutoPlay

window may vary depending on what

programs are currently installed on

your computer.)

Device initialisation (Windows environment)

1. Select your language preference from the drop-down menu and click Next’ (Figure

3.1).

Figure 3.1 – Language selection

Document No. 48000191-001.A00

DataTraveler®6000

Page 5 of 21

2. Review the licence agreement and click Next’ (Figure 3.2). (Note: You must accept

the licence agreement before continuing; otherwise the Next’ button will remain

disabled.)

Figure 3.2 – Licence agreement

3. Create a password to protect your data on the DT6000. Enter it in the Password’

field, then re-enter it in the Password Confirmation’ field, as seen below in Figure 3.3.

The password you create must meet the following criteria before the initialisation process

will allow you to continue:

1. Passwords must contain 8 characters or more (up to 128 characters).

2. Passwords must contain three (3) of the following:

- UPPER CASE, lower case, numeric and/or special characters (!, $, etc.)

You may also enter a password hint, but it is not a mandatory field. The hint field can be

useful in providing a clue as to what the password is, should the password ever be

forgotten. (Note: The hint CANNOT be an exact match to the password.)

Document No. 48000191-001.A00

DataTraveler®6000

Page 6 of 21

Figure 3.3 – Password setup

4. Enter your contact information in the text boxes provided (see Figure 3.4). (Note: The

information you enter in these fields may NOT contain the password string you created in

Step 3. However, these fields are optional and can be left blank, if so desired.)

•The Name’ field may contain up to 32 characters, but cannot

contain the exact password.

•The Company’ field may contain up to 32 characters, but cannot

contain the exact password.

•The Details’ field may contain up to 128 characters, but cannot

contain the exact password.

Document No. 48000191-001.A00

DataTraveler®6000

Page 7 of 21

Figure 3.4 – Contact information

5. Click Finish’ to complete the device initialisation process. This will initiate a device

format of the secure data partition and prepare the drive for use.

Initialisation complete.

Device usage (Windows environment)

Document No. 48000191-001.A00

DataTraveler®6000

Page 8 of 21

Once the DT6000 has been initialised, you can

access the secure data partition and use the

device options by logging in to the device with

your password. To do so, follow these steps:

1. Insert the DT6000 into a USB port on your

notebook or desktop and enter your

password (see Figure 4.1).

2. Once you’ve typed your password, click the

•If the correct password is entered, the

DT6000 will unlock and you can begin

using the device.

•If an incorrect password is entered, an

error message will appear just below

the Hint’ field, indicating a login

failure (see Figure 4.2).

Figure 4.1 – Login window

During the login process, if a bad password

is entered, you will be given another

opportunity to enter the correct password;

however, there is a built-in security feature

that tracks the number of failed login

attempts*. If this number reaches the pre-

configured value of 10 failed attempts, the

DT6000 will lock and require a device

format of the secure data partition prior to

its next use.

THIS MEANS THAT ALL DATA STORED

ON THE DT6000 WILL BE LOST.

For more details on this feature, see

Device Lockout’ on page 18.

Figure 4.2 – Login failure

*Note: Once you authenticate to the device successfully, the failed login counter will reset.

Device options (Windows environment)

Document No. 48000191-001.A00

DataTraveler®6000

Page 9 of 21

While you are logged in to the device, there will be a DT6000’ icon located in the right-

hand corner of the Windows taskbar (Figure 5.1). (Note: Windows 7 users will need to click on

the Up arrow in the Taskbar to access the DT6000’ icon (Figure 5.2).

Clicking once on the DT6000 icon will display the following menu:

Figure 5.1 – DT6000 icon in Taskbar

Figure 5.2 – DT6000 icon in Taskbar

(Windows 7 users)

DT6000 settings

•Allows you to change your password and/or hint (Figure 5.3)

•Allows you to add/view/change your contact information (Figure 5.4)

•Allows you to change your current language selection (Figure 5.5)

(Note: For security purposes, your current DT6000 password is required to update and/or

modify any of these settings).

Figure 5.3

Change password

Figure 5.4

Contact information

Figure 5.5

Select language

Browse DT6000
