1. To reduce the risk of electric shock, insure

electricity has been turned off at the circuit

breaker or fuse box before beginning.

2. All wiring must be in accordance with the

National Electrical Code and local

electrical codes. Electrical installation

should be performed by a qualified

licensed electrician.

3. WARNING: To reduce the risk of electrical

shock and fire, do not use this fan with any

solid-state fan speed control device.

4. WARNING: To reduce the risk of fire,

electric shock, or personal injury, mount to

outlet box marked "Acceptable for Fan

Support of 22.7 kg (50 lbs.) Or Less"

and use mounting screws provided with

the outlet box. Most outlet boxes

commonly used for the support of light

fixtures are not acceptable for fan support

and may need to be replaced. Due to the

complexity of the installation of this fan, a

qualified licensed electrician is strongly

recommended.

5. The outlet box and support structure must

be securely mounted and capable of

reliably supporting a minimum of 50

pounds. Use only CUL Listed outlet boxes

marked "FOR FAN SUPPORT".

6. The fan must be mounted with a minimum

of 7 feet clearance from the trailing edge of

the blades to the floor.

7. To operate the reverse function on this fan,

press the reverse button while the fan is

running.

8. Avoid placing objects in the path of the

blades.

9. To avoid personal injury or damage to the

fan and other items, be cautious when

working around or cleaning the fan.

10. Do not use water or detergents when

cleaning the fan or fan blades. A dry dust

cloth or lightly dampened cloth will be

suitable for most cleaning.

11. After marking electrical connections,

spliced conductors should be turned

upward and pushed carefully up into outlet

box. The wires should be spread apart with

the grounded conductor and the

equipment-grounding conductor on one

side of the outlet box.

12. Electrical diagrams are reference only.

Light kits that are not packed with the fan

must be CUL Listed and marked suitable

for use with the model fan you are

installing. Switches must be CUL General

Use Switches. Refer to the Instructions

packaged with the light kits and switches

for proper assembly.

NOTE: SUITABLE FOR USE WITH SOLID-

STATE SPEED CONTROLS.

1. SAFETY RULES

WARNING

TO REDUCE THE RISK OF FIRE, ELECTRIC

SHOCK OR PERSONAL INJURY, MOUNT FAN TO

OUTLET BOX MARKED "ACCEPTABLE FOR FAN

SUPPORT". WARNING

TO REDUCE THE RISK OF PERSONAL INJURY,

DO NOT BEND THE BLADE BRACKETS (ALSO

REFERRED TO AS FLANGES) DURING

ASSEMBLY OR AFTER INSTALLATION. DO NOT

INSERT OBJECTS IN THE PATH OF THE BLADES.

3. PACKAGE CONTENTS

Unpack your fan and check the contents. You

should have the following items:

Philips screw driver

Slot screw driver

11 mm wrench

Step ladder

Wire cutters

2. TOOLS AND MATERIALS REQUIRED

Cottage GroveTM

a. Fan blades (5)

b. Mounting bracket

c. Canopy

d. Ball/downrod assembly (1)

& extra downrod (1)

e. Coupling cover

f. Fan assembly

g. Decorative arm

h. Upper glass shade

I. Set of blades bracket (5)

j. Mountiong plate

k. Light kit

l. Bottom Glass shade

m Decorative plate

n Finial

o Bulb

p Mounting plate

q Receiver +7 wire nuts

r CoolTouchTM Control System

s Package hardware

1) Mounting hardware:

wood screws (2), flat washers(2),

screws(2),wire nuts(4)

2) Blade attachment hardware:

screws (16), flat washers(16),

fiber washers(16)

3) Blade bracket hardware:

screws (1)

4) Safety cable hardware:

wood screw, spring washer, flat washer

5) Light kit hardware

manual nut (1) , silicon washer(1) ,

metal washer(1)

6) Balance kit

4. MOUNTING OPTIONS

Secure the outlet box directly to the building

structure. Use appropriate fasteners and

building materials. The outlet box and its

support must be able to fully support the

moving weight of the fan (at least 50 lbs). Do

not use plastic outlet boxes.

Figures 1,2 and 3 are examples of different

ways to mount the outlet box.

NOTE: You may need a longer downrod to

maintain proper blade clearance when

installing on a steep, sloped ceiling. (Fig. 3)

To hang your fan where there is an existing

fixture but no ceiling joist, you may need an

installation hanger bar as shown in Fig 4.

Outlet box

Provide strong

support

Recessed

outlet box Ceiling

mounting

plate

Outlet box

Fig. 1

Fig. 3

Fig. 4

Outlet box

Fig. 2

If there isn't an exsiting UL ( CUL for Canadian

Installation) listed mounting box, then read the

following instructions. Disconnect the power by

removing fuses or turning off circuit breakers.

Cottage GroveTM

5. HANGING THE FAN

REMEMBER to turn off the power. Follow the

steps below to hang your fan properly:

Step 2. Secure the hanger bracket to the

ceiling outlet box using screws and washers

provided. (Fig. 6)

Step 3. Remove hanger ball from downrod

assembly by loosening set screws, removing

the cross pin, and sliding ball off the rod. (Fig. 7)

Step 4. Loosen the two set screws and

remove the hitch pin and lock pin from the top

coupling of the motor assembly. (Fig. 8)

Step 1. Remove the fan motor and housing

assembly from the protective plastic bag.

Place the fan assembly into the lower pad

with the bottom of the motor facing up.(The

lower foam pad serves as a holder for the

fan during the first stages of assembly).

Remove the plastic motor shipping blocks

and discard. (Fig. 5)

Step 5. Place the upper glass bowl on the fan

assembly and tighten it to the mounting plate

with screws provided. (Fig. 8)

Step 6. Carefully feed fan wires up through the

downrod. Thread the downrod onto the motor

coupling until the hitch pin holes are aligned.

Next, replace hitch pin and lock pin, and

tighten both set screws.(Fig. 9)

Fig. 7

Fig. 5

Fig. 6

Fig. 8

Fig. 9

Downrod

Cross pin

Hanger

ball Set screw

CUL listed

electrial box

Mounting bracket

Mounting screw 120V wires

Washer

Fan housing

Screw

shipping block

Hitch pin

Set screw

Lock pin

Downrod

Mounting plate

Screw

Bulb

Upper glass bowl

Fig. 10

Fig. 11

Registration slot

Downrod

Screw

Hitch pin

Lock pin

Coupling cover

Canopy Canopy cover

Decorative arm

Step 7. Slip coupling cover, decorative arm,

canopy cover and canopy onto the downrod.

Carefully reinstall the hanger ball onto the

dowrod. Make sure that cross pin is in the

correct position and the set screw is tight

and the wires are not twisted. (Fig 10)

Step 8. Now lift the motor assembly into

position and place the hanger ball into the

hanger bracket. Rotate until the “Check Tab”

has dropped into the “Registration Slot” and

seats firmly. (Fig. 11) The entire motor

assembly should not rotate if this is done

correctly.

Cottage GroveTM

6. INSTALLATION OF SAFETY SUPPORT

( For Canadian Installation ONLY )

Fig. 12

Fig. 13

Fig. 14

An additional safety support is provided to

prevent the fan from falling. Secure the safety

cable to the ceiling joist with screw and

washer, as illustrated in Figure 12.

7. MAKE THE ELECTRIC CONNECTIONS

Code switch

Receiver

Hanger

bracket

Battery Compartment

Hanger bracket Safety cable

WARNING: To avoid possible electrical

shock, be sure electricity is turned off at the

main fuse box before wiring.

NOTE: The CoolTouchTM Control System is

equipped with 16 code combinations to

prevent possible interference from or to other

remote units. The frequency switches on your

receiver and transmitter have been preset at

the factory. Please recheck to make sure the

switches on the transmitter and receiver are

set to the same position, any combination of

settings will operate the fan as long as the

transmitter and receiver are set to the same

position. (Fig. 13)

Step 2. (Fig. 14) Motor to Receiver Electrical

Connections: Connect the black wire from the

fan to black wire marked "TO MOTOR L" from

the receiver. Connect the white wire from

the fan to the white wire marked "TO MOTOR

N" from the receiver. Connect the blue wire

from the fan to the blue wire marked "For

Bottom Light" from the receiver. Connect the

orange wire from the fan to the orange wire

marked “For Upper Light” from the receiver.

Secure all the wire connections with the plastic

wire nuts provided. (Fig. 15 on next page)

Step 1. Insert the receiver into the mounting

bracket, and keep flat in opposition of ceiling.

(Fig. 14)

Fig. 15

Fig. 16

Step 1. Tuck connections neatly into ceiling

outlet box.

NOTE: adjust the canopy screws as necessary

until the canopy and canopy cover are snug.

(Fig.16)

Note: Fan must be installed at a maximum

distance of 30 feet from the transmitting unit for

proper signal transmission between the

transmitting unit and the fan's receiving unit.

8. FINISHING THE INSTALLATION

Step 2. Slide the canopy up to ceiling and

onto the two screws on hanger bracket.

Rotate the canopy clockwise and tighten both

screws.

Step 3. Receiver to House Supply Wires

Electrical Connections: Connect the black

(hot) wire from the ceiling to the black wire

marked "AC in L" from the receiver. Connect

the white(neutral) wire from the ceiling to the

white wire marked "AC in N" from the Receiver.

Secure the wire connections with the plastic

wire nuts provided. (Fig. 15)

Step 4. If your outlet box has a ground wire

(green or bare copper) connect it to the fan

ground wires; otherwise connect the hanging

bracket ground wire to the mounting bracket.

Secure the wire connection with a plastic nut

provided. After connecting the wires, spread

them apart so that the green and white wires

are on one side of the outlet box and black

and blue wires are on the other side.

Carefully tuck the wire connections up into

the outlet box. (Fig. 15)

Canopy cover

Canopy

Screw

Hanger bracket

Outlet box

white (neutral)

Orange

(For upper light)

Outlex box

Black (hot)

Black("AC" IN L")

Receiver

Black ("to motor L")

Blue (for bottom light)

Orange

(For upper light)

Black (motor)

White (neutral)

Green or bare

Copper (ground)

White("to motor N")

Ground -(Connect to

White("AC IN N")

(green) ground wire on

if no house ground

hanger bracket

wire exists)

Blue (for bottom light)

Warning: Make sure the “Check Tab” at the

bottom of the hanger bracket is properly seated

in the “Registration Slot” on the side of the

hanger ball before attaching the canopy to the

bracket. To seat the “Check Tab” improperly

could damage the electrical wires when to ceil-

ing fan blade direction is changed while the fan

is running.

CAUTION: All set screws must be checked and

retightened where necessary.

Cottage GroveTM

9. ATTACHING THE FAN BLADES

Fig. 17

Fig. 19

Fig. 18

10. INSTALLATING THE MOUNTING PLATE

Step 1 Attach the blade to the blade bracket

using the screws, washers and fiber washers

as shown in Figure 17. Start screw into

bracket. Repeat for the two remaining screws.

1. Remove the 1 of 3 screws from the

mounting ring and loosen the other 2 screws.

(Do not remove)

2. Place the key holes on the mounting plate

over the 2 screws previously loosened from

the mounting ring, turn mounting plate until it

locks in place at the narrow section of the key

holes. Secure by tightening the 2 screws

previously loosened and the one previously

removed. (Fig. 19)

Step 2. Make sure the blade is straight and

tighten each screw.

Step 3. Fasten blade assembly to motor using

"pre-installed" mounting screws in the blade

bracket . (Fig. 18)

Blade

Screw

Metal washer

Blade bracket

Fiber washer

Blade bracket

Blade

Screw

Mounting plate

Mounting ring

Screw

Table of contents

Other Kichler Lighting Fan manuals

Kichler Lighting

Kichler Lighting Fit User manual

Kichler Lighting

Kichler Lighting Monarch II User manual

Kichler Lighting

Kichler Lighting 35156 User manual

Kichler Lighting

Kichler Lighting 65" GENTRY User manual

Kichler Lighting

Kichler Lighting Almere User manual

Kichler Lighting

Kichler Lighting Spyn User manual

Kichler Lighting

Kichler Lighting Select Dorset User manual

Kichler Lighting

Kichler Lighting Golden Iridescence User manual

Kichler Lighting

Kichler Lighting Decor InnesII 300130 User manual

Kichler Lighting

Kichler Lighting Terra Select User manual

Kichler Lighting

Kichler Lighting 35153 Manual

Kichler Lighting

Kichler Lighting 52 inch Colerne LED User manual

Kichler Lighting

Kichler Lighting FLYY 310700MWH User manual

Kichler Lighting

Kichler Lighting Canfield 300117WH User manual

Kichler Lighting

Kichler Lighting Crescent 300325 User manual

Kichler Lighting

Kichler Lighting Ried 300356 User manual

Kichler Lighting

Kichler Lighting KAPONO User manual

Kichler Lighting

Kichler Lighting Cameron User manual

Kichler Lighting

Kichler Lighting Lacey User manual

Kichler Lighting

Kichler Lighting Renew Select Patio User manual

Kichler Lighting

Kichler Lighting Emerson HIGH COUNTRY User manual

Kichler Lighting

Kichler Lighting Seaside 310181WZC User manual

Kichler Lighting

Kichler Lighting Arkwet Patio User manual

Kichler Lighting

Kichler Lighting Kittery Point User manual

Popular Fan manuals by other brands

ELTA FANS

ELTA FANS H03VV-F installation guide

Hunter

Hunter 20714 Owner's guide and installation manual

Emerson

Emerson CARRERA VERANDA CF542ORB00 owner's manual

Hunter

Hunter Caraway Owner's guide and installation manual

Panasonic

Panasonic FV-15NLFS1 Service manual

Kompernass

Kompernass KH 1150 operating instructions

VES

VES FALA100/12V/TR Original instructions

Vertiv

Vertiv Liebert DCD user manual

Westinghouse

Westinghouse GFP Series owner's manual

Venmar

Venmar KUBIX HRV PLUS Series user guide

Maico

Maico ECR 31 installation instructions

Sonnenkonig

Sonnenkonig Dinky instruction manual

S&P

S&P ECOWATT HXBR manual

Wider

Wider IMP03369BH instruction manual

Panasonic

Panasonic F-60DHN Operating and installation instructions

Hinkley

Hinkley HIGHLAND instruction manual

Broan

Broan 766BN installation guide

Premium

Premium PFS16022 Use manual
