Jam Plus HX-P240 Instruction Manual

R35

HEY THERE!

JUST CHARGE IT

WE’RE HERE TO HELP. CONTACT US!

HX-P240

USER GUIDE AND

WARRANTY INFORMATION

You’ve got questions? We’ve got answers.

Contact a Consumer Relations representative by

phone or email to help answer any questions.

Please be sure to have the model number of your

product available. (Hint: It’s HX-P240)

you bought it and how you’re using it is like

gold for the people who make these speakers.

To register, visit:

USA: www.jamaudio.com/customer-support/product-registration

CAN: canada.jamaudio.com/product-registration

Charging the speaker is so easy you’ve probably ﬁgured it out by now, but just in case, you’ve got two options: you can charge it

using your computer or a wall outlet. The JAM Plus needs about 3 hours for up to 6 hours of party time.

The LED lights on your speaker let

you know what it’s doing.

1. The cord that came with the speaker — the

one with the USB on one end and the micro

USB on the other — will work with your

computer.

2. If you want to use the wall outlet, you’ll need

to pick up a power cord with a micro USB the

next time you’re at the store, or use any USB AC

adapter, including the one for your cell phone.

SHED SOME LIGHT

BLUETOOTH®CONNECTION — IT’S A SETUP

Like any amazing couple, this one starts with a connection — one

between your device and the speaker’s Bluetooth. Here’s how it works:

1. Make sure the smartphone, tablet, or computer you’re using with the

speaker has Bluetooth.

2. Turn on the speaker (press and hold the power button for 3 seconds)

and look for the little blinking light.

3. Do whatever your device needs you to do on its end.

USA

[email protected]

1.888.802.0040

8:30am–7:00pm EST M–F

[email protected]

1.888.225.7378

8:30am–5:00pm EST M–F

CANADA

4. Look for JAM Plus in your device’s Bluetooth list or click YES.

5. Now hit PLAY on your speaker and crank it up — or down if you’re lame.

The device and Bluetooth will ﬁnd each other every time, as long as the speaker is set

to Bluetooth and your device’s Bluetooth is, you know, on.

If you’re connecting to a computer, you may have some extra steps on that end. You’ll

have to get that information from the computer company.

Depending on your device, you may be prompted to enter a pairing code. If prompted,

enter “0000” as the code.

To disable pairing of an existing device and pair a new device, press and hold the

PLAY/PAUSE button for 5 seconds to activate pairing mode.

Note: If you turn on your JAM Plus but haven’t started the party yet, it will automatically

power off after 2 minutes of unpaired inactivity.

Note: Once you've paired, if you pause the party for 15 minutes or more, the JAM Plus

will automatically shut off to preserve battery power.

Note: You should never have to do this, but in the event the speaker controls are not

operable, press the reset button to reset the speaker.

Thank you for purchasing

the JAM Plus. Check

out the sections below

for all the important

information about your

new speaker.

Pairing Mode

Bluetooth Light Battery Light

Connected Charging

Ready to Party

Aux-In Mode

Low Battery

Continued on page 2.

AC adapter not included.

CONTROL YOUR DESTINY ... OR AT LEAST YOUR SPEAKER

Bluetooth®

Devices

JAM Plus

1. Check out how much juice is in the battery

2. Turn the music down

3. Push it to play, push it again to pause

4. Turn the music up

5. Lets you know when Bluetooth is paired

6. JAM2light shows when two JAM Plus

speakers are paired.

7. Here’s where you hook it up old-school

8. The power cord goes here

9. This is the power button

10. Toggle between languages here

11. Reset

12. Speaker mode switch

Bottom:

Back:

Reset

10 11

HELLO? SPEAKERPHONE? YES!

BLUETOOTH®CONNECTION, CONTINUED

Like any amazing couple, this one starts with a connection — one

between your device and the speaker’s Bluetooth. Here’s how it works:

1. Make sure the smartphone, tablet, or computer you’re using with the

speaker has Bluetooth.

2. Turn on the speaker (press and hold the power button for 3 seconds)

and look for the little blinking light.

3. Do whatever your device needs you to do on its end.

4. Look for JAM Plus in your device’s Bluetooth list or click YES.

5. Now hit PLAY on your speaker and crank it up — or down if you’re lame.

The device and Bluetooth will ﬁnd each other every time, as long as the speaker is set

to Bluetooth and your device’s Bluetooth is, you know, on.

If you’re connecting to a computer, you may have some extra steps on that end. You’ll

have to get that information from the computer company.

Depending on your device, you may be prompted to enter a pairing code. If prompted,

enter “0000” as the code.

To disable pairing of an existing device and pair a new device, press and hold the

PLAY/PAUSE button for 5 seconds to activate pairing mode.

Note: If you turn on your JAM Plus but haven’t started the party yet, it will automatically

power off after 2 minutes of unpaired inactivity.

Note: Once you've paired, if you pause the party for 15 minutes or more, the JAM Plus

will automatically shut off to preserve battery power.

Note: You should never have to do this, but in the event the speaker controls are not

operable, press the reset button to reset the speaker.

When friends call asking to join the party — and you know they will — answer the phone without disconnecting from your JAM Plus.

Yes, that’s right. Your speaker is a speakerphone, too. How amazing is that? Here’s how it works:

1. Make sure your phone and speaker are connected through Bluetooth.

2. Answering and ending a call works the same way: simply click the PLAY/PAUSE button on your JAM Plus.

3. If you’d rather not talk, hold down the PLAY/PAUSE button on your JAM Plus for 3 seconds to ignore the call.

THE COOLEST PART: The JAM Plus knows when a call is coming in and pauses the music before ringing. When you hang up, the

music starts where it left off — and so does the party. If it’s you making the call, just start dialing from your phone, and the JAM Plus

automatically does its hands-free thing. Isn’t it refreshing to know your speaker totally gets you?

Check out the chart below for a complete guide on handling calls with your JAM Plus.

Note: When handling calls in JAM2mode, only the master speaker (that’s the left one) can control the call.

COMING CLEAN

A soft, dry towel is all you need to

clean off your speaker. Using water,

harsh cleaners, or anything else only

starts messing with the mechanics

inside. So, yeah, don’t do it.

HOOKING UP OLD-SCHOOL AUDIO, JACK

1. Plug one end of the cord into the speaker

and the other into the headphone jack on

your device.

2. Turn on the speaker.

3. Hit PLAY on your device and crank it up —

or down if you’re lame.

You’ll have to play and pause the music from

your device, not your speaker. No problem.

You’re there anyway, right?

1. Turn the speaker over

and set the speaker

mode switch to “Mono.”

2. Press and hold the

power button for 5

seconds to turn on.

3. Follow the instructions

above to pair your

speaker.

4. Press play on your

device and crank it up —

or down if you’re lame.

1. Set the speaker mode switch on speaker 1 to “L.”

2. Set the speaker mode switch on speaker 2 to “R.”

3. Turn on speaker 1 (press and hold the power

button for 5 seconds).

4. Turn on speaker 2 (press and hold the power

button for 5 seconds).

5. The speakers will begin to pair together

automatically. This can take up to 30 seconds.

6. When you hear a tone and the JAM2indicator light

is illuminated white, you may pair your device.

7. Follow the instructions above to pair your speakers.

Choose Jam2 from your device’s Bluetooth list.

2m 15m

PAIRING ONE SPEAKER PAIRING TWO JAM PLUS SPEAKERS TOGETHER

L –Mono –R

Bluetooth

Devices

JAM Plus

Bluetooth

Devices

Jam2

Track 1

L –Mono –R L –Mono –R

Situation

Short Press Play/Pause Button Long Press Play/Pause Button

1st Incoming call

On call

Pick up call

End call

Reject call

Auxiliary cable not included.

STUFF THE GOVERNMENT MAKES US SAY STUFF OUR LAWYERS MAKE US SAY

A MESSAGE FROM THE ENVIRONMENT

FCC Compliance:

Note: This device complies with part 15 of the FCC Rules. Operation

is subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired

operation.

Note: This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a

particular installation.

If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or

more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Note: Changes or modiﬁcations not expressly approved by HMDX

could void the user's authority to operate this equipment.

IC Caution: RSS-GEN Issue 4 November 2014

This device complies with Industry Canada’s licence-exempt RSSs.

Operation is subject to the following two conditions: (1) This device

may not cause interference, and (2) This device must accept any

interference, including interference that may cause undesired

operation of the device.

IMPORTANT SAFEGUARDS:

When using an electrical product, basic precautions should always be

followed, including the following:

READ ALL INSTRUCTIONS BEFORE USING

• WARNING: Do not place speakers too close to ears. May cause

damage to eardrums, especially in young children.

• Use this product only for its intended use as described in this

manual. Do not use attachments not recommended by HMDX.

• HMDX is not liable for any damage caused to smartphones,

iPod/MP3 players, or any other device.

• Do not place or store this product where it can fall or be dropped

into a tub or sink.

• Do not place or drop into water or any other liquid.

• Not for use by children. THIS IS NOT A TOY.

• Never operate this product if it has a damaged cord, plug, cable,

or housing.

• Keep away from heated surfaces.

• Only set on dry surfaces. Do not place on surface wet from water or

cleaning solvents.

Attention California Residents:

WARNING: This product contains chemicals known to the State

of California to cause cancer, birth defects, and other

reproductive harm.

WARNING:

This product has an internal, non-replaceable lithium battery. Please

dispose in accordance with your local, state, province, and country

guidelines.

This product contains small parts that may present a choking hazard

for young children.

CAUTION: All servicing of this product must be performed by

authorized HMDX Service Personnel only.

IB-HXP240B BC

1 YEAR LIMITED WARRANTY

THE VOICE FROM WITHIN

When your JAM Plus isn’t rocking out, it can tell you all sorts

of things it’s doing: when it’s powering on, ready to pair,

paired, at maximum volume, charging, receiving a call, ending

a call, rejecting a call, and powering off.

Just like the global gadget it is, your speaker toggles between

several languages or no language at all. Your speaker can

parlay with you in English, Spanish, French, or Portuguese.

Making the change between language and tone is as simple

as poking a paperclip, safety pin, or the included language

selector pin into the small hole on the bottom of the speaker.

Click though until the speaker starts speaking your language.

For detailed warranty instructions and information visit:

USA: www.jamaudio.com/customer-support/warranty-1yr

CAN: canada.jamaudio.com/warranty-1yr

To obtain warranty service on your JAM product, contact a

Consumer Relations representative by telephone or email

for assistance (you can ﬁnd their contact info on page 1).

Please make sure to have the model number of the

product available.

Other Jam Plus Speakers manuals

Jam Plus

Jam Plus HX-P240 User manual

Popular Speakers manuals by other brands

argon audio

argon audio IE20 quick start

Denon

Denon SC-N7 owner's manual

Gemline

Gemline Ace 3952 user manual

Focal

Focal ON WALL 300 User manua

HEADRUSH

HEADRUSH Maximus HRSP 5024 manual

SoundLogic

SoundLogic BCCS-6/6395 instruction manual

Peavey

Peavey DTH 218 Specification sheet

Avantree

Avantree Pluto Air user guide

Morel

Morel Integra Series INTEGRA OVATION 4 install guide

Oppo

Oppo SONICA quick start guide

Bose

Bose SoundLink Wireless Music System owner's guide

Rocksteady

Rocksteady Stadium owner's manual

Bowers & Wilkins

Bowers & Wilkins 4 owner's manual

Sonance

Sonance SONOS OUTDOOR Series installation manual

Electro-Voice

Electro-Voice EVID FM4.2 Brochure & specs

Pioneer

Pioneer XW-HTD630 manual

Onn

Onn BWA16AA002 Product guide

HP GL313AA - USB Speakers PC Multimedia quick start guide
