Jacuzzi Nova 5 User manual

nova™ 5 pure air®II bath

nova—a brightly burning star. the nova™ pure air®II bath—a rejuvenating point of light in your day, your night, your routine.

Clean lined and classic, the Nova™ whirlpool

is versatility deﬁned.

features:

• Exclusive 360º Balanced Airﬂow™ system

• 600 watt variable speed heated air blower

• Thermal Lumbar Comfort (TLC)™

• Safely use salts and aromatic oils

• PrO3™ Ozone Sanitation System standard

nova™5 pure air®II bath

model number: EA00 – LH

exterior dimensions:

60" long x 42" wide x 18½" high

interior dimensions:

41" long x 27" wide x 18" high

operating gallons:

46 gallons

Nova™ 5 Pure Air® II Bath

Model: EA00

Installation Notes

Refer to installation instructions included with ﬁxture before beginning installation.

Please conﬁrm product availability and speciﬁcations before commencing with any

installation work.

PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE

WITHOUT NOTICE.

Electrical Components and Electrical Speciﬁcations do not apply to non-jetted baths.

Ordering Information

Product Code:

EA00 Nova® 5 Pure Air® II Bath

Left Hand

• Left Hand Drain Location

• Accessories / Hardware:

Trip-Lever Drain Kit #X559

Rotary Drain Kit, 26” Cable #8730

• Trim Kit Finishes Available:

(827) – Chrome

(898) – Brushed Chrome

(815) – Satin Nickel

(829) – Bright Brass

(805) – Platinum

(826) – Brushed Nickel

(849) – Oil Rubbed Bronze

Technical Speciﬁcations

Dimensions

60” L x 42” W x 18-1/2” H

(1524 mm) L x (1067 mm) W x (470 mm) H

Drain/Overﬂow

A: 14-3/4” (375 mm) B: 8-1/2” (216 mm)

Cutout

58” x 40” (1473 mm x 1016 mm)

Total Weight

795 lb (361 kg )/ 45.4 lb/ft2(222 kg/m2)

Operating Gallonage

46 U.S. Gal. (174 Liters)

Min. 35 U.S. Gal. (133 Liters)

Max. 54 U.S. Gal. (204 Liters)

Product Weight

97 lb (44 kg)

Skirt Mounting

Optional, U-Frame

Electrical Speciﬁcations

Requires a dedicated GFCI protected separate circuit.

Blower: 120 VAC, 15 AMP, 60 Hz.

Heater

No water heater is available on this unit. Blower has integral air heater.

NOVA® 5, LEFT HAND AIR BATH

*60"

21"

42"

11" x 4"

Blower

12" H x 18" L

Service Access

Opt. Service Access

2''

8-1/2''

5-3/8''

NOVA® 5, RIGHT HAND PURE AIR II BATH

END VIEW

18-1/2"

42"

SIDE VIEW

60"

(51 mm) (Blower)

#FR00 12/06

DRAIN/OVERFLOW

Product Shown: Nova® 5 Pure Air II Bath Left Hand Model: EA00

* Measurements inside unit represent cutout in ﬂoor to allow for drain/overﬂow.

Minimum Service Access dimensions given.
