Jacuzzi Duetta 6042 User manual

Looking for a Jacuzzi®bath for two? Consider the Duetta™ Salon™ Spa,

a lush, oval whirlpool designed for discerning bathers.

FEATURES:

 

 ®

 

 

 

 

 

 

 

 

 

 3



Duetta™6042 |

Duetta™





DZ35 (Right-hand)



60" long x 42" wide x

26" high



4 TheraPro™

8 Back Jets & Foot Jets



77 - 83 gallons

Technical Speciﬁcations

DIMENSIONS

60” L x 42” W x 26” H

(1524 mm) L x (1067 mm) W x (660 mm) H

DRAIN/OVERFLOW

A: 18.4” (467 mm) B: 11” (279 mm)

CUTOUT

Template Provided Part Number: DA09000

TOTAL WEIGHT

999 lbs (453 kg) / 57.1 lb/sq. ft. (2279 kg/m2)

OPERATING GALLONAGE

Min. 77 U. S. Gal. (291 liters)

Max. 83 U.S. Gal. (314 liters)

PRODUCT WEIGHT

110 lbs (50 kg)

SKIRT MOUNTING

Not Available

ELECTRICAL SPECIFICATIONS

Requires a dedicated GFCI protected separate circuit.

Blower: 120VAC, 20AMP, 60 Hz.

Motor/Pump and RapidHeat™: 240VAC, 20AMP, 60 Hz.

HEATER (STANDARD)

Requires a dedicated GFCI protected separate circuit.

RapidHeat™: P/N BN60000

INSTALLATION NOTES

Refer to installation instructions included with ﬁxture before

beginning installation. Please conﬁrm product availability and

speciﬁcations before commencing with any installation work.

PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT

TO CHANGE WITHOUT NOTICE.

#FR31000 01/08

Duetta™6042

SALON™SPA

DZ35 Duetta™ 6042 Salon™ Spa with Chromatherapy

Right Hand

• Center Drain Location

• Accessories / Hardware:

TheraPro™ Jet Rings Kit: #D095

Sch 40, Rotary Drain Kit: #DA34

• Trim Kit Finishes Available:

(827) – Chrome

(898) – Brushed Chrome

(815) – Satin Nickel

(829) – Bright Brass

(805) – Platinum

(826) – Brushed Nickel

(845) – Oil Rubbed Bronze

Product Shown: Duetta™ 6042 Salon™ Spa

Right Hand Model: DZ35

* Measurements inside unit represent cutout

in ﬂoor to allow for drain/overﬂow.

Minimum Service Access dimensions given.

11.04"

42"

30"

3.84"

13" x 4" 2"

Motor

Heater

12" H x 24" L

Service Access

Blower

END VIEW

26"

42"

SIDE VIEW

60" 1/2"

(13 mm)

(Motor)

(Inlet Heater)

(Blower)

DRAIN/OVERFLOW
