Jabra BT2090 User manual

User manual

www.jabra.com

Jabra BT2090

ENGLISH

JABRA BT2080

CONTENTS

THANKYOU....................................................2

ABOUTYOURJABRABT2090...................................2

WHATYOURHEADSETCANDO................................3

GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

CHARGEYOURHEADSET.......................................4

TURNING YOUR HEADSET ON AND OFF . . . . . . . . . . . . . . . . . . . . . . . . 4

PAIRINGITWITHYOURPHONE.................................4

CONNECTING WITH YOUR PHONE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

WEARITHOWYOULIKEIT.....................................6

HOWTO .......................................................6

HOW THE STATUSDISPLAY™ WORKS. . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

TROUBLESHOOTING&FAQ ....................................8

NEEDMOREHELP?.............................................9

TAKING CARE OF YOUR HEADSET . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

WARNING!....................................................10

SAFETYINFORMATION!.......................................11

BUILT BATTERYCARE:......................................11

CHARGERCARE: ..............................................12

WARRANTY...................................................13

CERTIFICATION ...............................................15

GLOSSARY....................................................16

ENGLISH

JABRA BT2090

THANK YOU

Thank you for purchasing the Jabra BT2090 Bluetooth® headset.

We hope you enjoy it! This instruction manual will get you started

and ready to make the most of your headset.

ABOUT YOUR JABRA BT2090

A. Answer/end button

C. StatusDisplayTM

With battery indicator and Bluetooth connection indicator

D. Charging socket

E. Volume up/down

F. Ear hook

ENGLISH

JABRA BT2090

WHAT YOUR HEADSET CAN DO

Your Jabra BT2090 lets you do all this:

- Answer calls

- End calls

- See battery status

- See Bluetooth connection status

- Reject calls*

- Voice dialling*

- Last number redial*

- Mute

- Transfer calls

- Adjust volume

- Talk time 6 hours

- Standby time 8 days

- B .1 with EDR and eSCO

- Weight 8 gram

- Operating range up to 10 meters (approximately 33 feet)

- Supported B

- Internal rechargeable battery charged by wall charger

- Always see your battery and connection status on the

Jabra StatusDisplay™

GETTING STARTED

You should follow three steps before using your headset

1 Charge your headset

2 Activate Bluetooth on your mobile phone (refer to the

manual for your mobile phone)

3 Pair your headset to your mobile phone

The Jabra BT2090 is easy to operate. The answer/end button on

you press it.

* Phone dependent

ENGLISH

JABRA BT2090

Instruction Duration of press

Tap

Press Approx: 1 second

Press and hold Approx: 5 seconds

CHARGE YOUR HEADSET

Make sure that your headset is fully charged for two hours before

you start using it. Use the AC power supply to charge from a

power socket. When the battery indicator has a solid red light,

your headset is charging. When the headset is fully charged the

Use only the charger provided in the box - do not use chargers

from any other devices as this may damage your headset.

Please note: T

if your device is left uncharged for a long period. We therefore

recommend that you recharge your device at least once a month.

TURNING YOUR HEADSET ON AND OFF

Slide the switch to the 'I' position to power on, and to the 'O' position

to power o.

PAIRING IT WITH YOUR PHONE

Headsets are connected to phones using a procedure called

‘pairing’. By following a few simple steps, a phone can be paired

with a headset in a matter of minutes.

1 Put the headset in pairing mode

- When you turn on your Jabra BT

headset will automatically start up on pairing mode – i.e. it is

discoverable for your phone. When the headset is in pairing

mode the Bluetooth status indication on the StatusDisplay™ is

ENGLISH

JABRA BT2090

2 Set your Bluetooth phone to‘discover’ the Jabra BT2090

- Follow your phone’s instruction guide. First make sure that

Bluetooth is activated on your mobile phone. Then set your

phone to discover new devices. This usually involves going

to a‘setup,’‘connect’or‘Bluetooth’ menu on your phone and

selecting the option to ‘discover’or ‘add’ a Bluetooth device.*

- BT2090”.

Your phone then asks if you want to pair with the headset.

Accept by pressing‘Yes’or‘OK’on the phone. You may be asked

. Then use 0000 (4 zeros). Your

Bluetooth

light to steady light.

CONNECTIVITY

SELECT

MobilSurf

BLUETOOTH

Infrared port

Wap options

Synchronization

Networks

DEVICES FOUND

Jabra BT2090

Passkey:

****

HANDSFREE

SELECT

Jabra BT2090

added.

The handsfree is

now ready for use

SELECT

Manual pairing mode

pairing process was interrupted, you can manually set the headset

to pairing mode.

Make sure the headset is on. Press and hold the answer/end

button for approximately 5 seconds until the Bluetooth icon turns

. Then repeat steps 2 and 3 in

the above pairing guide.

CONNECTING WITH YOUR PHONE

used together. When the headset and phone have been paired

once, they will automatically connect when the headset is on and

Bluetooth is activated on the phone. The headset can be used

when it is“connected”to the phone. If the devices are paired, but

do not immediately connect, tap the answer/end button. When

your headset is connected the Bluetooth connection icon in the

StatusDisplay™ will be constant on for 3 seconds.

* Phone dependent

ENGLISH

JABRA BT2090

WEAR IT HOW YOU LIKE IT

The Jabra BT2090 can be worn on either ear with or without

earhook. Simply remove the earhook if you prefer this wearing

your preference.

HOW TO

Answer a call

- Tap (less than 1 sec) the answer/end button on your headset to

answer a call.

End a call

- Tap the answer/end button to end an active call.

Reject a call*

- Press (approx 1 sec) the answer/end button when the phone

rings to reject an incoming call. Depending on your phone

settings, the person who called you will either be forwarded to

your voice mail or will hear a busy signal.

Make a call

- When you make a call from your mobile phone, the call will

(subject to phone settings) automatically transfer to your

headset. If your phone does not allow this feature, tap on the

Jabra BT2090’s answer/end button to transfer the call to the

headset. Press answer/end button and volume up button at the

same time, you can transfer the call back to phone.

Activate voice dialling*

- Press the answer/end button. For best results, record the voice

dialling tag through your headset. Please consult your phone’s

user manual for more information about using this feature.

Redial last number*

- Double tap the answer/end button when the headset is

connected to your phone.

Adjust sound and volume*

- Tap the volume up or down to adjust the volume.

* Phone dependent

ENGLISH

JABRA BT2090

Mute/un-mute

- To mute, press both volume up and down at the same time.

A low beep alert plays during a muted call.

- To un-mute, tap either of the volume buttons.

Call waiting and placing a call on hold*

- This lets you put a call on hold during a conversation and

answer a waiting call.

- Press the answer/end button once to put the active call on hold

and answer the waiting call.

- Press the answer/end button to switch between the two calls.

- Tap the answer/end button to end the active conversation.

HOW THE STATUSDISPLAY™ WORKS

Bluetooth

Indicator

Indicates if your headset is connected to your

phone

- Solid light means headset is connected to your

phone

- Flashing light means headset is in ‘pairing

mode’and ready to be connected to a new

phone

Battery

Indicator

Indicates battery level and if headset is

turned ON

- Green light indicates that the headset has more

than 10 minutes of talk time remaining

- Red light indicates that the headset has less

than 10 minutes of talk time remaining

Get an instant status from the Jabra StatusDisplay™ by a tap on

any button on the headset when you are not on a call.

* Phone dependent

ENGLISH

JABRA BT2090

TROUBLESHOOTING & FAQ

I hear crackling noises

- Bluetooth is a radio technology, which means it is sensitive to

objects between the headset and the connected device. It is

designed for the headset and the connected device to be used

within 33 feet (10 meters) of each other, with no major objects

in the way (walls, etc.).

I cannot hear anything in my headset

- Increase the volume in the headset.

- Ensure that the headset is paired to the device that you wish to use.

- Make sure your phone is connected to the headset by tapping

the Answer/End button. See the Jabra StatusDisplay™.

I am having pairing problems

- You may have deleted your headset pairing connection in your

mobile phone.

Follow the pairing instructions.

I want to reset the headset

It is possible to reset and test the headset by ’Press and hold’the

volume down and answer/end buttons at the same time. In the

StatusDisplayTM the battery icon and B

simultaneously. In this mode, the pairing list is reset, and you can

test if the headset works as you will be able to hear audio in the

speaker from the microphone.

T. 10 seconds.

The next time you power on, the headset will go into pairing

BT2090 on.

Will the Jabra BT2090 work with other Bluetooth equipment?

- The Jabra BT2090 is designed to work with Bluetooth mobile

phones. It can also work with other Bluetooth devices that are

compliant with Bluetooth version 1.1 or higher and support a

I cannot use Reject call, call on hold, Redial or voice dialling

These features are dependent on the ability of your phone to

implemented reject call, call hold and voice dialling are optional

features which are not supported by all devices. Please consult

your device manual for details.

ENGLISH

JABRA BT2090

NEED MORE HELP?

1. Web: www.jabra.com

(for the latest support info and online User Manuals)

2. E-mail:

Deutsch suppor[email protected]om

English suppor[email protected]om

Español suppor[email protected]om

Français [email protected]

Italiano suppor[email protected]

Nederlands suppor[email protected]om

Polska suppor[email protected]

Scandinavian support.no@jabra.com

Россия [email protected]

Information: info@jabra.com

3. Phone:

Belgique/Belgie 00800 722 52272

Danmark 702 52272

Deutschland 0800 1826756

Die Schweiz 00800 722 52272

España 900 984572

France 0800 900325

Italia 800 786532

Luxembourg 00800 722 52272

Nederland 0800 0223039

Norge 800 61272

Österreich 00800 722 52272

Polska 0801 800 550

Portugal 00800 722 52272

Suomi 00800 722 52272

Sverige 020792522

United Kingdom 0800 0327026

Россия +7 495 660 71 51

International 00800 722 52272

Other manuals for BT2090

Table of contents

Other Jabra Headset manuals

Jabra

Jabra GN2100 User manual

Jabra

Jabra HALO2 User manual

Jabra

Jabra PRO 9450 Safety guide

Jabra

Jabra PRO 9465 User manual

Jabra

Jabra PRO 9460 Duo User manual

Jabra

Jabra Engage 75 Mono User manual

Jabra

Jabra CLIPPER Reference guide

Jabra

Jabra TALK 25 SE Specification sheet

Jabra

Jabra BT2040 - Headset - In-ear ear-bud User manual

Jabra

Jabra Talk 35 User manual

Jabra

Jabra GN9330 - Headset - Over-the-ear User manual

Jabra

Jabra JX20 - Pura - Headset User manual

Jabra

Jabra HALO2 User manual

Jabra

Jabra JX10 - MANUAL 2 User manual

Jabra

Jabra STEALTH Silver User manual

Jabra

Jabra BT135 - Headset - Over-the-ear Operating and maintenance instructions

Jabra

Jabra OTE17 User manual

Jabra

Jabra BIZ 2400 Series User manual

Jabra

Jabra GN9120 Flex User manual

Jabra

Jabra Engage 75 User manual

Jabra

Jabra Pro 930 Mono User manual

Jabra

Jabra TALK User manual

Jabra

Jabra GN9120 Flex User manual

Jabra

Jabra Pro 9450 Mono User manual

Popular Headset manuals by other brands

Sena

Sena SMH10 quick start guide

IASUS

IASUS Stealth IA-NT4-BASIC-BT manual

Sennheiser

Sennheiser EPOS ADAPT 230 user guide

Doro

Doro Flexus HS2005 user guide

GE 98971 datasheet

Hama

Hama 00184070 quick start guide

Plantronics

Plantronics Blackwire 3200 Series user guide

Blue Tiger

Blue Tiger Advantage PLUS user manual

Jawbone

Jawbone Icon user manual

Roxcore

Roxcore Flow A+ manual

Turtle Beach

Turtle Beach XP 510 user guide

Philips

Philips SHB6101 Specification sheet

HyperX

HyperX HyperX Cloud Flight manual

Bose

Bose MIE2 Mobile owner's guide

HyperX

HyperX cloud ii quick start guide

Southwing

Southwing SA505 Specifications

Plantronics

Plantronics VOYAGER 520 user guide

Blueant

Blueant X5i user manual
