IOGear GWU735 User manual
1
Quick Start Guide
Wireless AC1200 Dual-Band
USB Adapter
GWU735
PART NO. Q1262
www.iogear.com
© 2014 IOGEAR®Part No. Q1262
IOGEAR, the IOGEAR logo, are trademarks or registered trademarks of IOGEAR. Microsoft and
Windows are registered trademarks of Microsoft Corporation. All other brand and product names are
trademarks or registered trademarks of their respective holders. IOGEAR makes no warranty of any
kind with regards to the information presented in this document. All information furnished here is for
informational purposes only and is subject to change without notice. IOGEAR assumes no responsi-
bility for any inaccuracies or errors that may appear in this document.
3
Table of Content
Table of Contents 3
Package Contents 4
System Requirements 4
Overview 5
Software Installation – PC 6
:LUHOHVV1HWZRUN&RQ¿JXUDWLRQ±3& 7
Software Installation – MAC 16
:LUHOHVV1HWZRUN&RQ¿JXUDWLRQ±0$& 11
FCC Statement 27
CE Statement 27
Limited Warranty 28
Contact 28
4
1 x Wireless AC1200 Dual-Band USB Adapter
1 x Quick Start Guide
1 x Driver Installation CD
1 x Warranty Card
Operating System
:LQGRZV9LVWD®, Windows®7, Windows®8, Windows®8.1
0DF26;RUDERYH
Available USB 1.1, USB 2.0, or USB 3.0 port*
*Note: For best results, connect the wireless AC1200 Dual-Band USB
adapter to a USB 3.0 port.
Package Contents
System Requirements
5
Overview
1. WPS Button
2. LED Status Indicator
DÀDVKVHF±:LUHOHVV/$1$GDSWHULVDFWLYH
EÀDVKHVVHF±$GDSWHULVFRQQHFWLQJWRDQ$FFHVV3RLQW
c. Off – Wireless LAN adapter is disabled
3. USB Connector
4. Cap
3
2
4
1
6
1. Insert the driver installation
CD into your CD-ROM Drive.
Double-click on Setup.exe
to start the installation.
2. Wizard is ready to
install driver and
utility. Click Next to
begin installation.
3. Click Finish to restart
your computer for the
installation to be
in effect.
Software Installation – PC
77
Insert the USB Adapter
1. After the computer has restarted, insert the GWU735 Wireless
AC1200 Dual-Band USB Adapter into an available USB port.*
*Note: For optimal performance, connect to a USB 3.0 port.
$QHZLFRQZLOODSSHDULQ\RXUV\VWHPWUD\RQFHWKHFRPSXWHU¿QLVKHV
the driver installation.
&OLHQWPRGHXWLOLW\UXQQLQJEXW*:8LVQRWSOXJJHGLQWR
computer.
&OLHQWPRGHXWLOLW\UXQQLQJ*:8LVSOXJJHGLQDQGFDQQRZ
scan for an available Access Point (AP).
&OLHQWPRGHXWLOLW\UXQQLQJ*:8LVQRZFRQQHFWHGWR\RXU
wireless AP.
:LUHOHVV1HWZRUN&RQ¿JXUDWLRQ±3&
8
Connect to a
Wireless Network
1. Double-click the
wireless utility
icon on your
desktop to open the
IOGEAR USB
Wireless LAN Utility.
2. Select the Available
Network tab and
wait for the utility to
search for available
wireless networks.
The available
networks will be
listed in the table.
Select the desired
network and click
$GGWR3UR¿OH.
9
3. Next, the Wireless
Network Properties
window will appear.
Enter the network key,
then click OK to continue.
4. Once connected, the utility will display the Signal Strength and
Link Quality.
10
5. To set the currently connected network as your default, select the
SUR¿OHWDEDQGFOLFN“Set Default”.
Wi-Fi Protected SetupTM
Wi-Fi Protected Setup (WPS) is a simple and secure way to connect to
an existing network. Before you start, make sure your wireless router
$FFHVV3RLQW$3VXSSRUWV:367KLVRSWLRQDOFHUWL¿FDWLRQIHDWXUH
provides two connection methods: 3,1,QSXW&RQ¿JXUDWLRQ3,1 or
3XVK%XWWRQ&RQ¿JXUDWLRQ3%&.
Option 1: 3,1,QSXW&RQ¿JXUDWLRQ3,1PHWKRG
1. 2SHQWKH&RQ¿JXUDWLRQ
program for your wireless
URXWHU$FFHVV3RLQWDQGVHOHFW
the WPS Client set-up option.
2. Next, select the Wi-Fi
Protect Setup tab in the
IOGEAR USB Wireless LAN
Utility, click the Pin Input
&RQ¿J3,1 button.
