Intermec PM4I User manual

Page 1 4/13/2012

[RFID Movement]

[User Manual for Printing Labels]

[1.3]

[RFID Movement]

Page 2 4/13/2012

Table of Contents

Safety Summary................................ 3

Introduction....................................... 4

Media Load –Peel Off ..................... 5

Program Usage.................................. 8

Glossary .......................................... 13

Works Cited .................................... 14

Page 3 4/13/2012

Safety Summary

Intermec assumes no responsibility regarding the CE Directive if

the printer is handled, modified, or installed in any way other than

that described in Intermec’s manuals.

• Read this manual carefully before connecting the printer.

• Moving parts are exposed when the side doors are open, so

ensure that the doors are closed before you operate the printer.

• Do not open the front/left-hand cover. Dangerous voltage!

• Do not remove the bottom plate. Dangerous voltage!

• Do not put your fingers inside the print mechanism when the

power is on.

• Make sure that the side door cannot unintentionally swing down

when you have your fingers or hands inside the media

compartment. Risk of injury because of the weight of the side

door!

• Place the printer on an even surface which can support its weight

of approximately 13.5 kg (30 pounds) plus supplies.

• Do not spray the printer with water. If you are using a hose to

clean the premises in an industrial environment, remove the printer

or protect it carefully from spray and moisture.

• Carefully read the warning text on the envelope before using a

cleaning.

(Intermec)

Page 4 4/13/2012

Introduction

The following is a user’s manual for the purpose of printing

RFID labels with an Intermec PM4I label printer using Seagull

Scientific Bartender Software.

Page 5 4/13/2012

Media Load –Peel Off

The EasyCoder PM4i can print on labels, tickets, tags, and

continuous stock in various forms. This section describes the case

when self-adhesive labels are separated from the liner immediately

after printing, which requires optional integral self-strip unit with

liner take-up. This is also known as “Self-strip” operation.

Peel-off operation cannot be performed when an optional fan-fold

guide fitted. Peel-off can only be used for:

• Self-adhesive labels with liner, an optional label-taken sensor can

hold the printing of the next label in a batch until the present label

has been removed.

Note: Save the label indicating the sensitivity number attached to

the media roll. You will need this number to set the media

sensitivity.

Note: Peel-off operation sets high demands on the media in regard

of label stiffness, release characteristics of the adhesive and liner,

resistance against electrostatic charging etc., so the labels will be

dispensed properly. Consult your media supplier or test the media

to ascertain that it is suitable for your application.

(Intermec)

Page 6 4/13/2012

Figure 1: Loading Tags Started

Figure 2: Loading Tags Continued

Page 7 4/13/2012

Figure 3: Finishing Loading Tags

(Intermec)

Page 8 4/13/2012

Program Usage

Step 1

Find the program icon (Bartender) on the desktop and double

click it to open up the printing software.

Figure 4: Program Icon

Page 9 4/13/2012

Step 2

The user is presented with a blank label format which they

have set up in advance; you must then click the print button in

the toolbar

Figure 5: Opening the Program

Page 10 4/13/2012

Step 3

When you select the print button, you will be prompted for the

product code of Field Aviation for part numbers which must

be input in the database prior to use.

Figure 6: Inputting Product Numbers
