Interlogix TruVision DVR 42 User manual

TruVision DVR 42 User

Manual

P/N 1072662A-EN • REV 0.4 • ISS 16OCT13

2013 United Technologies Corporation.

Interlogix is part of UTC Climate Controls & Security, a unit of United

Trademarks and

paten

rade names used in this document may be trademarks or registered

trademarks of the manufacturers or vendors of the respective products.

Manufacturer

United Technologies Corpor

ation.

2955 Red Hill Avenue, Costa Mesa, CA 92626

-5923, USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, The Netherlands

Certification

N4131

FCC com

pliance

Class A:

This equipment has been tested and found to comply with the limits for

a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference when

the equipm

ent is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation

of this equipment in a

residential area is likely to cause harmful interference in which case the user will

be required to correct the interference at his own expense.

ACMA compliance

Noti

ce! This is a Class A product. In a domestic environment this product may

cause radio interference in which case the user may be required to take

adequate measures.

European Union

directives

12004/108/EC (EMC directive):

Hereby, UTC Fire & Security declares that this

device is in compliance

or with the essential requirements and other relevant

provisions of Directive 2004/108/EC

2002/96/EC (WEEE directive):

Products marked with this symbol cannot be

disposed of as unsorted municipal waste in the Euro

pean Union. For proper

recycling, return this product to your local supplier upon the purchase of

equivalent new equipment, or dispose of it at designated collection points. For

more information see: www.recyclethis.info.

2006/66/EC (battery directive)

: This product contains a battery that cannot be

disposed of as unsorted municipal waste in the European Union. See the

product documentation for specific battery information. The battery is marked

with this symbol, which may include lettering to indicate

cadmium (Cd), lead

(Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or

to a designated collection point. For more information see: www.recyclethis.info.

Contact information

For contact information

, see www.utcfireandsecurity.com or

www.utcfssecurityproducts.eu

TruVision DVR 42 User Manual i

Content

Chapter 1 Product introduction 1

Product overview 1

Default settings to access the device 2

Chapter 2 Installation 3

Installation environment 3

Unpacking the TVR 42 and its accessories 3

Back panel 4

RS-485 ports 6

RS-232 port 6

Monitor connections 6

Loop through 6

Audio inputs and output 7

Brackets 7

PTZ dome camera set up 8

Wiring the KTD-405 keypad 12

Chapter 3 Getting started 15

Turning on and off the DVR 15

Using the setup wizard 16

Chapter 4 Operating instructions 19

Controlling the TVR 42 19

Using the front panel 19

Using the mouse 21

Using the IR remote control 22

Menu overview 25

Chapter 5 Live view 29

Description of live view 29

Video output 30

Audio output 30

Controlling live view 30

Multiview format 32

Sequencing cameras33

Accessing frequently used commands 34

Configuring live view 35

Configuring time and date 38

General settings 39

V-stream encoding 42

Chapter 6 Controlling a PTZ camera 43

Configuring PTZ settings 43

Calling up presets, tours and shadow tours 44

ii TruVision DVR 42 User Manual

Setting and calling up presets 45

Setting and calling up preset tours 47

Setting and calling up a shadow tour 48

Chapter 7 Playing back a recording 51

Overview of the playback window 51

Playback pop-up menu 54

Instant playback 54

Previous-day playback 55

Searching recorded video 56

Playing back recordings by time and video type 57

Playing back recordings by event 58

Creating and playing back bookmarked recordings 59

Slideshow of snapshots 60

Playing back recordings from the system log 61

Playback skip time 62

Motion search 62

Playing back frame-by-frame 63

Digital zoom in playback 63

Chapter 8 Archiving recorded files 65

Archiving files 65

Auto archiving 68

Creating and archiving video clips 69

Archiving snapshots 70

Managing backup devices 70

Playing back archived files on a PC 70

Chapter 9 Using the web browser 71

Windows Vista and 7 users 71

Accessing the web browser 72

Web browser overview 72

Using the web browser to configure the device 74

Searching and playing back recorded video 78

Searching for event logs 80

Dual streaming 81

Controlling a PTZ dome camera in the web browser 82

Capturing text insertions 83

Text overlay 85

Using a network storage system 86

Chapter 10 Recording 87

Initializing recording settings 87

Defining a recording schedule 90

Daily schedules 91

Holiday schedules 92

Manual recording 93

Motion detection schedules 94

TruVision DVR 42 User Manual iii

External alarm schedules 94

Protecting recorded files 94

HDD redundancy 96

Chapter 11 Alarm settings 99

Description of alarm notification types 99

Setting up motion detection 102

Setting up external alarms 105

Triggering or clearing alarm outputs manually 107

Setting up system notifications 107

Detecting video loss 108

Detecting video tampering 109

Chapter 12 Network settings 111

Configuring general network settings 111

Configuring PPPoE 112

Configuring DDNS 113

Configuring an NTP server 114

Configuring e-mail 114

Configuring UPnPTM 115

Configuring SNMP 117

Configuring an FTP server to store snapshots 117

Configuring a remote alarm host 117

Configuring multicast 118

Configuring the server and HTTP ports 118

Configuring the RTSP service port 118

Checking network status 119

Exporting network packet data 120

Bandwidth throttle management 120

Chapter 13 HDD management 123

Initializing HDDs 123

Controlling disk space on the HDD 123

Setting up HDD groups 124

Recording dual streaming 125

Setting the HDD property 125

Checking HDD status 126

Configuring HDD alarms 126

Managing eSATA 127

Checking the S.M.A.R.T. information 127

Searching video using disk analysis 128

Chapter 14 Camera settings 131

Configuring the camera OSD settings 131

Setting up privacy masking 132

Adjusting camera image settings 133

Hiding a camera image from view 134

iv TruVision DVR 42 User Manual

Chapter 15 DVR management 135

Configuring the RS-232 port 135

Updating system firmware 136

Restoring default settings 137

Viewing system information 138

Searching system logs for events 140

Importing and exporting configuration settings 141

Chapter 16 User management 143

Adding a new user 143

Customizing a user’s access privileges 144

Deleting a user 146

Modifying a user 146

Changing the Admin password 146

Appendix A Specifications 147

Appendix B PTZ protocols 149

Appendix C Port forwarding information 151

Appendix D KTD-405 keypad 153

Supported firmware 153

Wiring the keypad 153

Setting up the keypad to work with the TVR 42 154

Operating the keypad 156

Appendix E Maximum pre-recording times 161

Appendix F Supported PTZ commands 163

Appendix G Default menu settings 165

Index 175

TruVision DVR 42 User Manual 1

Chapter 1

Product introduction

Product overview

This is the TruVision DVR 42 (TVR 42) User Manual for models:

Table 1: Product codes

Americas

EMEA

TVR

-4208-2T TVR-4204-1TEA

TVR

-4208-4T TVR-4204-2TEA

TVR

-4216-2T TVR-4208-2TEA

TVR

-4216-4T TVR-4208-4TEA

TVR

-4216-8T TVR-4216-2TEA

TVR

-4216-12T TVR-4216-4TEA

TVR-4216-8TEA

TVR-4216-12TEA

Note: Models are shipped with the power chords for their region.

For regions not listed in Table 1 above, please contact your local supplier.

The TruVision™ DVR 42 (TVR 42) is a versatile, user-friendly embedded digital

video recorder (DVR) allowing end-users to record 4, 8, or 16 analog cameras at

960h in real time (25/30 fps), while providing integration with the UTC portfolio of

security solutions, and offering a seamless product experience within the

TruVision brand.

Its dual streaming functionality allows the user to set up different settings for

recording and streaming video in live view mode.

TruVision DVR 42 can fully integrate with the license-free TruVision Navigator

software, which is ideal for the most commercial applications. TVR 42’s easy and

intuitive-to-use web browser interface enables remote configuration and secure

viewing, searching, and playing back of video from computers connected via the

Internet.

0BChapter 1: Product introduction

2 TruVision DVR 42 User Manual

Default settings to access the device

Default user names and passwords

See Table 2 below for the list of default user names and passwords. Go to

Chapter 16 “User management” on page 143 for further information.

Table 2: Default user names and passwords

User

Description

Administrator

There can only be one administrator.

The user name is admin. The name cannot be modified.

The default password is 1234.

Operator

The default user name is “operator”.

The default password is 2222.

Guest

The default user name is “guest”.

The default password is 3333.

Note: The default passwords should be changed for security reasons.

Default network settings

The default values for TVR 42 network settings are:

• IP address - 192.168.1.82

• Subnet mask - 255.255.255.0

• Gateway address - 192.168.1.1

• Ports:

When using the browser:

RTSP port: 554

HTTP port: 80

When using TruNav:

RTSP port: 554

Server/Client software port: 8000

Go to Chapter 9 “Using the web browser” on page 71 for further information.

TruVision DVR 42 User Manual 3

Chapter 2

Installation

This section describes how to install the TVR 42 unit.

Installation environment

When installing your product, consider these factors:

• Ventilation

• Temperature

• Moisture

• Chassis load

Ventilation: Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions. Ensure that the location planned for the installation

of the unit is well ventilated.

Temperature: Consider the unit’s operating temperature (-10 to +55 ºC, 14 to

131 °F) and noncondensing humidity specifications (10 to 90%) before choosing

an installation location. Extremes of heat or cold beyond the specified operating

temperature limits may reduce the life expectancy of the DVR. Do not install the

unit on top of other hot equipment. Leave 44 mm (1.75 in.) of space between

rack-mounted TruVision DVR 42 units.

Moisture: Do not use the unit near water. Moisture can damage the internal

components. To reduce the risk of fire or electric shock, do not expose this unit to

rain or moisture.

Chassis: Equipment weighing less than 15.9 kg (35 lb.) may be placed on top of

the unit.

Unpacking the TVR 42 and its accessories

When you receive the product, check the package and contents for damage, and

verify that all items are included. There is an item list included in the package. If

any of the items are damaged or missing, please contact your local supplier.

1BChapter 2: Installation

4 TruVision DVR 42 User Manual

Items shipped with the product include:

• IR (infrared) remote control

• Two AAA batteries for the remote control

• AC power cords (US, Europe, UK)

• USB mouse

• DVR

• Video loop through cable

• CD with software and manuals

• TruVision DVR 42 Quick Start Guide

• TruVision DVR 42 User Manual (on CD)

Back panel

Figure 1 on page 5 shows the back panel connections and describes each

connector on a typical TVR 42 digital video recorder. Details may vary for specific

models.

Before powering up the DVR, connect the cameras and a main monitor for basic

operation.

Other manuals for TruVision DVR 42

Table of contents

Other Interlogix DVR manuals

Interlogix

Interlogix TruVision DVR 12HD User manual

Interlogix

Interlogix truVision DVR 31 User manual

Interlogix

Interlogix TruVision DVR 44HD User manual

Interlogix

Interlogix truVision 11c Series User manual

Interlogix

Interlogix TruVision DVR 12HD User manual

Interlogix

Interlogix TruVision DVR 40 User manual

Interlogix

Interlogix TruVision DVR 60 User manual

Interlogix

Interlogix TruVision TVR-1108-1T User manual

Interlogix

Interlogix TruVision DVR 20 User manual

Interlogix

Interlogix TruVision TVR 1516DHD User manual

Interlogix

Interlogix TruVision DVR 15HD User manual

Interlogix

Interlogix TruVision NVR 21 User manual

Interlogix

Interlogix TruVision DVR 45HD User manual

Interlogix

Interlogix TruVision DVR 44HD User manual

Interlogix

Interlogix TruVision DVR 30 User manual

Interlogix

Interlogix TruVision DVR 41 User manual

Interlogix

Interlogix truVision DVR 31 User manual

Interlogix

Interlogix TruVision NVR 21 User manual

Interlogix

Interlogix TruVision TVR-1116D-2T User manual

Interlogix

Interlogix TruVision DVR 12 User manual

Interlogix

Interlogix TruVision DVR 11 User manual

Interlogix

Interlogix TVR 12HD User manual

Interlogix

Interlogix TruVision 70 User manual

Interlogix

Interlogix TVR 60 series User manual

Popular DVR manuals by other brands

FLIR

FLIR M3100E Series instruction manual

VTRACKPRO

VTRACKPRO FPRO300 user manual

Swann

Swann NVR-7085 models instruction manual

XtendLan

XtendLan DVR-1670C user manual

urmet domus

urmet domus 1093/004AHD instructions

Holux

Holux M1 user manual

CMOS DOTCOM

CMOS DOTCOM ANX-1670 manual

Whistler

Whistler D16VRS user guide

Defender Security

Defender Security 82-20235 user manual

MISUMI

MISUMI MP-WF100M user guide

Speco

Speco D8HU user guide

UST

UST DDR-E04AA Hardware user manual

Consolidated

Consolidated Digital Video Recorder user manual

Mace

Mace DVR0404RW Operational manual

RCA

RCA RTD315W user manual

FSM

FSM Colibri Grande PRO user manual

Hauppauge

Hauppauge HD PVR 2 Quick install guide

Identivision

Identivision ICR-PH161i PIONEER user manual
