Infinity Total Solutions TSS-Center1100 User manual
TSS-CENTER1100
Owner’s Guide
TOTAL SPEAKER SOLUTIONS
TSS-4000
Center 1100 OM 5/4/05 2:23 PM Page 1
INTRODUCTION
InfinityTotal Solutions™
Infinity Total Solutions TSS-CENTER1100 center channel
loudspeaker is designed to perfectly complementTotal Solutions
speakers. It provides exceptional dialogue reproduction and a
seamless transition between the front channels.The horizontal
design allows for maximum placement flexibility.
AboutThis Guide
Please read this guide completely before connecting and
operating theTSS-CENTER1100 center channel speaker.
Maximum performance is dependent upon following these
instructions, as well as those in the owner’s manuals of
associated components in your home theater system. Save
these instructions for future reference.
Unpacking the Speaker
Finish unpacking the speaker and check the contents. If you
suspect damage from transit, report it immediately to your
dealer. Keep the shipping carton and packing materials for
future use.
Contents
Please verify that the package contains the following items:
PLANNING YOUR SYSTEM
Before deciding where to best place your speakers, survey your
room and study Figures 1 and 2.
Figure 1. In this overhead view of a typical installation, satellite
speakers are used to reproduce sound for the front and surround
channels.The center channel reproduces sound and dialogue.
The powered subwoofer provides bass for effects and music.
Placement
Figure 2.This example shows the TSS-CENTER1100 being placed
on top of a television.The speaker can also be placed below the
television and tilted up (see Figure 3).
Couch
Left
Front
Channel
Left
Surround
Channel
Right
Surround
Channel
Right
Front
Channel
Center
Channel
(above or below TV) Subwoofer
(1) TSS-CENTER1100 center channel speaker
(1) Speaker base
Center 1100 OM 5/4/05 2:23 PM Page 2
Tilting the Speaker
If needed, the enclosed stand allows you to tilt the speaker
across a wide range (i.e., up a maximum of 18˚ or down a
maximum of 7˚), as shown in Figure 3.
Important!
Do not exceed the tilt range. Doing so may cause the speaker to
fall out of its stand.
Figure 3.
WIRING THE SPEAKER
After placing the speaker, you are ready to connect it to your
system. First, turn off all audio system power. Use high-quality
speaker wire to make the connections. Consult the owner’s
manuals included with your amplifier or receiver for connection
and operation procedures.
Surround Modes
When using theTSS-CENTER1100 in a Dolby* Digital or DTS®
home theater system, make sure the amplifier or receiver
center channel speaker modes are set to“Small.”
Wiring and Polarity
The TSS-CENTER1100 speaker has gold-plated terminals that
can accept bare wire.To ensure proper polarity, connect each
+terminal on the back of the amplifier or receiver to the
respective + (red) terminal on each speaker, as shown in
Figure 4. Connect the – (black) terminals in a similar way.
See the owner’s manuals that were included with your
amplifier or receiver to confirm connection procedures.
Important!
Do not reverse polarities (i.e., + to – or – to +) when making
connections. Doing so will degrade the imaging and bass
response of the home theater system.
After correctly placing and wiring theTSS-CENTER1100 and
the rest of your speaker system, adjust the levels for all of the
channels as recommended by the manufacturer of your amplifier
or receiver.
Figure 4.This example shows how to connect bare wires to the
terminals. Banana plugs may also be inserted directly into the
rear of the connector.
1Loosen the terminals.
2Insert bare ends; tighten terminals.
– +
1
2
Center 1100 OM 5/4/05 2:23 PM Page 3
©2005 Harman International Industries, Incorporated.All rights reserved.
Infinity Systems,250 Crossways Park Drive,Woodbury, NY 11797 USA
516.674.4INF (USA only) www.infinitysystems.com
*Trademark of Dolby Laboratories.DTS is a registered trademark of Digital Theater Systems, Inc.
Infinity and MMD are registered trademarks, and Total Solutions is a trademark, of
Harman International Industries, Incorporated.
Part No. 400-OMCNTR 5/05
CARE OF YOUR SPEAKER SYSTEM
When needed, use a soft cloth to remove any fingerprints or
towipe off dust. Do not use any cleaning products or polish.
Clean the grille by gently vacuuming.
SPECIFICATIONS
TSS-CENTER1100
Frequency Response 120Hz – 20kHz (±3dB)
Nominal Impedance 8ohms
Sensitivity 89dB
(2.83V @ 1m)
Recommended Amplifier 10 – 125 watts
Power Range
Crossover Frequencies 3,500Hz; 24dB/octave
Low-FrequencyDrivers (2) 3-1/2" (89mm) MMD®
,
magnetically shielded
High-FrequencyDriver 3/4" (19mm) MMD,
elliptical waveguide,
magnetically shielded
Dimensions (H x WxD) 4-1/8" x 9-1/4" x 4-3/8"
(105mm x 235mm x 111mm)
Weight 4.5 lb (2.0kg)
Infinity continually strives to update and improve existing products, as well as create new ones.
The specifications and construction details in this and related Infinity publications are therefore
subject to change without notice.
Declaration of Conformity
We, Harman Consumer Group International
2, route de Tours
72500 Chateau-du-Loir
France
declare in own responsibility that the product
described in this owner’s manual is in compliance
with technical standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Laurent Rault
Harman Consumer Group International
Chateau-du-Loir, France 5/05
