Infinity INTERLUDE IL40 User manual

Technical Manual

Interlude IL40

Infinity Systems, Inc. 250 Crossways Park Dr., Woodbury, New York 11797 Rev1 04/03

NETWORK, IL40

336241-001

+IN

-IN

GRN

GRN/BLK

2.5mH

120 F

3.3 ohm C4

6.8 F

60.0 F

0.07mH

YEL

YEL/BLK

335225-003

L.F.

H.F.

00195

IL40 SCHEMATIC

100V

20W 100V

100V

TRANSDUCER

HIGH FREQUENCY

.250

.187

.110

GRN

GRN/BLK

MIDRANGE FREQUENCY

335812-002

TRANSDUCER

.205

1.65mH

4.2 ohm

20W

2.70mH

0.45mH

14.0 F

100V

-IN

+IN

WHT/BLK

WHT

.205

.250

M.F.

TRANSDUCER

335804-001

LOW FREQUENCY

WHT/BLK

WHT

YEL/BLK

YEL

ACOUSTIC & ELECTRICAL SPECIFICATIONS:

lNominal Impedance: 89

lMax Amp Power 75 watts*

lFrequency Response 38 Hz - 22,000Hz (E3dB)

lSensitivity: 89dB (2.83V @ meter)

lCrossover Frequency: 600, 2500Hz 24dB/octave

SYSTEM COMPONENTS:

lCabinet IL40 (Not for Sale)

lGrille, (Platinum) 336057-001

lLow-Frequency Transducer: 8” (203mm) C.M.M.D.,

shielded (335804-00 )

DC Resistance 4.6 ohms E0%

lMidrange-Frequency Transducer: 4.5” ( 4mm) C.M.M.D.,

shielded (3358 2-002)

DC Resistance 4.6 ohms E0%

lHigh-Frequency Transducer: ” (25mm) C.M.M.D.,

shielded (335225-003)

DC Resistance 3.5 ohms E0%

lCrossover Network 33624 -00

AURAL SWEEP TEST SPECIFICATIONS:

lSystem Aural Sweep Test 6.0V Input 30 Hz to 22 kHz

lL.F. Aural Sweep Test 6.0V Input 30 Hz to kHz

lM.F. Aural Sweep Test 3.0V Input 500 Hz to 3 kHz

lH.F. Aural Sweep Test 3.0V Input 2 kHz to 22 kHz

PHYSICAL SPECIFICATIONS:

lEnclosure dimensions: 40” x 0” x - /2”

( 0 .6cm x 25.4cm x 29.2cm)

lWeight 4 lbs ( 8.6 kg) Each

WARRANTY:

lRefer to Warranty Statement packed with each product.

* The maximum recommended amplifier power rating will

ensure proper system headroom to allow for occasional peaks.

We do not recommend sustained operation at these maximum

power levels.

PACKING WIRING DIAGRAM

INTERLUDE IL40

Technical Manual

Interlude IL40

Infinity Systems, Inc. 250 Crossways Park Dr., Woodbury, New York 11797 Rev1 04/03

EXPLODED VIEW

ROTATED

00193

CABNET IL40

(NOT FOR SALE)

CUP, ISOLATION

335809-001

SCREW, (4)

#6-19X.375 BLK

905401-006

SCREW, (8)

#8-X.75 BLK

900101-012

SCREW, (4)

PB,PPH, #6X.75 BLK

903401-012

SCREW, (8)

PB,PPH, #6X.75 BLK

903401-012

MID-RANGE

335812-002

SCREW, (8)

PB,PPH, #6X.75 BLK

903401-012

TWEETER

335225-003

WOOFER

335804-001

GRILLE CUP (8)

333249-003

SCREW, (4)

NETWORK ASSY

336241-001

BUMP-ON (4)

330104-001 PEDESTAL

335780-001

PORT TUBE

336055-001

TO SERVICE THE INTERLUDE IL40

1) Remove the grille.

2) Extract all (8) rubber grille retainers; this can be accomplished by carefully pulling them out

of their cavities with long-nosed pliers or similar tool.

3) Remove the (8) Phillip screws that are now exposed.

4) Carefully lift the front baffle, with tweeter attached, off the cabinet.

5) If necessary, remove the (8) Phillips screws holding the woofer to the cabinet.

SHORTING STRAPS (2)

073-110002-000

FRONT BAFFLE

336028-001

#8-X.75 BLK

900101-012

GRILLE, WARM GRAY, 336057-001

GRILLE, MIDNIGHT BLUE, 336057-002

GRILLE, RICH BURGUNDY, 336057-003

INTERLUDE IL40

GRILLE, BLACK, 336057-004
