Hunter 42122 User manual

Owner’s Manual

Models

42122

42123

42177

Form# 44047-01

20120618

©2012 Hunter Fan Co.

English

Non Programmable

INSTALLATION

5 MINUTE

44047-01 • 06/18/2012

2

At A Glance

Know Your ermostat � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3

Setup

Setting Temperature ��10

Features

Alerts ��12

Menu Options ��16

Additional Features ��20

ermostat Assistance

Troubleshooting and Support� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �21

Technical Support��23

Warranty

1 Year Limited Warranty � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �24

Table of Contents

©2012 Hunter Fan Company 3

If you need any assistance with installion or setup of your new

Hunter Thermostat, please call us, our technical support staff is

ready to help!

USA: 1-888-830-1326

Canada: 1-866-268-1936

Hours of operation are from 7:00 am to 7:00 pm Monday - Friday and 8:00 am

to 5:00 pm on Saturday, Central Time. You may also contact us over the Internet at:

www.HunterFan.com

Read this manual thoroughly. The following notes should help you with getting

around your thermostat:

• The thermostat temperature can be set in increments of 1°F (1°C).

• After 15 minutes without a key press, the thermostat will return to the home

display screen and save any changes you have made.

Know Your ermostat

44047-01 • 06/18/2012

4

1. Allows access to the advanced features of the thermostat and saves changes

to the menu options.

2. Adjusts time and temperature settings as well as moving up or down

menu lists.

3. Indicates whether the system is set to Heat, Cool, or Off.

4. Indicates if the fan is set to Auto or On modes.

5. Allows you to switch between Heat, Cool, and Off modes.

6. Allows you to switch between fan Auto and On modes.

Know Your ermostat

©2012 Hunter Fan Company 5

1

2

4

3

65

Know Your ermostat

44047-01 • 06/18/2012

6

1. Holds 2 “AA” Batteries.

2. HE/HG Switch - allows you to set your furnace to Gas/Oil or Electric, based

on the type of system you have.

3. Allows your thermostat to operate your HVAC system* properly by indicating

the system type that you have.

*Conventional System: Uses a condensing unit for cooling and a

separate furnace system for heating.

*Heat Pump System: Uses the condensing unit for both heating

and cooling.

NOTE: If you are unsure of your system type it may be necessary

to contact our technical support department at 1-888-830-1326, your

HVAC manufacturer, or a local HVAC technician to determine this.

Improper selection of your system type could cause the thermostat to

not operate your system properly.

Know Your ermostat

©2012 Hunter Fan Company 7

1

3

2

Know Your ermostat

44047-01 • 06/18/2012

8

1. Indicates the current room temperature.

2. C will display when in Celsius mode. Nothing will display when set

to Fahrenheit.

3. Low battery warning, replace the batteries in the thermostat.

4. Will show when your heat pump or system is reporting a problem

to the thermostat.

5. Flashes when the furnace lter should be checked for replacement.

6. Indicates auxiliary heat on a heat pump is running.

7. Current operating mode, heat or cool.

8. Current Set temperature the thermostat is scheduled to run.

9. Indicates the fan is running when displayed.

10. Shows the current mode of the fan, Auto or On.

Know Your ermostat

©2012 Hunter Fan Company 9

o

Auto

Filter

o

Heat

Cool to

C

Aux

Sys.

2

3

4

5

78

9

10

1

6

Know Your ermostat

44047-01 • 06/18/2012

10

Once you install the batteries, the thermostat will display the home screen.

1. Set the system switch to Heat or Cool depending on your season.

2. Use the or button to activate the thermostat.

3. Press the or buttons again to adjust your set temperature.

4. Press when nished. The thermostat will show “Updated!” to

conrm your settings are saved.

NOTE: Follow this process anytime you need to make a change to

your temperature.

Setting Temperature
