Quidway® AR 28 Router T1 Interface Module

Quidway® AR 28 Router T1 Interface Module

Overview

AR28 router supports three channelized CT1/PRI modules, 1T1, 2T1 and 4T1, and three

non-channelized T1 modules, 1T1-F, 2T1-F and 4T1-F.

1T1/2T1/4T1 is the abbreviation of 1-/2-/4-port channelized CT1/PRI interface module. The major

function of T1 module is to transmit T1 data flow and provide the CT1 access. It can realize the

ISDN RPI function and the purpose of one board multi-use.

1T1-F/2T1-F/4T1-F is the abbreviation of 1-/2-/4-port non-channelized T1 module. Where, F

indicates fractional T1. The main differences between the 1CT1/2CT1/4CT1 and

1T1-F/2T1-F/4T1-F are:

The FT1 working mode supported by T1-F module can be bound once (bound as a channel;

the rate is n × 64 K or 56 K, n=1-24). The CT1 module can group the 24 channels randomly to

realize binding for many times.

z

zThe T1-F module does not support the PRI mode.

Specifications

The specifications of T1 interface module ofAR28 router are shown in the following table.

Product Number Interface

Type Description

RT-1T1-V2 RJ48 1-port CT1/PRI interface module(V2)

RT-2T1-V2 RJ48 2-port CT1/PRI interface module(V2)

RT-4T1-V2 RJ48 4-port CT1/PRI interface module(V2)

RT-1T1-F-V2 RJ48 1-port non-channelized T1 interface module(V2)

Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved. 1

http://datacomm.huawei.com

Quidway® AR 28 Router T1 Interface Module

Interface

Product Number Description

Type

RT-2T1-F-V2 RJ48 2-port non-channelized T1 interface module(V2)

RT-4T1-F-V2 RJ48 4-port non-channelized T1 interface module(V2)

Interface property

The interface properties of 1T1/2T1/4T1 and 1T1-F/2T1-F/4T1-F modules are shown in the

following:

Attribute Description

Connector type RJ48

Connector quantity 1(1T1/1T1-F module)

2(2T1/2T1-F module)

4(4T1/4T1-F module)

Interface standard

G.703/T1 102

G.704

AT&T TR 54016

AT&T TR 62411

ANSI T1.403

Interface rate 1.544 Mbps

Cable type T1 cable(100Ωshielded network cable)

Working mode CT1、ISDN PRI(1T1/2T1/4T1 module)

FT1(1T1-F/2T1-F/4T1-F module)

Protocol IP

Novell IPX

Service supported Backup

Terminal access service

ISDN PRI(1T1/2T1/4T1 module)

Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved. 2
