Huawei E1762 Installation guide

All rightsreserved

Nopartofthis documentmaybereproduced ortransmitted inanyformorbyanymeans

withoutpriorwritten consentofHuaweiTechnologies Co.,Ltd.

The productdescribedinthis manualmayincludecopyrighted softwareofHuawei

Technologies Co.,Ltdand possiblelicensors.Customers shall not inanymannerreproduce,

distribute,modify,decompile,disassemble,decrypt,extract,reverseengineer,lease,assign,

orsublicensethe said software,unless suchrestrictions areprohibited byapplicablelaws or

suchactions areapproved byrespectivecopyrightholders underlicenses.

TrademarksandPermissions

,HUAWEI, and aretrademarks orregistered trademarks ofHuawei

Technologies Co.,Ltd.

Othertrademarks,product,serviceand companynames mentionedarethepropertyoftheir

respectiveowners.

Notice

Somefeaturesofthe productand its accessories describedhereinrelyonthesoftware

installed,capacitiesandsettings oflocalnetwork,andmaynot beactivatedormaybelimited

bylocalnetwork operatorsornetwork serviceproviders,thusthedescriptionshereinmaynot

exactlymatchthe productorits accessoriesyoupurchase.

HuaweiTechnologies Co.,Ltdreserves the rightto changeormodifyanyinformationor

specifications contained inthis manualwithoutpriornoticeorobligation.

NO WARRANTY

THECONTENTSOFTHISMANUALAREPROVIDED ASIS”.EXCEPT ASREQUIREDBY

APPLICABLELAWS,NOWARRANTIESOFANYKIND,EITHEREXPRESS OR IMPLIED,

INCLUDING BUT NOTLIMITEDTO,THEIMPLIEDWARRANTIESOFMERCHANTABILITYAND

FITNESS FORAPARTICULAR PURPOSE,AREMADEINRELATIONTOTHEACCURACY,

RELIABILITYOR CONTENTSOFTHISMANUAL.

TOTHEMAXIMUMEXTENTPERMITTEDBYAPPLICABLELAW,INNOCASESHALL HUAWEI

TECHNOLOGIESCO.,LTDBELIABLEFOR ANYSPECIAL,INCIDENTAL,INDIRECT,OR

CONSEQUENTIAL DAMAGES,OR LOST PROFITS,BUSINESS,REVENUE,DATA,GOODWILL

OR ANTICIPATEDSAVINGS.

ImportandExportRegulations

Customers shall complywithall applicableexportorimportlaws and regulations and will

obtainall necessarygovernmentalpermits and licenses inorderto export,re-exportor

importthe productmentioned inthismanualincluding the softwareand technicaldata

therein.

Tableof Contents

Getting to Knowthe E1762..........................................................................................1

Requirements forthePC..............................................................................................3

Preparing the E1762....................................................................................................3

InstallationGuide........................................................................................................5

SafetyInformation......................................................................................................8

Thankyou for purchasingHuaweiE1762HSPAUSB

Stick.

Note:

nThismanualbrieflydescribesthe preparation,the process forinstalling/uninstalling,and

safetyprecautions forusing HuaweiE1762 HSPAUSB Stick(hereinafterreferred to as

the E1762).

nYouarerecommended to read the manualbeforeusing theE1762.

GettingtoKnowtheE1762

The following figures showthe appearanceofthe E1762. The actualproductmaydiffer.

ŒUSBInterface

Connects to the USB interfaceofthePC.

•USIM/SIMcardslot

Holds the USIM/SIMcard.

ŽMicroSDcardslot

Holds the MicroSDcard.

•ExternalAntennaJack

Connects to an externalantenna.

•Indicator

Indicates the status ofthe E1762.

nGreen,blinking twiceevery 3s:The E1762 is powered on.

nGreen,blinkingonceevery3s:TheE1762 isregisteredto theGSM/GPRS/EDGE network.

nBlue,blinking onceevery 3s:The E1762 is registered to the WCDMA/HSDPA/HSUPA

network.

nGreen,always on:The GPRS/EDGE connectionis setup.

nBlue,always on:The WCDMAconnectionis setup.

nCyan,always on:The HSDPA/HSUPAconnectionis setup.

nOff: The E1762 is removed fromthe PC.

RequirementsforthePC

Tousethe E1762, the PCmustmeetthefollowing requirements:

nStandardUSB interface.

nWindows 2000 SP4, Windows XP SP2, Windows Vista.

nThe hardwareofyourPCmustmeetorexceed the recommended systemrequirements

forthe installed versionofOS.

nDisplayresolution:800 ×600 orabove.

PreparingtheE1762

InsertingtheUSIM/SIMCard

InserttheUSIM/SIMcardinto thecardslots.Makesurethatthe cards areproperlyinserted.

InsertingtheMicroSDCard

Insertthe MicroSDcard into the E1762, as showninthefollowing figure.

Note:

nMicroSDcard isan optionalaccessory.

nDonot removetheUSIM/SIMcard andthe MicroSDcard when theyarebeingused.

Removing the cardsduring an operationmaydamagethe cards as well as the device,

and datastored onthecards maybecorrupted.

InstallationGuide

The procedureforinstalling the managementprogramdepends ontheoperating system

installed onyourPC.Thefollowing sectiontakes Windows XP as anexample.

ConnectingtheE1762with aPC

Note:

PoweronyourPCbeforeconnecting the E1762 withthe PC.Otherwise,the normal

installationofthe E1762 maybeaffected.

Oneway: PlugtheE1762intotheUSBinterface ofthePC.

Theotherway: connecttheE1762 toaPCusingtheUSBextension cable.

InstallingtheE1762 ManagementProgram

1. Connectthe E1762 withthe PC.

2. The OSautomaticallydetects and recognises newhardwareand starts the installation

wizard

Note:

Ifthe auto-runprogramdoesnot respond,findthe AutoRun.exe fileinthe driverpath.

Then double-click AutoRun.exe to run theprogram.

3. Followthe prompts ofthe installationwizard.

4. Afterthe programis installed,the shortcuticonofthe managementprogramis

displayed onthe desktop.

LaunchingtheManagementProgram

Afterthe E1762 isinstalled,themanagementprogramislaunched automatically.Then every

timethe E1762 is connected to the PC,the managementprogramis launched automatically.

Youcan alsodouble-click theshortcuticononthedesktop to launchthemanagement

program.

UninstallingtheManagementProgram

1. Choose Start>ControlPanel.

2. Find the managementprogram,and click Add/RemoveProgram to uninstall the

managementprogram.

Note:

Itis recommended to restartthe PCaftertheuninstallationto ensurethatthe management

programiscompletelyuninstalled.

RemovingtheE1762

1. Double-click inthe systemtray.TheUnplugorEjectHardwareinterfaceis

displayed.

2. Selectthe hardwarerelated to the E1762 andclick Stop.

3. Whenthe prompt "It issafetoremovethedevice" isdisplayed,removetheE1762.

Note:

Beforeremoving the E1762, exit the managementprogram.
