Huawei C5060 User manual
CDMA1X Mobile Phone
USER GUIDE
C5060
Copyright © Huawei Technologies Co., Ltd. 2010.
All rights reserved.
No part of this document may be reproduced or transmitted in any
form or by any means without prior written consent of Huawei
Technologies Co., Ltd.
The product described in this manual may include copyrighted
software of Huawei Technologies Co., Ltd and possible licensors.
Customers shall not in any manner reproduce, distribute, modify,
decompile, disassemble, decrypt, extract, reverse engineer, lease,
assign, or sublicense the said software, unless such restrictions are
prohibited by applicable laws or such actions are approved by
respective copyright holders under licenses.
Trademarks and Permissions
, , and
are trademarks or registered
trademarks of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names mentioned
are the property of their respective owners.
Notice
Some features of the product and its accessories described herein rely
on the software installed, capacities and settings of local network,
and may not be activated or may be limited by local network
operators or network service providers. Thus the descriptions herein
may not exactly match the product or its accessories you purchase.
Huawei Technologies Co., Ltd reserves the right to change or modify
any information or specifications contained in this manual without
prior notice or obligation.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”.
EXCEPT AS REQUIRED BYAPPLICABLE LAWS, NO
WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE
ACCURACY, RELIABILITY OR CONTENTS OF THIS
MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE
LAW, IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD
BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR
CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS,
REVENUE, DATA, GOODWILL ORANTICIPATED SAVINGS.
Import and Export Regulations
Customers shall comply with all applicable export or import laws and
regulations and will obtain all necessary governmental permits and
licenses in order to export, re-export or import the product mentioned
in this manual including the software and technical data therein.
i
Table of Contents
1Your Phone.....................................................................................1
2Keys and Functions........................................................................3
3Screen Icons....................................................................................5
4Menu Tree ......................................................................................6
5Installing the Battery and microSD Card ...................................7
6Charging the Battery.....................................................................7
7Using the Function Menu..............................................................7
8Making a Call.................................................................................8
9Answering a Call............................................................................9
10 Creating and Sending a Message ...............................................9
11 Creating and Sending a Multimedia Message ........................10
12 Phone Lock.................................................................................10
13 Locking the Keypad...................................................................10
14 Changing the Text Input Modes ..............................................11
15 Entering English (En)................................................................11
16 Entering English (Abc)..............................................................12
17 Entering Spanish........................................................................12
18 Entering Numbers .....................................................................12
19 Entering Symbols.......................................................................13
20 Playing Music.............................................................................13
21 Taking a photo ...........................................................................14
22 Warnings and Precautions........................................................15
1
1 Your Phone
Earpiece
Screen
Left Soft key
Music key
Talk/Send key
Navigation key
*Key
OK key
Right soft key
Clear key
End/Power key
Number keys
#Key
Microphone
2
Charger interface/
Data cable connector
Camera
Speaker
Headset jack
Strap hole
3
2 Keys and Functions
Press… To…
End key
zPower on or off the phone (by pressing and holding
it).
zEnd a call or reject an incoming call.
zReturn to the standby mode.
Dial key
zView the call log in standby mode.
zMake or answer a call.
Left soft
key
Select the option displayed on the lower left corner of
the screen.
Right soft
key
Select the option displayed on the lower right corner of
the screen.
z: Display the Contacts List screen.
z: Display the Messages screen.
z:Switch to the previous shortcut menu on the
standby screen or decrease the volume during a call.
z: Switch to the next shortcut menu on the
standby screen or increase the volume during a call.
Confirm a selection.
4
Press… To…
–
zEnter numbers, letters, and symbols.
zAccess the voice mailbox in standby mode (by
pressing and holding the 1key).
zSpeed-dial phone numbers in standby mode (by
pressing and holding the 2–9 keys).
zSelect a submenu item labeled with the
corresponding number.
zEnter the * symbol.
zActivated or deactivated the Meeting profile in
standby mode (by pressing and holding it).
zProvide different functions according to the phone
features being used.
zEnter the # symbol.
zLock the keypad in standby mode (by pressing and
holding it).
zProvide different functions according to the phone
features being used.
zLaunch the Media Player.
zMinimize or exit the Media Player.
zDelete items, such as pictures, sounds, and contacts.
zDelete letters in edit mode.
5
3 Screen Icons
Icon Description Icon Description
Network signal
strength Battery power level
No network signal Low battery
CDMA 1X network Alarm clock on
Domestic roaming General profile
Overseas roaming Silence profile
Calling Meeting profile
Keypad locked Outdoor profile
Push SMS received My profile
Message received Voice mail received
Urgent message
received Data service
microSD card
Installed - -
6
4 Menu Tree
Multimedia
1 Media Player
2 Recorder
3 Radio
4 WAP
5 Camera
1 Alarms
2 Scheduler
3 Calculator
4 Stopwatch
5 World Clock
6 Weather Forecast
7 Ducati
1 Search
2 Search By
Location
3 Add New
4 Groups
5 Speed Dial
6 My Number
7 Management
Contacts
1 SMS
2 MMS
Messages
1 All Calls
2 Missed Calls
3 Received Calls
4 Dialed Calls
5 Call Memo
6 Call Duration
Call Log
Tools
Access the
Mobile Shop
Brew
1 Phone Settings
2 Display Settings
3 Call Settings
4 Connectivity
Settings
5 Security Settings
Settings
WAP
1 Home
2 Google Search
3 History
4 Bookmark List
5 Go to URL
6 Saved Pages
7 Push Messages
8 Settings
9 Exit Browser
1 Pictures
2 Musics
3 Others
4 Memory Card
5 Memory Status
My Files
