Hotpoint HSWP1000MWW User manual

www.Hotpoint.com

Safety Instructions .......... 2,3

Operating Instructions

Care and Cleaning

of the Washer ...................... 6

Control Panel ....................... 4

Control Settings .................... 4

Features ............................ 5

Loading and Using

the Washer ........................ 6

Troubleshooting Tips ........ 7-9

Consumer Support

Consumer Support ................ 12

Warranty .......................... 11

Write the model and serial

number here:

Model #

Serial #

You can find them

under the lid of

the washer,

49-90443 72-77 GE

IMPORTANT SAFETYINFORMATION.

READALL INSTRUCTIONSBEFOREUSING.

of fire or explosion, electric shock, or to prevent proper{y damage, persona/injury,

or loss of life.

WATEl?HEATEl?SAFETY

Under certain conditions, hydrogen gas may be produced in awater heater that has not been

used for two weeks or more. Hydrogen gas can be explosive under these circumstances.

If the hot water has not been used for two weeks or more, prevent the possibility of damage or injury by turning

on all hot water faucets and allowing them to run for several minutes. Do this before using any electrical

appliance which is connected to the hot water system. This simple procedure will allow any

built-up hydrogen gas to escape. Since the gas is flammable, do not smoke or use an open flame or

appliance during this process.

%PROPERINSTALLATION

This washer must be properly installed and located in accordance with the Installation

instructions before it is used. if you did not receive an installation instructions sheet, you can

receive one bY visiting www Hotpoint.corn or by calling 800. GE.CARES (800.432.2737).

B Install or store where it will not be exposed to

temperatures below freezing or exposed to the

weather, which could cause permanent damage

and invalidate the warranty.

BProperly ground washer to conform with all

governing codes and ordinances. Follow details

in Installation Instructions.

Parts and Accessories

Order on-line at GEAppfiances.comtoday, 24

hours a day or by phone at 800.626.2002 during

normal business hours.

Part Number

WH41X10207

Accessory

4 ft RubberWater Supply Hose

I This washer does not include water supply hoses. WX14X10005 4 ft Braided Water Supply Hose

GEstrongly recommends the use of factory

specified parts. A list of factory hoses available for

purchase are listed below. These hoses are

manufactured and tested to meet GE

specifications.

GEstrongly recommends the use of new water

supply hoses. Hoses degrade over time and need

to be replaced every 5 years to reduce the risk of

hose failures and water damage.

YOURLAUNDRYAREA

B Keep the area underneath and around your

appliances free of combustible materials such as

lint, paper, rags, chemicals, etc.

B Close supervision is necessary if this appliance is

used by or near children. Do not allow children to

play on, with or inside this or any other appliance.

www,Hot oint.com

Use this

appliance

only for its

intended

purpose as

described in

this Owner's

Manual.

WHENUSING THEWASHER

Never reach into the washer while it is moving,

Wait until the machine has completely stopped

before opening the lid,

Do not mix chlorine bleach with ammonia or acids

such as vinegar and/or rust remover, Mixing

different chemicals can produce a

toxic gas which may cause death,

Do not wash or dry articles that have been

cleaned in,washed in,soaked in or spotted with

combustible or explosive substances (such as

wax, oil, paint, gasoline, degreasers, dry-cleaning

solvents, kerosene, etc,),These substances give off

vapors that may ignite or explode, Do not add

these substances to the wash water, Do not use or

place these substances around your washer or

dryer during operation,

The laundry process can reduce the flame

retardancy of fabrics, To avoid such a result,

carefully follow the garment manufacturer's

wash and care instructions,

To minimize the possibility of electric shock,

unplug this appliance from the power supply

or disconnect the washer at the building's

distribution panel by removing the fuse or

switching off the circuit breaker before attempting

any maintenance or cleaning,

NOTE."Turning the Cycle Selector Knob to an off

position, or pressing PAUSE does NOT disconnect

the applL?nce from the power supp_,

Never attempt to operate this appliance if it is

damaged, malfunctioning, partially disassembled,

or has missing or broken parts, including a

damaged cord or plug,

WHENNOTIN USE

Turn off water faucets to relieve pressure on hoses

and valves and to minimize leakage if a break or

rupture should occur, Check the condition of the fill

hoses; Hotpoint recommends changing the hoses

every 5 years,

Before discarding a washer, or removing it

from service, remove the washer lid to prevent

children from hiding inside,

I Do not attempt to repair or replace any part of this

appliance unless specifically recommended in this

Owner's Manual, or in published user-repair

instructions that you understand and have the skills

to carry out,

I Do not tamper with controls,

READAND FOLLOWTHISSAFETYINFORMATION

CAREFULLY.

SAVETHESEINSTRUCTIONS

About the control panel

* Add detergent

Step 1Step 2

- Add items

p 3

• Select load size

• Select temperature

Step 4

, Select wash cycle * Close lid

•Pull knob

LOAD SIZE TEMPERATURE

Controls

Load Size (on some mode/s)

Loosely load items in the washer basket, Overloading may negatively impact wash performance, Adjust the load size accordingly,

Temperature (on some mode/s)

Select the water temperature for the wash and rinse cycles, Always follow fabric manufacturer's care label or instructions when

laundering,

Wash Cycle--Cycle Selector Knob

The chart below will help you match the wash cycle setting with your items, The chart is ranked from greatest to least wash intensity,

Your washer may not have all these cycles,

WHITESForheavyto lightly soiledcottons, household linens,work and play clothes,

(REGULARWASH/FASTSPIN)

COLORSForheavy to lightly soiledcolors andjeans

(REGULARWASH/FASTSPIN)

CASUALSForheavy to lightly soiledcottons, household linens,work and play clothes,

(PULSED/FASTSPIN)

About washer features, www.Hotpoint.com

Liquid Bleach Funnel

The water fill dilutes liquid chlorine bleach as the washer fills for the wash cycle,

] Check clothing care labels for special instructions,

r_ Measure liquid bleach carefully, following instructions on the bottle,

II Never pour undiluted liquid chlorine bleach direct_ onto clothes or into the wash

basket,

II Do not pour powdered bleach into bleach funnel,

r_ Before starting the washer, pour measured amount of bleach directly into bleach funnel,

Avoid splashing or over-filling dispenser, If you prefer to use powdered bleach, add it into

the wash basket with your detergent,

II Do not mix chlorine bleach with ammonia or acids such as vinegar and/or rust remover,

FAQ

Q: What is the difference between Heav)/and Light settings?

A: For Whitesand Colors, the wash agitation time is increased by 6 minutes and for Casuals,

by 12 minutes, (Times are approximate)

Q: What is the difference between Regularand Pulsed?

A: Regu/armeans the washer will continuously agitate during the wash cycle, Pu/sedprovides

a more gentle wash cycle by including pause periods during the wash cycle,

Q: Which cycle is best for heavily soiled items?

A: Whites or Colors cycles have the greatest wash intensity, This cycle provides the best overall

cleaning Casuals should be used for wrinkle-free and permanent press items,

Q: How can reduce linting?

A: Sort wash loads by fabric type and whether they collect lint (velveteen, corduroy) or produce

lint (terry cloth, chenille), Wash small loads for a shorter amount of time,

Q: How much detergent do I use?

A: For best performance, always follow the detergent manufacturer's instructions on usage,

Many detergents are concentrated, so consult the product label and follow the clearly

marked lines on the detergent measuring cups, Excessive detergent can negatively impact

the wash performance,

Loading and using the washer.

Always follow fabric manufacturer's care label when laundering

_WashLoads

(whites, lights, colors), soil level,

fabric type (sturdy cottons, easy care, delicates)

and whether the fabric produces lint (terry cloth,

chenille) or collects lint (velveteen, corduroy),

Pro er Useof Deter ent

detergent can work effectively, Using too little or too

much detergent is a common cause of laundry

problems,

For spots, apply pre-treatment to items as

recommended on the product label, Application

should be made in the basket to prevent overspray

which may cause the coloring on the lid or graphics

to fade,

You can use less detergent if you have soft water,

a smaller load or a lightly soiled load,

When using high efficiency or concentrated

detergents, consult the product label to determine

amount required for optimum performance,

Excessive detergent will negatively impact wash

performance,

_/f_l__ __'_ __the Washer

_,) "t loading wet items, make sure you set the load/water

"" level high enough to allow the items to move freely,

Water level should just cover the items, To add items

after washer has started, lift the lid and submerge

additional items next to the agitator,

BDo not wrap long items like sheets orpants

around the agitator.

BDo not wash fk_bricscontaining flammable

materials (waxes, cleaning fluids, etc...).

B Washer will not agitate or spin with the lid up,

however the timer will continue to run.

Care and cleanin of the washer.

Wash Basket: Leave the lid open after washing to

allow moisture to evaporate, Ifyou want to clean

the basket, use a clean soft cloth dampened with

liquid detergent; then rinse, (Do not use harsh or

gritty cleaners,)

Eft/Hoses: Hotpoint recommends changing the hoses

every 5years,

Exterior: Immediately wipe off any spills, Wipe

with damp cloth, Try not to hit surface with

sharp objects,

Moving and Storage: Ask the service technician to

remove water from drain pump and hoses, See the

Installation Instructions packed with product for

information on how to reinstall the shipping rod

to keep the tub stationary when moving the washer,

For more information, visit www.Hotpoint.com or call

800.GE.CARES(800,432,2737), Do not store the

washer where it will be exposed to the weather,

Long Vacations: Be sure water supply is shut off at

faucets, Drain all water from hoses if weather will

be below freezing,

carl for service...

_Troub/eshoodng Tips

S'_3vetime and money./Review the charts on the following pages,

or visit www.Hotpoint.com. You may not need to ca# for service.

www.Hotpoint, com,

WATEl? Possible Causes What ToDo

Too manysuds Too much detergent • Measure your detergent carefully. Use less soap if you have

soft water, a smaller load or a lightly soiled load.

Type of detergent • Switch to a lower sudsing detergent brand and follow

instructions on package.

Soft water • Try less detergent.

Water/eaRs Using too much detergent • Use less detergent. Use less soap if you have soft water,

in washer a smaller load or a lightly soiled load.

Fill hoses or drain hose is • Make sure hose connections are tight at faucets and

improperly connected rubber washers are installed. Make sure end of drain hose

is correctly inserted in and secured to drain facility.

Household drain may • Check household plumbing. You may need to call

be clogged a plumber.

Drain hose loose , Make sure drain hose is fully seated in back of washer and

that the two retaining screws are fully seated.

Drain hose rubs on wall , Make sure drain hose does not make contact with the wall.

May cause excessive wear on the hose.

Constant water pressure • Tighten hoses at the faucets and turn the water off after

to the fill hoses at the each use.

water source • Check condition of the fill hoses; they should be replaced

every 5 years.

Water temperature Cooler water temperatures • New laundry detergents have been formulated to work

seems incorrect provide improved energy with cooler water temperatures without affecting wash

efficiency performance.

Water supply is turned off • Turn both hot and cold faucets fully on and make sure

or improperly connected hoses are connected to correct faucets.

Water valve screens are • Turn off the water source and remove the water connection

stopped up hoses from the upper back of the washer. Use a brush or

toothpick to clean the screens in the machine. Reconnect

the hoses and turn the water back on.

House water heater is • Make sure house water heater is delivering water at

not set properly 120°F-140°F (48°C-60°C).

Water pumped out before Lid lifted or cycle was put in • Reset cycle.

cycle is complete pause for over 24 hours

Water won'tdrain Drain hose is kinked or • Straighten drain hose and make sure washer is not

improperly connected sitting on it.

• Top of drain outlet should be less than 6 ft (1.8 m)

above floor.

Washer pauses during This is normal • This is normal. The washer alternates between agitate and

wash or rinse cycle soak during these cycles to get your clothes cleaner with

less wear.

Washer pauses during This is normal • The washer may pause during the spin cycle to remove

spin cycle soapy water more efficiently.

Before you carl for service...

OPERATION Possible Causes What To Do

Washer won't operate Washer is unplugged * Make sure cord is plugged securely into a working outlet,

Water supply is turned off • Turn both hot and cold faucets fully on,

Controls are not set properly * Check controls,

Lid is open--safety feature • Close lid and reset cycle, to the beginning if necessary,

prevents agitation and

spinning when lid is up

Circuit breaker/fuse is • Check house circuit breakers/fuses, Replace fuses or

tripped/blown reset breaker, Washer should have separate outlet,

Timer knob not pulled • Pull timer knob,

Lid magnet missing • Call for service,

Movement inside machine Shifting mechanism is • When the machine is manually turned off, the shifter will

when shut off disengaging the motor disengage the motor before completely shutting down,

If lid is raised before the motor isdisengaged, it will resume

when lid is closed,

PERFORMANCE Possible Causes What To Do

Clothes too wet incorrect spin cycle • Make sure the spin cycle selected matches the load you are

selected washing, Some fabrics will feel wetter when rinsed with cold water,

Colored spots incorrect use of fabric • Check fabric softener package for instructions,

softener • Pretreat stain and rewash,

Dye transfer • Sort whites or lightly colored items from dark colors,

Grayed oryellowed Not enough detergent • Use more detergent (especially with larger loads),

clothes Be sure to follow detergent manufacturer's directions,

Hard water • Use a water conditioner like Calgon brand or install

a water softener,

Water is not hot enough • Make sure water heater is delivering water at

120°F-140°F (48°C-60°C),

Washer is overloaded • Select load size to match clothes load,

Detergent is not • Add detergent before you load items,

dissolving

Dye transfer • Sort clothes by color, If fabric label states wash sepamte_

unstable dyes may be indicated,

Lint or residue on Clothes are air or line dried • If you do not dry your clothes with a clothes dryer, your

clothes clothes may retain more lint,

incorrect sorting * Separate lint producers from lint collectors,

Washing too long * Wash small loads for a shorter time than larger loads,

Detergent not dissolving • Add detergent before you load items,

• Try a liquid detergent,

• Use warmer water temperature,

Overloading • Load clothes loosely in the washer basket,AdJust load size

based on items size and material,

• Make sure load size selected matches clothes load size,

incorrect use of fabric • Check fabric softener package for instructions,

softener

www.Hotpoint.com

PERFORMANCE (cont.) Possible Causes What To Do

Pilling Result of normal wear on • While this is not caused by the washer, you can slow the

poly-cotton blends and pilling process by washing garments inside out,

fuzzy fabrics

Snags, holes, tears, rips

or excessive wear Pins, snaps, hooks, sharp • Fasten snaps, hooks, buttons and zippers,

buttons, belt buckles, • Remove loose items like pins, objects in pockets and

zippers and sharp objects sharp buttons,

left in pockets • Turn knits (which snag easily) inside out,

Undiluted chlorine bleach • Check bleach package instructions for proper amount,

• Never add undiluted bleach to wash or allow clothes to

come in contact with undiluted bleach,

Chemicals like hair bleach or • Rinse items that may have chemicals on them before

dye, permanent wave solution washing,

Wrinkling improper sorting • Avoid mixing heavy items (like work clothes) with light items

(like blouses),

• Try a fabric softener,

Overloading or incorrect • Load your washer so clothes have enough room to move

water level freely with water covering all of the clothes,

incorrect wash and • Match Cycle selection to the type of fabric you are washing

dry cycles (especially for easy care loads),

Repeated washing in • Wash in warm or cold water,

water that is too hot

SOUNDS Possible Causes What To Do

"Metallic clicking" Shifter mechanism is • The drive system will engage at the start of agitate and

engaging or disengaging disengage when agitate is complete, This occurs multiple

times during the wash,

"Click"when water Relay switch • The relay makes a click sound when activated, The water

stops titling level activates the relay and stops filling,

"Clicking"behind Control Automatic Temperature • This valve mixes in cold and hot water, The "clicking" isthe

Pane/during fiT/ Control Valve valve turning on and off,

Water volume changes Automatic Temperature • This valve mixes in cold and hot water, The sound changes

during fiTI Control Valve when the valves are turned on and off,

Motor "whining up"or Motor ramping up/down • The motor will speed up incrementally during the spin cycle,

"coasting down"in spin during spin cycle When spin is complete, it will coast until it stops,

"Humming" Water drain pump • The drain pump will make a humming sound when pumping

out water after agitation stops and continue until spin is

complete,

"Gurgling" Water drain pump • When the pump starts drawing in air, It starts to gurgle,

The washer should then begin spinning and the sound will

continue until it is done spinning,

Notes...

Other manuals for HSWP1000MWW

This manual suits for next models

Table of contents

Languages:

Other Hotpoint Washer manuals

Hotpoint

Hotpoint ARTL 104 User manual

Hotpoint

Hotpoint WMD 843 User manual

Hotpoint

Hotpoint WLW3750B Installation instructions

Hotpoint

Hotpoint WMD 763 User manual

Hotpoint

Hotpoint WMF 760 P User manual

Hotpoint

Hotpoint WM12 User manual

Hotpoint

Hotpoint WMYL 6151 User manual

Hotpoint

Hotpoint AQGD 169 S User manual

Hotpoint

Hotpoint AQXXL129PI Instruction manual

Hotpoint

Hotpoint AQ113D 697 E User manual

Hotpoint

Hotpoint BHWM 149 User manual

Hotpoint

Hotpoint WMSIF 8437 User manual

Hotpoint

Hotpoint WML 720 P User manual

Hotpoint

Hotpoint WML 740 P/G/A User manual

Hotpoint

Hotpoint AQUALTIS AQ9L 29 U User manual

Hotpoint

Hotpoint WMJLD 943 User manual

Hotpoint

Hotpoint Aquarius WF560 Instructions for and use User manual

Hotpoint

Hotpoint Aquarius wmaql 741 User manual

Hotpoint

Hotpoint FIRST EDITION FIRST EDITION WMA10 Guide

Hotpoint

Hotpoint Aquarius WMA50 User manual

Hotpoint

Hotpoint HTWP1000M0WW User manual

Hotpoint

Hotpoint VLSR1090GWW - 3.2 cu. Ft. Washer User manual

Hotpoint

Hotpoint WMAO 863 User manual

Hotpoint

Hotpoint Experience WMEF 963 User manual

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Electrolux

Electrolux EWF1284EDW Service manual

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide
