Honeywell PRO 2000 Series User manual
Operating
Manual
PRO 2000 Series
Programmable Thermostat
69-2608EFS-05
Read and save these instructions.
Need Help?
For assistance with this product please visit http://customer.resideo.com
CAUTION: EQUIPMENT DAMAGE HAZARD.
To prevent possible compressor damage, do not operate cooling system when outdoor
temperature is below 50°F (10°C).
This manual covers the following models:
TH2110DH: For 1 Heat/1 Cool systems
TH2210DH: For 2 Heat/1 Cool heat pump systems only
(Pull thermostat from wallplate and turn over to find model
number.)
PRO 2000
1 69-2608EFS—05
About your new thermostat
Thermostat features ........................................ 2
Thermostat is preset, ready to go............... 3
Quick reference to controls........................... 4
Quick reference to display............................. 5
Programming & Operation
Set time and day................................................ 6
Select system setting ...................................... 7
Select fan setting .............................................. 8
Using program schedules ..................... 9–10
Adjust program schedule ............................11
Program schedule overrides ..............12–13
Compressor protection.................................14
Early Start ..........................................................15
Appendices
Battery replacement ......................................16
Customer assistance.....................................17
In case of difficulty.................................18–19
Limited warranty .............................................20
This thermostat is ready to go!
Your new thermostat is pre-programmed
and ready to go.
See page 9 to check settings.
Table of contents
ENGLISH
About your new thermostat
Your new Resideo thermostat has been designed to give you many years of reliable
service and easy-to-use, push-button climate control.
Features
• Backlit display is easy to read
• Displays ambient (measured) temperature at all times
• One-touch access to setpoint temperature
• Preset program settings
• Temporary and permanent override of schedule
• Early start ensures the right temperature at the right time
• Built-in compressor protection
Operating Manual
2
PRO 2000
3 69-2608EFS—05
ENGLISH
This thermostat is ready to go!
Your new thermostat is pre-programmed and ready to go. All you have to do is set
the time and day. Then check the settings below and change if needed:
1. Set time and day (required for proper operation)....................................See page 6
2. Select system setting: Preset to Off...........................................To change, see page 7
3. Select fan setting: Preset to Auto..............................................To change, see page 8
4. Program schedules: Preset to energy-saving levels
while you’re at work or asleep ........................................... To change, see pages 9-11
ONETOUCH TEMP CONTROL: You can override the program schedule at any time, and
manually adjust the temperature (see pages 1213).
Operating Manual
69-2608EFS—05 4
ENGLISH
System switch (see page 7)
• Cool: Cooling system control.
• Off: All systems off.
• Heat: Heating system control.
• Em Heat: Emergency & Auxiliary Heat control.
Compressor is locked out. (Select models only.)
M32781
E.M. Heat Heat Off Cool Auto On
Fan
Quick reference to controls
Temperature
adjustment
Screen Lit for 12 seconds when you press any button.
Fan Switch (see page 8)
On: Fan runs continuously.
Auto: Fan runs only when heating
or cooling system is on.
Set: Press to set time/
day/schedule.
Hold: Press to override
programmed tempera-
ture control.
Run: Press to resume
program schedule.
PRO 2000
5 69-2608EFS—05
ENGLISH
M32701
We
Lo
Batt
Wake
Set
am
Heat
75
On
6:30
Quick reference to display screen
Low battery warning
(see page 16)
Setpoint indicator
Appears when the
setpoint temperature
is displayed.
Temperature
The ambient (measured)
temperature is normally
displayed. To view the
setpoint temperature,
press the Up or Down
button once. The setpoint
temperature will appear
for five seconds.
System status
Cool On: Cooling system is on.
Heat On: Heating system is on.
Aux On: Auxiliary heat is on. (Only for heat pumps with this capability [select models only].)
When Heat On or Cool On is flashing, compressor protection is engaged (see page 14).
Current day/time
(see page 6)
Current program period
Wake/Leave/Return/Sleep
(see pages 910)
Operating Manual
69-2608EFS—05 6
ENGLISH
Set Time
am
6:30
M32702
Set Day
We
M32703
Set the time and day
1. Press the SET button, then press s or
t to set the clock time.
2. Press the SET button, then press s or
t to select the day of the week.
3. Press RUN to save & exit.
Note: If the clock flashes, the thermostat will
follow your settings for the Monday “Wake” time
period until you reset the time and day.
Press SET, then adjust time.
Press SET, then select current day.
PRO 2000
7 69-2608EFS—05
ENGLISH
M32781
E.M. Heat Heat Off Cool Auto On
Fan
Select the system setting
The SYSTEM switch can be set to control
your heating or cooling system, depend-
ing on the season.
• Cool: Cooling system control.
• Off: All systems are off.
• Heat: Heating system control.
• Em Heat: Emergency & Auxiliary
Heat control. Compressor is locked
out. (Select models only.)
Set SYSTEM switch to control the
heating or cooling system.
CAUTION: EQUIPMENT DAMAGE
HAZARD. To prevent possible
compressor damage, do not operate
cooling system when outdoor
temperature is below 50°F (10°C).
Operating Manual
69-2608EFS—05 8
ENGLISH
Select the fan setting
Set the FAN switch to Auto or On.
In “Auto” mode (the most commonly used
setting), the fan runs only when the heat-
ing or cooling system is on.
If set to “On,” the fan runs continuously.
Set FAN switch to choose whether the fan
runs continuously or only as needed.
M32781
E.M. Heat Heat Off Cool Auto On
Fan
