Honeywell Manning GM-JR Manual

Gas Monitoring Alarm System

Manning GM-JR

Feed-Through Configuration

Instruction and Installation Manual

10/06

Release C

Honeywell Condential &Proprietary

This work contains valuable, condential, and proprietary information. Disclosure, use

or reproduction outside of Honeywell Inc. is prohibited except as authorized in writing.

This unpublished work is protected by the laws of the United States and other countries.

Notices and Trademarks

Release C October 2006

While thisinformation ispresented in good faith and believed to be accurate, Honeywell disclaimsthe implied

warranties of merchantability and tness for a particular purpose and makes no express warranties except as may

be stated in its written agreement with and for its customers.

In no event isHoneywell liable to anyone for anyindirect, special or consequential damages. The information and

specicationsin thisdocument are subject to change without notice.

Manning isa registered trademarkof Honeywell International Inc.

Other brand or product names are trademarks of their respective owners.

Honeywell Analytics

405 Barclay Blvd

Lincolnshire, IL 60069

847 955 8200

800 538 0363

[email protected]

www.honeywell.com

About This Document

World Wide Web

The following Honeywell web sites maybe of interest toIndustry Solution customers.

Honeywell Organization WWW Address (URL)

Corporate www.honeywell.com

Honeywell Analytics www.honeywellanalytics.com

Manning Gas Detection www.manningsystems.com

Telephone

rebmuNenohPnoitazinagrO

United States/ Canada Honeywell AnalyticsInc. 1-800-538-0363

Lincolnshire, IL

Service 1-800-321-6320

Asia Pacic Honeywell Asia Pacic Inc. (852) 23 31 9133

gnoKgnoH

Europe Honeywell PACE {32-2} 728-2711

Brussels, Belgium

Latin America Honeywell International Inc. 1-847-955-8200

Lincolnshire, IL

Sales Information

Symbol Denitions

The following table lists those symbolsused in thisdocument to denote certain conditions.

Symbol Denition

ATTENTION: Identiesinformation that requires special consideration.

TIP: Identies advise or hints for the user, often in terms of performing a task.

REFERENCE-EXTERNAL:Identiesan additional source of information outside of

thisbookset.

REFERENCE-INTERNAL:Identiesan additional source of information within this

bookset.

CAUTION: Indicatesa potentiallyhazardous situation which, if not avoided, mayresult

in minor or moderate injury. It may also be used to alert against unsafepractices.

CAUTION

symbol on the equipment refers the user to the product manual for

additional information. The symbol appearsnext to required information in the manual.

Contents Serial number:

Section Title Page

1 System Description 5

2 Installation 7

3 Operation 9

4 Limited Warranty 11

Introduction

This manual has been prepared to help in the use and installation of the Manning GM-JR Gas Monitoring Alarm

System. This manual will convey the operating details of the alarm system, ensure proper installation, and

demonstrate start-up and routine maintenance procedures.

ATTENTION: This manual must be carefully followed by all individuals who have or will have the

responsibility for using or servicing the sensor. Warranties made by Honeywell Analytics with respect to

this equipment will be voided if the equipment is not used and serviced in accordance with the instructions in this

manual. If in doubt about a procedure, please contact Honeywell Analytics before proceeding.

1System Description

The Manning GM-JR is designed to accept a single

4/20 mA current input signal and provide a 20

segment vertical LED bargraph display which gives a

visual indication of the gas concentration.

The unit has one relay which will trip when a field-

adjustable gas concentration setpoint is exceeded,

allowing the user to incorporate functions such as

ventilation control, remote horns, security system

monitoring, and automatic shutdown.

Designed to be highly reliable when properly installed,

the relay is energized during normal operation, and a

sensor fault monitoring circuit will indicate a fault and

trip the relay if the signal falls below 1.4 mA.

The unit has a power-up delay feature that places the

output in a normal condition for one minute to allow for

sensor stabilization.

The Manning GM-JR will support all Manning sensors,

including oxygen, which requires a down-scale alarm.

Monitoring Options:

The Manning GM-JR can be mounted in its own NEMA

1 enclosure or in the door of most Manning sensor

enclosures.

In the “Feed-Through Configuration,” the Manning GM-

JR can operate anywhere between the sensor and the

readout unit, including either a Manning readout or a

customer-supplied computer. In this configuration, the

Manning GM-JR is powered by the same cable which

powers the sensor.

If ordered in the “Stand-Alone Configuration,” the

Manning GM-JR requires a regulated 24 VDC power

supply provided by the installer. Honeywell Analytics

can supply a 120 VAC plug-in DC power supply to

power the Manning GM-JR and associated sensor. In

this case, ask for the “Stand-Alone Configuration”

instruction manual.

Attention: The Manning GM-JR is for use in

non-classified areas only.

1System Description continued

System Specifications

Electrical Power: 15-24 VDC regulated

Signal Input: 4/20 mA precision differential input

allows this unit to be mounted remotely and powered

from sensor power (internal resistance drop is

100 ohms).

Maximum Current Draw: 300 mA

(In standard configuration and no upscale indication,

the standby current draw is 100 mA)

Display: 20-segment LED bargraph, with a bottom

segment that flashes to indicate power up delay, and

lights continuously to indicate that the power is on

Trip Setting: 5% increments by use of shorting tab

Alarm Indication: Red LED

Fault Indication: White LED (at 1.4 mA or below)

Accuracy: LED readout provides 5% of full scale

resolution. Trip accuracies at these 5% increments are

within ± 1% of set point.

Time Delays: Alarm relay is 10 second delay on,

30 second delay for reset after alarm condition clears

Power Up Time Delay: On application of power the

alarm relay will be held in the normal state for one (1)

minute to allow the sensor to stabilize.

Relay Alarm Output: Relay is rated at 0.5 amp at

24 VDC or 24 VAC, 0.25 amp at 120 VAC. Relay will

trip on Alarm and Fault conditions.

Note: The relay is normally energized and

monitored by a green LED for ease of

troubleshooting.

Operating Ambient Temperature Range: 0oF to

+120oF

Storage Temperature Range: —40oF to +160oF

Operating Humidity: 5—95% Relative Humidity, non-

condensing

Enclosure: NEMA 1, gasketed, 16-gauge steel

Weight: 3 lbs.

Dimensions: 6" high x 4" wide x 3.5" deep

Cable Requirements: #18/3 shielded cable (Belden

#8770) for runs up to 1,000 feet. High current draw

sensors may require larger cable. Contact Honeywell

Analytics for details.

Note: The Manning GM-JR is for use only

in non-classified areas.

2Installation

ALocating Manning GM-JR

When unpacking the unit, inspect all boxes and

contents for shipping damage. If any screws or other

metal parts are missing, they must be found to ensure

that the printed circuit boards will not be damaged

when power is applied.

The control unit is designed to be mounted on a solid

(non-vibrating) wall through four holes in the two

mounting flanges. While the physical location must be

determined in part by local conditions, it is important to

consider the following:

• Protect the Manning GM-JR from rain, snow,

water sprays, cleaning crews, and physical

damage.

• Mount the unit on a solid wall (non-vibrating) at

eye level for convenience in taking readings,

servicing, etc.

• The Manning GM-JR is NOT explosion proof.

DO NOT MOUNT in a hazardous atmosphere.

• Operating temperature for the Manning GM-JR

is 0oF to +120oF.

• Pre-punched holes are provided in the bottom

of the enclosure for cable access. DO NOT drill

holes in the top of the cabinet as this will void

the warranty.

• If hole drilling is required, be sure to remove all

metal filings.

• Mounting dimensions for the NEMA 1 enclosure

are shown in Figure 1.

BWiring

Electrical wiring must comply with all applicable

codes. Plant equipment that may be involved and

operating conditions should be discussed with local

operating personnel to determine if any special needs

should considered.

Nearly all start-up problems are due to improper wiring

or monitor configuration. Please follow these guide-

lines carefully. Figure 2 presents a wiring diagram for

the Manning GM-JR in the feed-through configuration.

Relay Wiring:

The relay has Form C, dry contacts. Any required

power source must be within the amp rating and fused

or current limited to keep from damaging the contacts.

Relay wiring must be run in separate conduit from the

sensor cable if the relay circuit is AC.

The maximum relay rating is 0.5 amp at 24 VDC or

24 VAC, or 0.25 amp at 120 VAC.

Sensor Wiring:

Respect minimum voltage requirements.

• See sensor manual for proper sensor cable.

• See sensor manual for proper sensor location.

• Never run AC circuits in the same conduit as the

sensor cable.

Note: Relays are energized in a non-alarmed

condition so that a power loss in the Manning

GM-JR will result in an alarm.

Figure 1: NEMA 1 enclosure mounting dimensions

Manning GM-JR

Gas Monitor

2" 5/16" diameter

6 3/4"

Risk of electrical shock.

2Installation continued

Figure 2: Wiring diagram for the Manning GM-JR Gas Monitoring Alarm System — Feed-Through Configuration

SHLD GND +24 SIG

TO SENSOR

TO CONTROL UNIT

JR-BACK

+24

SIG IN

SIG OUT

GND

+24

SIG IN

SIG OUT

GND

100%

95%

90%

85%

80%

75%

70%

65%

60%

55%

50%

45%

40%

35%

30%

25%

20%

15%

10%

SETPOINT

BOT

TOP

SIG

TB1

GND

NC COM NO

TP2

SIGNAL TEST

40-200 mVDC

TP1

JP2

JP1

JP3

Relay output 0.5 amp at 24 VDC or 24 VAC Max

or 0.25 amp at 120 VAC

Note: JP1, JP2 and JP3 are not installed for

the Feed-Through Configuration

Outside bare wrap—connects

to “SHLD” terminal of sensor

Black—connects to “GND”

terminal of sensor

Connect to 24 VDC power

supply positive side

(300 mA + sensor requirement)

Connects to signal input of

monitoring equipment

Connects to case ground of

monitoring equipment

(earth ground)

Connect to power supply

ground side

Red—connects to “+24”

terminal of sensor

White—connects to “SIG”

terminal of sensor

Note: If the GM-JR is mounted in the sensor enclosure, the display board will be

connected directly into the sensor pre-amp.The sensor terminal block will function the

same as the bottom terminal block shown.

Risk of electrical shock.

Operation

ADisplay Panel

A 20-segment Bargraph Display indicates the gas

concentration level. The bottom LED is always lit to

indicate power to the display.

The bottom LED will flash during the one-minute power

up delay, indicating that the relay is held in the normal

condition to allow for sensor stabilization upon power

up.

When flashing, the Alarm LED indicates the alarm level,

as determined by the alarm setpoint, has been

exceeded. An alarm condition will trip the relay after a

10 second time delay.

The Fault LED indicates a signal input of less than

1.4 mA. A fault condition will also trip the relay after a

10 second time delay.

BSignal and Setpoints

The voltage between TP1 and TP2 indicates the current

signal received from the sensor. The normal range is

40 mV to 200 mV, which corresponds with 4 mA to

20 mA (see Figure 3, Note 1).

The setpoint can be adjusted from 10% to 100% full

scale in 5% increments using the shorting tab and

jumper block on the back of the display circuit board as

shown in Figure 3, Note 2. If the shorting tab is not

installed, the unit will go into alarm.

After setpoint adjustment, always expose sensor to

the gas being monitored and verify that the alarm

light triggers at the desired concentration as

displayed by the bargraph.

CStart-Up Procedures

Before applying power, make a final check of all

wiring for continuity, shorts, grounds, etc. It is usually

best to disconnect external alarms and other

equipment from the unit until the initial start-up

procedures are completed.

After power-up, allow 24 hours for the system

to stabilize before testing the sensor. Because

sensors are normally located at a distance from the

monitoring unit, the test time required and accuracy of

the response checks will be improved if two people

perform the start-up procedures and use radio contact.

Start-Up Test: One person exposes the sensor to a

small amount of the gas that is being monitored. The

second person stays at the monitoring unit to determine

that the sensor, when exposed to the gas fumes, is

connected to the proper input, responds, and causes

appropriate alarm functions.

Figure 3: Setpoint adjustment and signal reading on the Manning GM-JR

SHLD GND +24 SIG

TO SENSOR

TO CONTROL UNIT

JR-BACK

+24

SIG IN

SIG OUT

GND

+24

SIG IN

SIG OUT

GND

100%

95%

90%

85%

80%

75%

70%

65%

60%

55%

50%

45%

40%

35%

30%

25%

20%

15%

10%

SETPOINT

BOT

TOP

SIG

TB1

GND

NC COM NO

TP2

SIGNAL TEST

40-200 mVDC

TP1

JP2

JP1

JP3

40-200 mV

Black

-Red

mVDC

Relay output 0.5 amp at

24 VDC or 24 VAC Max

or 0.25 amp at 120 VAC

Note 2: Setpoint adjustment

using shorting tab

Note 1: Reading signal from sensor

Note: If the GM-JR is mounted in the

sensor enclosure, the display board

will be connected directly into the

sensor pre-amp. See sensor manual

for instructions on reading the signal.

Risk of electrical shock.

Operation continued

DTroubleshooting

Risk of electrical shock.

The unit will indicate a fault if the signal is less than

14 mV between TP1 and TP2 (see Figure 4, Note 1).

A signal greater than 20 mA (200 mV) must be

considered a high gas concentration.

Some Manning sensors are configured to send a

signal of 0.5 mA if a sensor fault exists. If the voltage

between TP1 and TP2 = 5 mV, this indicates a properly

wired sensor is in a fault condition. Proceed to

investigate the sensor.

If the voltage between TP1 and TP2 = 0.0 V, this

indicates no signal current is flowing. Check

monitoring equipment connections and configuration.

Input impedance must be 250 ohms or less.

The relay has a green LED in series with its coil

(see Figure 4, Note 2). If this LED is on, this indicates

that the relay is energized and contacts will be in the

normal position. If this LED is off, the contacts will be in

the tripped condition.

Power supply voltage should be checked at +24 on

the control unit input terminal block (see Figure 4,

Note 3). The voltage should be 15—24 VDC.

The Manning GM-JR and the connected sensor are

powered from the same supply. The supply must be

capable of supplying 300 mA at 24 VDC for the

Manning GM-JR in addition to the sensor current

requirement (see sensor manual).

The setpoint shorting tab must be installed (see

Figure 4, Note 4). If it is removed, the unit will go into

an alarm condition after the 10 second delay.

If questions arise, call Honeywell Analytics.

EMaintenance

The Manning GM-JR is designed for long life and high

reliability. Honeywell Analytics recommends checking

signal voltages monthly and logging them.

Additionally, the sensor being monitored should be

exposed to the target gas on a monthly basis while all

alarm functions are verified at the Manning GM-JR.

This will test the sensor and any equipment connected

to the relays in addition to the Manning GM-JR.

FReplacement Parts

For replacement parts, contact Honeywell Analytics.

Be sure to give serial number and model number of

unit.

Figure 4: Troubleshooting the Manning GM-JR Gas Monitoring Alarm System

SHLD GND +24 SIG

TO SENSOR

TO CONTROL UNIT

JR-BACK

+24

SIG IN

SIG OUT

GND

+24

SIG IN

SIG OUT

GND

100%

95%

90%

85%

80%

75%

70%

65%

60%

55%

50%

45%

40%

35%

30%

25%

20%

15%

10%

SETPOINT

BOT

TOP

SIG

TB1

GND

NC COM NO

TP2

SIGNAL TEST

40-200 mVDC

TP1

JP2

JP1

JP3

40-200 mV

Black

-Red

mVDC

15-24 VDC

Black

-Red

VDC

Note 4: If setpoint shorting

tab is not installed, unit will

be in alarm condition

Note 2: Green LED lighted

indicates relay is in normal

position

Note 1: Checking

signal 40-200 mV

Note 3: Checking

24 VDC power supply

to input terminal blocks

Note: If the GM-JR is mounted in

the sensor enclosure, the display

board will be connected directly into

the sensor pre-amp. See sensor

manual for further troubleshooting.

Risk of electrical shock.

Table of contents

Other Honeywell Security System manuals

Honeywell

Honeywell LYNX Touch Security System User manual

Honeywell

Honeywell VISTA-32FBPT User manual

Honeywell

Honeywell Lyric User manual

Honeywell

Honeywell Notifier P700N User manual

Honeywell

Honeywell ADEMCO VISTA-40 User manual

Honeywell

Honeywell 6272CV User manual

Honeywell

Honeywell First Alert FA130CP User manual

Honeywell

Honeywell LYNX Touch L5210 Series Operating instructions

Honeywell

Honeywell ADEMCO VISTA-48A Assembly instructions

Honeywell

Honeywell Ademco Vista-48LA Assembly instructions

Honeywell

Honeywell ADEMCO 745 3 Series Assembly instructions

Honeywell

Honeywell Lynx Plus Series Assembly instructions

Honeywell

Honeywell ESSER IQ8Alarm User manual

Honeywell

Honeywell Code Encryptor II User manual

Honeywell

Honeywell Fire-Lite Alarms ES-50XC User manual

Honeywell

Honeywell sixsiren User manual

Honeywell

Honeywell SILENT KNIGHT EVS Series User manual

Honeywell

Honeywell Lyric User manual

Honeywell

Honeywell Ademco VISTA-50P Operating instructions

Honeywell

Honeywell Water Defense RWD41 User manual

Honeywell

Honeywell RWD21 User manual

Honeywell

Honeywell 5800WAVE - Ademco Wireless Siren Assembly instructions

Honeywell

Honeywell VISTA-20PSeries User manual

Honeywell

Honeywell PID-95P Guide

Popular Security System manuals by other brands

Inner Range

Inner Range Concept 2000 user manual

Climax

Climax Mobile Lite R32 Installer's guide

CADDX

CADDX NX-6 user manual

FBII

FBII XL-31 Series installation instructions

Johnson Controls

Johnson Controls PENN Connected PC10 Install and Commissioning Guide

Aeotec

Aeotec Siren Gen5 quick start guide

Blaupunkt

Blaupunkt SA 2700 quick start guide

IDEAL

IDEAL Accenta Engineering information

AJAX

AJAX DoubleButton user manual

Swann

Swann SW-P-MC2 Specifications

Ecolink

Ecolink Siren+Chime user manual

Digital Monitoring Products

Digital Monitoring Products XR150 user guide

EDM

EDM Solution 6+6 Wireless-AE installation manual

Highway Safety Group

Highway Safety Group EA401 user manual

Siren

Siren LED GSM operating manual

Detection Systems

Detection Systems 7090i Installation and programming manual

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 instructions

Siemens

Siemens FDM273 manual
