Hisense WTJD802G Mounting instructions
X08060447
X08060447
B
王爱军 201 9.03. 15
崔维明 2019.03.15
刘泽旺 2019.03.15
程木聪 2019.03.15
姜 鹏 2019.03.15
石伟泽 2019.03. 15
2013675
南非
WTJD802T
GB/T 1804-m ；
XECN003611
刘大燕 2019.03.15
WTJD802G/WTJD802T
X08060447B
WTJD802G/WTJD802T
0.03
0.03
33
0.03
As shown on the left figure, pull out the soap box before adding the liquid detergent.
Either the washing powder detergent or liquid detergent can be used.
Put the washing powder detergent/liquid detergent directly into the appropriate position in the detergent box.
The low foaming washing powder detergent/liquid detergent is recommended.
The required quantity of washing powder detergent/liquid detergent will vary with the quality of the washing powder
detergent/liquid detergent and the dirtiness of the laundry.
When the load of laundry is little, the water level should not be too high, otherwise not only the water and washing powder/
detergent will be wasted, but water will spill out easily.
When the liquid detergent is added, the height of the liquid detergent should not be higher than that of the cover.
When the liquid detergent or washing powder detergent is agglomerated or viscous, it should be diluted with a small
amount of water before being placed into the detergent box to avoid any residue of detergent or additives after washing.
(Please put enough amount of washing
powder required for one time wash to
the box evenly)
Add the
liquid
detergent
Add the washing
powder detergent
Detergent box A
1. Power switch
Press the power switch to turn on the power.
After power-on, press the power switch to turn off the power.
If the “Start/Pause” button is not pressed in 10 minutes after the
power is turned on, the washing machine will automatically power
off .
2. Start/Pause
After power-on, press this button to start the washing machine.
While the washing machine is running, press this button to stop it.
3. Temp./Options
press Temp./Options button repeatedly to cycle through the
water temperature, air dry and tub clean
Cold>Cold, Air dry>Cold, Hot>Cold, Hot, Air dry>Hot>Hot, Air
dry>Cold, Hot, Tub Clean>Cold
Program
Choose the appropriate washing program based on the load,
texture and dirtiness of laundry.
The selection sequence is as follows: Fuzzy → Quick → Delicate
→ Jeans →Heavy→ Wool → Memory → Eco → Fuzzy
4.
5. Delay
The Delay time is within 24 hours. When the Delay is set, the
digital tube displays the reserve time, and it will be canceled when
the automatic process programming is performed again.
After the Delay is started, the ongoing process and automatic time
programming of Delay time can be stopped. During pause, the
Delay time is displayed; after the water level, soak, wash, rinse
and spin are changed, the current process, water level, function
and remaining time are showed; when the Delay time is changed,
the new Delay time is displayed; when the “Start/Pause” button is
pressed, the program controller will automatically adjust the Delay
time according to the currently required total time.
6. Selection of water level
This machine has 8 water levels for selection.
Depending on the load of laundry to be washed, press this button
to select the appropriate water level.
Water replenishing: After the program is started, press the “Water
level” button to replenish water until the button is released. And
the water level indicator does not change during this process.
The water replenishing is suitable for the soak, wash and rinse
processes. When the water reaches the highest level, the water
replenishing is automatically stopped.
In addition, no water replenishing is allowed during the fuzzy run.
Under child lock state, the manual water replenishing is
prohibited.
7. Soak
Soak or not is determined according to the dirtiness of laundry.
In quick and wool programs, the soak process cannot be started.
8. Child lock
After the program is started, press the “Soak” and “Wash” buttons
simultaneously for 3 seconds to set or cancel the child lock. After
the child lock is started, all the buttons on the panel are invalid,
and the child lock is automatically canceled after the program
finishes.
Wash
program
Wash
time(min)
Spin
time(min)
Fuzzy
Quick
Delicate
Jeans
Heavy
Wool
Memory
Eco
9.
The default time of rinses is as follows: When the quick program
is selected, the default time of rinse is 1; when the programs of
fuzzy, delicate, jeans, heavy or wool are selected, the time is 2;
and when the eco is selected, the time is 2. If only rinse program
is set by the user, the time of rinse cannot be set to 0.
10. Rinse
Wash
The washing time can be adjusted according to the needs of the
user.
When the “Wash” button is pressed for a long time, the figure on
the digital tube is incremented continuously until the button is
released.
The washing time for quick program is no more than 8 minutes.
The washing time for wool program is no more than 16 minutes.
After powering on the machine or selecting the program, press
the “Wash” button to select the single wash program. At this
time, the digital tube displays the currently required washing
time; press the “Wash” button again to increment the washing
time in cycle, and the washing time cannot be set to 0. After
selecting the single washing program, press the “Rinse” button to
add the rinsing process, and press the “Spin” button to add the
spin process.
11. Spin
The spin time can be selected.
The single spin can be set. After powering on the machine or
selecting the program, press the “Spin” button to select the
single spin program. Meanwhile, the spin time cannot be set to 0.
Under the child lock state, if the cover is opened, the “E1” alarm
will be issued, then if the cover is not covered within 5 seconds,
the washing machine will automatically drain, and stop the
drainage after the alarm is removed.
After the power is turned off, the child lock is invalid.
15 7
13
14
16
11 5
15
11 16
