Hisense HWGE9014 Mounting instructions

MODEL: HWGE9014

HWGE8014 English

USER’S OPERATION MANUAL

Before operating this unit, please read this manual

thoroughly, and retain for future reference.

The following symbols are used throughout the manual and they have the following meanings:

Information, advice, tip, or recommendation

Warning – general danger

Warning – danger of electric shock

Warning – danger of hot surface

Warning – danger of fire

It is important that you carefully read the instructions.

820685

4 SAFETY PRECAUTIONS

10 WASHING MACHINE DESCRIPTION

11 Technical specifications

12 Control unit

14 INSTALLATION AND CONNECTION

14 Removing the blocking rods

15 Moving and transport after installation

16 Selecting the room

16 Adjusting the washing machine feet

18 Connecting to water supply

19 Aqua stop

19 Total aqua stop

20 Connecting and securing the water discharge hose

22 Connecting the appliance to the power mains

23 BEFORE USING THE APPLIANCE FOR THE FIRST TIME

24 WASHING PROCESS, STEP BY STEP (1–7)

24 Step 1: Heed the labels on the laundry

25 Step 2: Preparing the washing process

27 Step 3: Choosing the washing programme

31 Step 4: Choosing the settings

35 Step 5: Selecting additional functions

37 Step 6: Starting the washing programme

38 Step 7: Change of washing programme or manual (physical) cancellation

39 Step 8: End of the washing programme

40 INTERRUPTIONS AND CHANGING THE PROGRAMME

43 MAINTENANCE & CLEANING

43 Cleaning the dispenser tray

44 Cleaning the water supply hose, detergent dispenser housing, and rubber

door gasket

45 Cleaning the pump filter

46 Cleaning the washing machine exterior

47 TROUBLESHOOTING

47 What to do ...?

48 Troubleshooting and error table

52 Servicing

53 RECOMMENDATIONS FOR WASHING AND ECONOMIC USE YOUR

WASHING MACHINE

56 Stain removal tips

58 DISPOSAL

59 PROGRAM DURATION AND SPINNING RATE TABLE

60 INFORMATION FOR TEST INSTITUTE

STEPS OF

THE WASHING

PROCESS

WASHING

MACHINE

CLEANING AND

MAINTENANCE

INTRODUCTION

TROUBLE-

SHOOTING

PREPARING

THE WASHING

MACHINE

BEFORE FIRST

USE

MISCELLANE-

OUS

CONTENTS

820685

Carefully read the instructions for use before using the

washing machine.

Please, do not use the washing machine without reading

and understanding these instructions or use first.

These instructions for use of a washing machine are

supplied with different types or models of washing

machines. Therefore, they may include descriptions

of settings or equipment that are not available in your

washing machine.

Failure to observe the instructions for use or inappropriate

use of the washing machine may result in damage to the

laundry or the appliance, or injury to the user. Keep the

instruction manual handy, near the washing machine.

Instructions for use are available through Hisense customer

service centers.

Your washing machine is intended solely for household

use. If the washing machine is used for professional,

for-profit purpose or purpose exceeding normal use in a

household, or if the washing machine is used by a person

who is not a consumer, the warranty period shall be equal to

the shortest warranty period required by relevant legislation.

SAFETY PRECAUTIONS

820685

Follow the instructions for correct installation of the Hisense

washing machine and connection to the water and power

mains (see chapter »INSTALLATION AND CONNECTION«).

Connection to water and power supply has to be executed

by an adequately trained technician or expert.

Any repair and maintenance pertaining to safety or

performance should be done by trained experts.

To avoid danger, a damaged power cord may only be

replaced by the manufacturer, a service technician, or an

authorized person.

Before connecting the washing machine to the power

mains, wait for at least 2 hours until it reaches room

temperature.

In case of a defect, only use approved spare parts by

authorized manufacturers.

In case of incorrect washing machine connection, incorrect

use, or servicing by an unauthorized person, the user shall

bear the cost of any damage as such damage shall not be

covered by warranty.

The washing machine may not be connected to the power

mains using an extension cord.

Do not connect the washing machine to power mains using

an external switching device such as a programme timer, or

connect it to power mains that is regularly switched on and

off by the power supply provider.

820685

Do not connect the washing machine to an electrical outlet

intended for an electric shaver or hair dryer.

Do not install the washing machine in a room where the

temperature can drop to below 5°C, as washing machine

parts may be damaged in case of water freezing.

Place the washing machine on a level and stable solid

(concrete) base.

If the washing machine is placed on an elevated stable base,

the washing machine has to be additionally secured against

tipping.

Before the first use of the washing machine, remove the

blocking rods, as switching on a blocked washing machine

can result in serious damage (see chapter »INSTALLATION

AND CONNECTION/Removing the blocking rods«). Warranty

shall be void in cases of such damage.

To connect the washing machine to water supply, make

sure to use the supplied water supply hose and gaskets.

Water pressure has to be between 0.05 and 0.8 MPa (0.5 – 8

bar).

Always use a new water supply hose to connect the washing

machine to water supply; do not reuse an old water supply

hose.

The end of the water discharge hose should reach into a

water drain line.

820685

Before the start of the washing cycle, press the door on the

indicated spot until it locks into place. The door cannot be

opened during washing machine operation.

We recommend removing any impurities from the

washing machine drum before the first wash using the

Cotton 90°C programme (see PROGRAMME TABLE).

After the washing cycle, close the water tap and pull out

the washing machine plug from the power socket.

Clean the pump filter whenever the symbol appears on the

display unit.

Only use the washing machine for washing laundry, as

described in the instruction manual. The machine is not

intended for dry cleaning.

Only use agents for machine washing and care of

laundry. We shall not be responsible for any damages or

discolouration of gaskets and plastic parts resulting from

incorrect use of bleaching or colouring agents.

When descaling, only use descaling agents with added

anti-corrosion protection. (Only use non-corrosive descaling

agents.) Follow the manufacturer's instructions. Finish the

descaling process with several rinse cycles or by running the

Drum Clean (Self-cleaning programme) in order to remove

any residual acid (e.g. vinegar etc.).

Do not use detergents that contain solvents as this could

lead to release of poisonous gases, damage to the washing

machine, and risk of fire and explosion.

820685

No silver ions are released during the washing programme.

The washing machine is not intended for use by persons

(including children) with physical or mental impairments,

or persons with lacking experience and knowledge. These

persons should be instructed about the use of the washing

machine by a person responsible for their safety.

The warranty does not cover consumables, minor

deviations in colour, increased noise that results from

appliance age and which does not affect the functionality of

the appliance, and aesthetic defects on components, which

do not affect the functionality and safety of the appliance.

CHILD SAFETY

Before closing the washing machine door and running the

programme, make sure there is nothing except laundry in the

drum (e.g. if a child climbed into the washing machine drum

and closed the door from the inside).

Keep the detergent and conditioner out of reach of children.

Activate the child lock. See chapter »CHOOSING THE

SETTINGS/Child lock«.

Do not let children younger than three years come

near the appliance, unless they are under constant

supervision.

The washing machine is made in compliance with all

relevant safety standards.

This washing machine may be used by children aged 8

years and above and by persons with reduced physical,

820685

sensory or mental capabilities or lack of experience and

knowledge, but only if they are supervised during the use of

the washing machine, if they have been provided relevant

instructions regarding safe use of the washing machine, and

if they understand the hazards of inappropriate use. Make

sure children do not play with the appliance. Children may

not clean the washing machine or perform any maintenance

tasks without supervision.

DANGER OF HOT SURFACE

At higher washing temperatures, the door glass will heat up.

Be careful to avoid burns. Make sure children do not play

near the door glass.

WATER OVERFLOW PROTECTION (WITH WASHING

MACHINE SWITCHED ON)

If the water level in the appliance rises above normal level,

then the excess water level protection will be activated. It will

shut off the water supply and start pumping out the water.

The program is interrupted and an error is reported (see

TROUBLESHOOTING TABLE).

TRANSPORT/TRANSPORT AFTER INSTALLATION

If you intend to move the washing machine after it has

been installed, then it should be blocked by inserting at

least one blocking rod (see chapter »INSTALLATION AND

CONNECTION/Moving and transport after installation«).

Before inserting the blocking rods, disconnect the washing

machine from the power mains!

820685

BACK

1 Water supply hose

2 Power cord

3 Water discharge hose

4 Adjustable feet

FRONT

1 Control unit

2 Start/pause button

3 Programme selector knob

4 On/off/reset button

5 Dispenser tray

6 Door

7 Rating plate

8 Pump filter

WASHING MACHINE DESCRIPTION

34 25

6 87

This manual suits for next models

Table of contents

Other Hisense Washer manuals

Hisense

Hisense 5S Series Mounting instructions

Hisense

Hisense WFHV9014 Owner's manual

Hisense

Hisense WDQY901418VJM Series User manual

Hisense

Hisense WFBJ7012 Mounting instructions

Hisense

Hisense HWFE1014VA User manual

Hisense

Hisense WFEH9014VA Owner's manual

Hisense

Hisense WTHX1701T Mounting instructions

Hisense

Hisense WFPV9014EMT Mounting instructions

Hisense

Hisense WFDJ80121 Mounting instructions

Hisense

Hisense HWGA9014 Mounting instructions

Hisense

Hisense WF5S1043B Series Mounting instructions

Hisense

Hisense Washing Machines Mounting instructions

Hisense

Hisense WFN9012 User manual

Hisense

Hisense WFMB6010EM Mounting instructions

Hisense

Hisense XQG70-HR1014 User manual

Hisense

Hisense WFGE901439VM Mounting instructions

Hisense

Hisense WFPV7012EMS Mounting instructions

Hisense

Hisense WFQP6010EVM Series Mounting instructions

Hisense

Hisense WDQY8014EVJM Series Owner's manual

Hisense

Hisense W921DJS Mounting instructions

Hisense

Hisense XQB30-M328H User manual

Hisense

Hisense HDFS10HP Mounting instructions

Hisense

Hisense WFQP8014EVM Mounting instructions

Hisense

Hisense WFDJ60101 Mounting instructions

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Electrolux

Electrolux EWF1284EDW Service manual

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide
