Harbor Breeze L0982 User manual

Harbor Breeze®is a registered trademark

ITEM #0396772

MODEL #L0982

TWIN BREEZE II CEILING

FAN

Questions, problems, missing parts?

Before returning to your retailer, call our customer

service department at 1-800-643-0067, 8 a.m. - 6 p.m., EST, Monday - Thursday, 8 a.m. - 5

p.m., EST, Friday.

Español p. 20

ATTACH YOUR RECEIPT HERE

Serial Number

EB14427

Purchase Date

Lowes.com/harborbreeze

TABLE OF CONTENTS

Preparation ........................................................................................................................

Initial Instructions ...............................................................................................................

Wiring Instructions .............................................................................................................

Final Instruction ................................................................................................................

Operating Instructions ......................................................................................................

Care and Maintenance .....................................................................................................

Limited Lifetime Warranty .................................................................................................

Troubleshooting ................................................................................................................

Replacement Parts List ....................................................................................................

Safety Information .............................................................................................................

Package Contents .............................................................................................................

Hardware Contents ............................................................................................................

Lowes.com/harborbreeze

PACKAGE CONTENTS

A 1

Mounting Bracket

Downrod Assembly

Canopy

Top Housing

(Preassembled on

Motor Body (G))

Motor Body

Canopy Cover

E Coupling Cover

QUNTITYDESCRIPTIONPART

Blade Iron

Blade

J Fan Switch Cover

Fan Finial

Light Kit

Lowes.com/harborbreeze

2M Bulb

Glass Shade

Light Finial Cap

Light Finial 1

Switch Housing

(preassembled on Motor Body (G))

Bottom Housing

(preassembled on Motor Body (G))

T 1Balance Kit

U 1

Clevin Pin

(preassembled on Motor Body (G))

Hairpin Clip

(preassembled on Motor Body (G))

S 1Light Switch Cover

QUNTITYDESCRIPTIONPART

HARDWARE CONTENTS (Not shown actual size)

Lowes.com/harborbreeze

SAFETY INFORMATION

READ AND SAVE THESE INSTRUCTIONS

Please read and understand this entire manual before attempting to assemble, operate or install the product.

. All electrical connections must comply with local codes, ordinances or the National Electric Code (NEC).

Contact your municipal building department to inquire about your local codes, permits and/or inspections.

. Turn off electricity at main fuse box (or circuit breaker box) before beginning installation by removing fuse

or by removing th fuse or by switching off circuit breaker.

. Do not connect this fixture to an electrical system that does not provide a means for equipment grounding.

Never use a fixture in a two-wire system that is not grounded.

. If you are not sure your lighting system has a grounding means, do not attempt to install this fixture. Contact

a qualified, licensed electrician for information regarding proper grounding methods as required by the local

electrical code in your area.

. Make sure the installation site you choose allows a minimum clearance of 7 ft. from the blades to the floor

and at least 30 in. from the ends of the blades to any obstruction.

. If a dimmer control switch is used with this fixture, obtain professional advice to determine the correct type

and electrical rating required.

. The lighting fixture must be positioned so there is at least 1.64 ft. between the bulb and any illuminated

surface.

. For supply connections, if the conductor of a fan is identified as a grounded conductor, then it should be

connected to a grounded conductor power supply. If the conductor of a fan is identified as an ungrounded

conductor, then it should be connected to an ungrounded conductor power supply. If the conductor of a fan

is identified for equipment grounding, then it should be connected to an equipment-grounding conductor.

. Installing a fixture into an electrical system without a proper grounding means could allow metal parts of the

fixture to carry electrical currents. If any of the fixture wires, wire connections or splices are broken, cut or

loose during the mounting or normal operation of the fixture, under such conditon, anyone coming in contact

with the fixture is subject to electrical shock, which could cause serious injury or death.

. Connection of the bare or green fixture ground wire to the black or white house wires may allow metal parts

of the fixture to carry electrical currents. Under this condition anyone coming in contact with the fixture will

receive electrical shock, which could cause serious injury or death.

. Be careful not to damage or cut the wire insulation (covering) during fixture installation. Do not permit wires

to have contact with any surface having a sharp edge. Doing so may damage or cut the wire insulation,

which could cause serious injury or death from electric shock.

DANGER

AA CC DD

Wire Nut

Qty. 4

Blade Screw

Qty. 18 + 1 Extra Motor Screw

Qty. 7 + 6 Extra Fob

Qty. 2

WARNING

CAUTION

PREPARATION

. Risk of fire. Most dwellings built before 1985 have supply wire rated for 140°F. Consult a qualified

electrician before installation.

. To reduce the risk of fire or electric shock, do not use this fan with any solid state fan speed device

or variable speed control.

. To reduce the risk of personal injury, do not bend the blade brackets when installing the brackets,

balancing or cleaning the fan.

. Do not insert foreign objects in between rotating fan blades.

. Do not install or use the fan if any part is damaged or missing.

. Before servicing or cleaning the unit, switch power off at the service panel and lock the service

disconnecting means to prevent power from being switched on accidentally. When the service

disconnecting means cannot be locked, securely fasten a prominent warning device, such as a tag,

to the service panel.

. Do not use bulbs having a wattage greater than the maximum value stated on the fixture and in this

manual. Using a higher wattage bulb than specified will increase fixture temperature and increase

risk of fire.

Before beginning assembly of product, make sure all parts are present. Compare parts with package

contents list and hardware contents list. If any part is missing or damaged, do not attempt to

assemble the product.

. To reduce the risk of fire, electric shock or personal injury, mount to outlet box marked

'ACCEPTABLE FOR FAN SUPPORT OF 35 LBS OR LESS' and use mounting screws provided

with the outlet box and/or support directly from building structure. Most outlet boxes commonly

used for the support of luminaries are not acceptable for fan support and may need to be replaced.

Consult a qualified electrician if in doubt.

Estimated Assembly Time: 45 minutes

Tools Required for Assembly (not included): Philips Screwdriver, Step Ladder, Tape, Pliers and Wire

Cutters.

Lowes.com/harborbreeze

INITIAL INSTRUCTIONS

1. Turn off circuit breakers and wall switch to the fan supply

line leads.

Lowes.com/harborbreeze

2b. It is required at least 30 inch from blade tip to nearest

wall or obstruction. Check downrod length to ensure 7

feet from bottom edge of blade to the floor.

A. Standard Mounting: Standard mounting is best

suited for ceilings 8 ft. or higher. For taller ceilings you

may want to use a longer downrod (not included).

B. Angle Mounting: Angle-style mounting is best

suited for angled or vaulted ceilings. A longer downrod

is sometimes necessary to ensure proper blade

clearance. If using the angle mount, make sure the

ceiling angle is not steeper than 20°.

2a. Choose the desired mounting method:

Note: Flushmount and closemount options are not

available for this item.

DANGER: Failure to disconnect power supply prior to

installation may result in serious injury or death.

7 ft. MIN.

30 IN. MIN.

3. Check existing outlet box (not included) to ensure it is

securely fastened to at least two points in a structural

ceiling member and can support the full weight of the

fan. Once verified, install mounting bracket (A) to the

outlet box using the screws and washers provided with

the outlet box.

INITIAL INSTRUCTIONS

Lowes.com/harborbreeze

4. Remove the motor body (G) from the protective plastic

bag and take the lower packing pad out of the carton.

Place the motor body (G) into the packing pad with the

bottom of each motor facing up. Remove the motor

screws (CC) and motor blocks from each motor of motor

body (G). Discard motor blocks and save the motor

screws (CC) for later use.

Hardware Used

x 6

Motor Screw

5. Remove hairpin clip (V) and clevis pin (U) from the top

housing (F) preassembled to motor body (G). Retain for

later use.

Open End

Note: If using the angel mount, make sure open end of

mounting bracket (A) is installed facing the higher point

of the ceiling.

Note: Make sure to keep loose hardware separate to

avoid confusion during installation

Note: Make sure to keep loose hardware separate to

avoid confusion during installation.

Loosen the two screws preassembled in coupling on top

housing (F), but do not remove them.

DANGER: A loose outlet box can cause the fan to

wobble and increase the fan's potential to fall, which

could result in serious injury or death.

Motor Block

Screw

6 to 9 in

INITIAL INSTRUCTIONS

Lowes.com/harborbreeze

7. Feed power wires from motor body (G) through downrod

assembly (B), then insert downrod assembly (B) into the

coupling on top housing (F).

Align the hole on downrod assembly (B) to hole on

coupling, then re-install clevis pin (U). Re-attach hairpin

clip (V) into clevis pin (U) until it snaps into place, then

tighten the two previously loosened screws on coupling.

8. Cut off excess fixture wires, leaving approximately 6 to 9

inches above the top of the downrod assembly (B). Strip

1/2 inch insulation from the end of each fixture wire.

CAUTION: Ensure all screws are tight before moving

onto the next step.

6. Place downrod assembly (B) through canopy (C),

canopy cover (D) and coupling cover (E).

Screw

Lowes.com/harborbreeze

INITIAL INSTRUCTIONS

WIRING INSTRUCTIONS

WARNING: To avoid possible electrical shock, be sure electricity is turned off at the main fuse

box before hanging.

WARNING: If you are not sure if the outlet box is grounded, contact a licensed electrician for

advice, as it must be grounded for safe operation.

1. Connect the GREEN wires from the hanger ball of

downrod assembly (B) and mounting bracket (A) to the

supply ground (GREEN or bare color). Securely connect

wires using wire connector (AA) supplied.

WARNING: If house wires are different colors than referred to in the following steps, stop

immediately. A professional electrician is recommended to determine proper wiring.

WARNING: If you feel that you do not have enough electrical wiring knowledge or experience,

have your fan installed by a licensed electrician.

9. Carefully lift the assembly and rest the hanger ball of

downrod assembly (B) on the mounting bracket (A)

attached to the outlet box.

NOTE: Unlike a standard circular fan, the mounting

bracket (A) for this item does not have a tab, which

locks the fan into a specific position. This allows you

the freedom to rotate the fan's linear motor housing

360°so it can be correctly oriented with the layout of

your room.

Hardware Used

x 1

Wire Connector

Supply

Ground Wire

Green Wire

from A

Green Wire from

Hanger Ball

WIRING INSTRUCTIONS

FINAL INSTRUCTIONS

1. Loosen but do not remove the two preassembled

mounting screws on mounting bracket (A). Lift canopy

twist canopy (C) clockwise. Tighten mounting screws

securely.

Lowes.com/harborbreeze

2. Securely connect the fan WHITE wire to the supply

WHITE wire using wire connector supplied. Securely

connect the fan BLACK and BLUE wires to the supply

BLACK wire using wire connector supplied.

3. Wrap electrical tape (not included) around each wire

connector and make sure no bare wire or wire strands

are visible after making connections.

Then, turn wires upward and carefully push them into

the outlet box; make sure the WHITE and GREEN

connections are on one side and the BLACK connections

are on the other side.

Hardware Used

x 2

Wire Connector

Black

Fan Wire

Blue

Fan Wire

BLACK

GREEN

WHITE

White

Fan Wire

BLACK

BLUE

WHITE

GREEN

Outlet Box

Table of contents

Other Harbor Breeze Fan manuals

Harbor Breeze

Harbor Breeze CHESHIRE II CSD52FBZ5C4S User manual

Harbor Breeze

Harbor Breeze 35061 User manual

Harbor Breeze

Harbor Breeze 41239 User manual

Harbor Breeze

Harbor Breeze BARNSTAPLE BAY E-RLG52NWZ5C User manual

Harbor Breeze

Harbor Breeze BOD52MW3 User manual

Harbor Breeze

Harbor Breeze EXOCET 40764 User manual

Harbor Breeze

Harbor Breeze TOWNSEND LP8018LAZ User manual

Harbor Breeze

Harbor Breeze TIEMPO E-TM52BNK5CS User manual

Harbor Breeze

Harbor Breeze KITSILANO User manual

Harbor Breeze

Harbor Breeze CHESHIRE II User manual

Harbor Breeze

Harbor Breeze 872 User manual

Harbor Breeze

Harbor Breeze LP8115LAZ User manual

Harbor Breeze

Harbor Breeze WCK52NWZ5D User manual

Harbor Breeze

Harbor Breeze AERO CEILING FAN E-AER52BRZ5LKRCI User manual

Harbor Breeze

Harbor Breeze WO52BB5C User manual

Harbor Breeze

Harbor Breeze 00728 User manual

Harbor Breeze

Harbor Breeze CLASSIC STYLE 00819 User manual

Harbor Breeze

Harbor Breeze 40107 User manual

Harbor Breeze

Harbor Breeze CLASSIC STYLE BDB52LW5N User manual

Harbor Breeze

Harbor Breeze CALERA 00830 User manual

Harbor Breeze

Harbor Breeze MAZON MZ44MBK3LR User manual

Harbor Breeze

Harbor Breeze 40048 User manual

Harbor Breeze

Harbor Breeze Bath Ventilator with Light User manual

Harbor Breeze

Harbor Breeze KEYPORT HUGGER 40141 User manual

Popular Fan manuals by other brands

ELTA FANS

ELTA FANS H03VV-F installation guide

Hunter

Hunter 20714 Owner's guide and installation manual

Emerson

Emerson CARRERA VERANDA CF542ORB00 owner's manual

Hunter

Hunter Caraway Owner's guide and installation manual

Panasonic

Panasonic FV-15NLFS1 Service manual

Kompernass

Kompernass KH 1150 operating instructions

VES

VES FALA100/12V/TR Original instructions

Vertiv

Vertiv Liebert DCD user manual

Westinghouse

Westinghouse GFP Series owner's manual

Venmar

Venmar KUBIX HRV PLUS Series user guide

Maico

Maico ECR 31 installation instructions

Sonnenkonig

Sonnenkonig Dinky instruction manual

S&P

S&P ECOWATT HXBR manual

Wider

Wider IMP03369BH instruction manual

Panasonic

Panasonic F-60DHN Operating and installation instructions

Hinkley

Hinkley HIGHLAND instruction manual

Broan

Broan 766BN installation guide

Premium

Premium PFS16022 Use manual
