Hamilton Beach 14010 User manual

Irons

Fer à repasser

Planchas

840182703

Le invitamos a leer cuidadosamente este

instructivo antes de usar su aparato.

READ BEFORE USE

À LIRE AVANT UTILISATION

LEA ANTES DE USAR

English ......................................................................................... 2

USA: 1-800-851-8900

Visit www.hamiltonbeach.com for our complete line of products and Use and Care

Guides – as well as delicious recipes, tips, and to register your product online!

Français ..................................................................................... 15

Canada : 1-800-267-2826

Rendez-vous sur www.hamiltonbeach.ca pour notre liste complète de produits et de nos

manuels utilisateur – ainsi que nos délicieuses recettes, nos conseils et pour enregistrer

votre produit en ligne !

Español ...................................................................................... 27

En México: 01-800-71-16-100

¡Visite www.hamiltonbeach.com.mx para obtener nuestra línea completa de productos y

las Guías de Uso y Cuidado, además de deliciosas recetas, consejos y para registrar su

producto en línea!

840182703 ENv01.indd 1840182703 ENv01.indd 1 10/2/12 2:41 PM10/2/12 2:41 PM

When using an iron, basic precautions should always be followed,

including the following:

READ ALL INSTRUCTIONS BEFORE USING

1. Only use an iron for its intended use.

2. To avoid the risk of electric shock, do not immerse the iron

in water or other liquids.

3. Always turn the iron to OFF (O) before plugging or unplugging

the iron from the electrical outlet. Never pull on the cord to

disconnect the iron from the electrical outlet; instead, grasp

the plug and pull on the plug to disconnect the iron.

4. Do not let the cord touch hot surfaces. Let the iron cool

completely before putting the iron away. Loop cord loosely

around iron when storing.

5. Always disconnect the iron from the electrical outlet before

filling the iron with water, emptying the water from the iron,

and when the iron is not in use.

6. Do not operate the iron with a damaged cord or in the event

the iron has been dropped or damaged or there are visible signs

of damage or it is leaking. To avoid the risk of electric shock,

do not disassemble the iron. Take it to a qualified serviceman for

examination and repair. Incorrect assembly might result in a risk

of electric shock when the iron is used after reassembly.

7. The iron must be used and rested on a stable surface.

8. When placing the iron on its stand, ensure that the surface

on which the stand is placed is stable.

9. Close supervision is required for any appliance used by or near

children. Do not leave the iron unattended while the iron is

connected or on an ironing board.

10. Burns can occur from touching hot metal parts, hot water, or

steam. Use caution when you turn a steam iron upside down—

there might be hot water in the reservoir.

11. To avoid a circuit overload, do not operate an iron on the same

circuit with another high-wattage appliance.

IMPORTANT SAFETY INSTRUCTIONS

840182703 ENv01.indd 2840182703 ENv01.indd 2 10/2/12 9:42 AM10/2/12 9:42 AM

This appliance is intended for household use only.

WARNING! Shock Hazard: This appliance has a polarized plug (one

wide blade) that reduces the risk of electric shock. The plug fits only

one way into a polarized outlet. Do not defeat the safety purpose of

the plug by modifying the plug in any way or by using an adapter.

If the plug does not fit fully into the outlet, reverse the plug. If it still

does not fit, have an electrician replace the outlet.

Use the iron on an ironing board. Ironing on any other surface may

damage that surface.

Do not iron or vertical steam clothes that are being worn.

Do not use vertical steam in the direction of people or pets.

Please Read Before First Use:

• During first use of the iron, it may appear to smoke. This will stop

and does not indicate a defect or hazard.

• Many irons spit or sputter during the first few uses with tap water.

This happens as the steam chamber becomes conditioned. This

will stop after a few uses.

• To clean steam vents before first use, prepare iron for steam

ironing; then iron over an old cloth for a few minutes while letting

the iron steam. Press the Blast of Steam button several times

to clean the vents. Then follow the Self-Cleaning instructions on

page 11.

SAVE THESE INSTRUCTIONS

12. If an extension cord is absolutely necessary, a cord with an

ampere rating equal to or greater than the maximum rating of

the iron shall be used. A cord rated for less amperage can result

in a risk of fire or electric shock due to overheating. Care shall

be taken to arrange the cord so that it cannot be pulled or be

tripped over.

Other Consumer Safety Information

840182703 ENv01.indd 3840182703 ENv01.indd 3 10/2/12 9:42 AM10/2/12 9:42 AM

Parts and Features

MAX

Steam

OFF

Position

Steam

Position

Blast of

Steam Button

Water Fill

Opening

Adjustable

Steam

Control

Blast of

Steam Button

Self-Clean

Swivel

Power

Cord

Heel Rest

Temperature

Control Dial

Soleplate

Spray

Trigger

Power On

Light

840182703 ENv01.indd 4840182703 ENv01.indd 4 10/2/12 9:42 AM10/2/12 9:42 AM

This iron is equipped with a position/motion sensor. This

means that if the iron is left motionless it will turn off

automatically and cool to room temperature.

To restart iron, simply move the iron and allow it to reheat

on heel position.

The iron will reheat to the previously selected setting.

Iron Position

Resting on soleplate

Resting on either

side

Resting on heel

Sensor Control (available on some models)

Position Sensing

The iron will turn off automatically when left in the following

positions.

The auto off time varies based on the iron’s position.

Auto Shutoff Reset Light

After 30 seconds of no movement in the horizontal position,

the iron will automatically shut off and the red light will blink.

Move iron upright to vertical position to turn back on.

Motionless Time

30 seconds

30 seconds or

15 minutes

depending on

exact orientation

15 minutes

840182703 ENv01.indd 5840182703 ENv01.indd 5 10/2/12 9:42 AM10/2/12 9:42 AM

1. Plug the iron into outlet.

2. Set Adjustable Steam Control to

0 (Dry Iron).

3. Turn Temperature Control Dial to

desired temperature. Allow 2 minutes

for iron to reach desired temperature.

4. To turn iron off, turn Temperature

Control Dial to OFF and unplug iron.

To Dry Iron

Iron

High Temp

Setting Med Temp

Setting Low Temp

Setting

Fabric care labels on garments have symbols that show

ironing instructions and recommended temperature settings.

These symbols are shown below along with their meaning.

Do Not

Iron Do Not

Use Steam

DRY IRON: Synthetics, Silk/Wool (reverse side of fabric)

STEAM IRON:

Cotton (while damp; use steam or spray)

Linen (while damp on reverse side of fabric)

NOTE: To prevent possible garment damage, we do not

recommend ironing fabrics labeled “Dry Clean Only.”

Fabric Care Label Symbols

840182703 ENv01.indd 6840182703 ENv01.indd 6 10/2/12 9:42 AM10/2/12 9:42 AM

1. Unplug iron. Set Adjustable Steam Control to 0 (Dry Iron).

Hold iron with soleplate parallel to the ground.

2. Using a cup, slowly pour tap water into water fill opening

until MAX fill line is reached. Do not fill iron directly from

the faucet.

3. Plug iron into outlet.

4. Turn Temperature Control Dial to desired fabric setting in

the steam range.

5. Allow 2 minutes for the iron to reach

desired temperature.

6. Set Adjustable Steam Control to

desired steam setting.

7. To turn iron off, set Set Adjustable

Steam Control to 0 (Dry Iron). Turn

the Temperature Control Dial to OFF.

Unplug iron.

8. Empty water from the iron following directions in “Care

and Cleaning.”

Water: Please use ordinary tap water. If you have extremely

hard water, alternate between tap water and distilled water

for use in the iron.

To Steam Iron

840182703 ENv01.indd 7840182703 ENv01.indd 7 10/2/12 9:42 AM10/2/12 9:42 AM

1. Follow Steps 1 through 5 in

“To Steam Iron.”

2. Hang garment in a location that is

not susceptible to damage from heat

or moisture. Do not hang in front of

wallpaper, window, or mirror.

3. Hold iron about 6 inches (15 cm) away

from garment and press and release

the Blast of Steam Button to steam out

wrinkles. Do not press Blast of Steam

Button more than once every 5 seconds.

4. To turn iron off, turn Temperature Control Dial to OFF.

Unplug iron.

5. Empty water from the iron following directions in “Care

and Cleaning.”

NOTICE: Do not allow hot soleplate to touch delicate

garments.

To Vertical Steam

840182703 ENv01.indd 8840182703 ENv01.indd 8 10/2/12 9:42 AM10/2/12 9:42 AM

Power On Light

The red light stays on even

if Temperature Control Dial

is turned to OFF. Light flashes

if position sensor is activated.

Blast of Steam Button

Push Blast of Steam Button for

an extra blast of steam.

Adjustable Steam Control

This control adjusts the steam

to desired steam level.

Features

840182703 ENv01.indd 9840182703 ENv01.indd 9 10/2/12 9:42 AM10/2/12 9:42 AM

Care and Cleaning

Iron Storage

1. The water tank of your iron should be emptied after each

use. Turn Temperature Control Dial to OFF. Unplug the

iron and hold over a sink. Slowly tilt pointed end of iron

down over sink. Water will run out of water fill opening.

2. After iron has completely cooled, wrap cord loosely around

iron and store in an upright position. Do not store iron

laying flat on soleplate.

Soleplate

1. Never iron over zippers, pins, metal rivets, or snaps, since

these may scratch the soleplate.

2. To clean occasional buildup on the soleplate, wipe with

a sudsy cloth. Do not use abrasive cleansers or metal

scouring pads.

3. Always store iron upright in the heel rest position.

Spray Trigger

Press Spray Trigger to release

a fine spray of water for difficult

wrinkles in cotton or linen.

Features (cont.)

840182703 ENv01.indd 10840182703 ENv01.indd 10 10/2/12 9:42 AM10/2/12 9:42 AM

Other manuals for 14010

This manual suits for next models

Table of contents

Languages:

Other Hamilton Beach Iron manuals

Hamilton Beach

Hamilton Beach Steam Elite 14011 Instruction sheet

Hamilton Beach

Hamilton Beach 14431 - Smart Grip Iron Owner's manual

Hamilton Beach

Hamilton Beach 14963 User manual

Hamilton Beach

Hamilton Beach QuickGlide 14353 Instruction sheet

Hamilton Beach

Hamilton Beach 14010 Owner's manual

Hamilton Beach

Hamilton Beach 14525 User manual

Hamilton Beach

Hamilton Beach HIR200R User manual

Hamilton Beach

Hamilton Beach 840129100 User manual

Hamilton Beach

Hamilton Beach Easy Touch Iron User manual

Hamilton Beach

Hamilton Beach 14600 Programming manual

Hamilton Beach

Hamilton Beach 14525 User manual

Hamilton Beach

Hamilton Beach Durathon 19803 Owner's manual

Hamilton Beach

Hamilton Beach HIR800 User manual

Hamilton Beach

Hamilton Beach Durathon 19800 User manual

Hamilton Beach

Hamilton Beach 840164201 User manual

Hamilton Beach

Hamilton Beach 840127400 User manual

Hamilton Beach

Hamilton Beach 14506 Owner's manual

Hamilton Beach

Hamilton Beach 19804 Owner's manual

Hamilton Beach

Hamilton Beach 14401 User manual

Hamilton Beach

Hamilton Beach DURATHON User manual

Hamilton Beach

Hamilton Beach 14210 Owner's manual

Hamilton Beach

Hamilton Beach 840043400 Installation instructions

Hamilton Beach

Hamilton Beach 14515R User manual

Hamilton Beach

Hamilton Beach 14565 - Lightweight Iron Owner's manual

Popular Iron manuals by other brands

Clatronic

Clatronic DB 3703 instruction manual

TEFAL

TEFAL FV4093Z0 manual

Gorenje

Gorenje SIH 2200 BS instruction manual

Philips

Philips GC6012 Service manual

Bosch

Bosch 2 Series operating instructions

Riffel

Riffel Catena KB-819 instruction manual

Texi

Texi Hestia Instructions for use

Maxwell

Maxwell MW-3010 Manual instruction

TREVIDEA

TREVIDEA Girmi ST60 user manual

Philips

Philips HI5914/30 quick start guide

Primula

Primula Vapormat instruction manual

Magio

Magio MG-541 manual

Scarlett

Scarlett SC-1334S instruction manual

Bosch

Bosch Sensixx B22L manual

Philips

Philips GC651 Specifications

Vitek

Vitek VT-1247 VT Manual instruction

Cleanmaxx

Cleanmaxx 3397 instruction manual

Philips

Philips GC800 user manual
