Haier XQB60-91BF User manual

Automatic

Washing Machine

User Manual-

Guide de l’Utilisateur-

Manual del Usuario-

Model #

Modèle

Para Modelo de

XQB60-91BF

Lavadora Automática

Lave-Linge

Automatique

XQB60-91BF MANUAL 10/22/01 11:42 AM Page 1

IMPORTANT SAFETY INSTRUCTIONS

Warning – To reduce the risk of fire, electric shock, or injury

to persons when using your appliance, follow basic

precautions, including the following:

1. Read all instructions before using the appliance.

2. Use this appliance only for its intended purpose as described in this use and

care guide.

3. Use only detergents or softeners recommended for use in this appliance and

keep them out of the reach of children.

4. This appliance must be properly installed in accordance with the installation

instructions before it is used.

5. Never unplug your appliance by pulling on the power cord. Always grasp the

plug firmly and pull straight out from the outlet.

6. Replace immediately worn power cords, loose plugs/power outlets.

7. Unplug your appliance before cleaning or before making any repairs.

8. If your old appliance is not being used, we recommend that you

remove the door. This will reduce the possibility of danger to children.

9. Do not operate your appliance in the presence of explosive fumes.

10. Do not use this appliance to wash clothes soaked, spotted or washed in

gasoline, dry cleaning solvents or any other explosive or flammable substances

that could ignite and explode.

11. Clothes or rags used to clean flammable or explosive materials should not be

washed in this appliance till all traces of this material has been removed, to

avoid an accident.

12. Do not add or mix any flammable or explosive substances to the wash.

13. Do not try to remove clothes while the tub is moving. Let it come to a complete

stop before use.

14. The appliance loading door must be closed when tub is spinning.

15. Do not operate your appliance when parts are missing or parts are broken.

16. Do not use this appliance for commercial clothes washing.

17. Do not operate this appliance unless all enclosure panels are properly in place.

18. Do not tamper with controls.

19. To reduce risk of injury do not allow children to play in or on the appliance.

Close supervision of children is necessary when the appliance is used

near children.

English

XQB60-91BF MANUAL 10/22/01 11:42 AM Page 2

20. This appliance must be connected to proper electrical outlet with the correct

electrical supply.

21. Proper grounding must be ensured to reduce the risk of shock and fire. DO

NOT CUT OR REMOVE THE GROUNDING PLUG. If you do not have a

three-prong electric receptacle outlet in the wall, have a certified electrician

install the proper receptacle. The wall receptacle MUST be properly grounded.

22. Hydrogen gas may be produced if the water heater has not been used in more

then 2 weeks. This could be explosive and can explode under certain

circumstances. If this is the case, before using this appliance turn on all the hot

faucets and let the hot water run for a few minutes. This will let the trapped

hydrogen escape. During this process do not turn on an electric appliance,

smoke, light a match/lighter or use a flame to avoid an accident, as hydrogen

gas is flammable and can explode.

23. Do not repair or replace any part of the appliance or attempt any servicing

unless specifically recommended in the user-repair instructions that you

understand and have skills to carry out.

24. To reduce the risk or electric shock or fire, do not use extension cords or

adapters to connect the unit to electrical power source.

SAVE THESE INSTRUCTIONS

English

DANGER

Risk of child entrapment. Before you throw away your old

appliance, take off the door so that children may

not easily get trapped inside.

Thank you for purchasing our Haier

product. This easy-to-use manual will

guide you in getting the best use of

your washer.

Remember to record the model and

serial number. They are on a label in

back of the washer.

Model number

Serial number

Date of purchase

Staple your receipt to your manual. You will need it to obtain

warranty service.

XQB60-91BF MANUAL 10/22/01 11:42 AM Page 3

Table Of Contents

PAGE

SAFETY INSTRUCTIONS....................................................................1

Understanding Your “Hand Wash” Washer..............................................4

OPERATING INSTRUCTIONS............................................................5

Parts and Features..............................................................................5-6

Operations ............................................................................................7

Normal Operating Sounds....................................................................16

Care and Cleaning Guide ............................................................17

Cleaning and Maintenance ..................................................................17

Moving and Vacationing ......................................................................18

Storage of Your Washer ......................................................................18

Troubleshooting..............................................................................19

INSTALLATION INSTRUCTIONS ....................................................22

Tools and Materials Required................................................................22

Unpacking Your Washer ......................................................................23

Leveling Your Washer ..........................................................................23

Steps for Installation ............................................................................24

Installing Quick Sink Adapter................................................................26

Electrical Connections ....................................................................28

Grounding Instructions..........................................................................28

Power Interruptions ..............................................................................28

Warranty ........................................................................................29

English

XQB60-91BF MANUAL 10/22/01 11:42 AM Page 4

Understanding Your "Hand Wash"Washer

Hand-Wash System:

The convenient top loading format with no central agitator gives you more usable

space and cleans your clothes gently. The special designed pulsator at the bottom of

the washer creates a cascading motion to gently lift and bounce clothes through a

continuous waterfall. Because of this unique wash motion of the pulsator, you can

wash many delicate washables that you previously might have washed by hand.

Cascading Water Fall:

Series of small water falls moving through the clothes in clockwise direction going

from lower surface to upper surface removing soil and residue from the clothes to

give the best cleaning result.

Omni-Direction Flow:

To give you the optimum cleaning result for your clothes, the pulsator moves in both

clockwise and counter clockwise direction every couple of seconds throughout the

wash cycle. Your clothes are being folded and unfolded during this process to

remove the soil and stain out of your clothes. This gentle, but effective process

protects your clothes from wear and tear.

Pendulum Wash:

The water is being sprayed from the left to right direction during the wash and rinse

cycle to give you the best cleaning results for your clothes.

English

XQB60-91BF MANUAL 10/22/01 11:42 AM Page 5

English

1. Folding Top Lid

2. Detergent/Softener Dispenser

3. Control Panel

4. Balance Display (Leveling Indicator)

5. Lint Filter

6. Pulsator

7. Washer Cabinet

8. Front Leveling Legs

9. Inner Tub

10. Cabinet Handle (Located on both

sides of the washer)

OPERATING INSTRUCTIONS

Parts and Features

XQB60-91BF MANUAL 10/22/01 11:42 AM Page 6

English

1. Cold Water Inlet Valve

2. Hot Water Inlet Valve

3. Drain Hose Connection

4. Rear Leveling Legs

5. Power Cord (115 Volt / 60 Hz)

6. Power Cord Holder Clip

XQB60-91BF MANUAL 10/22/01 11:42 AM Page 7

WARM/COLD

COLD/COLD

HOT/COLD

English

Understanding the Control Panel

OPERATIONS

WARM/COLD

COLD/COLD

HOT/COLD

8 37 6 5 4

Power Button: (1)

•Press the button once to operate the washer. Press the button once again to turn

the washer "OFF".

Start/Pause Button: (2)

•Press this button once to start the wash process. Press this button once again to

pause the activity during the wash cycle. (See pg. 14 under "Start/Pause Button"

section for more details)

XQB60-91BF MANUAL 10/22/01 11:42 AM Page 8

English

Select Button: (3)

•"Select Button" will let you select your desired cycle program. There

are four options to select from in this mode: Soak, Wash, Rinse and Spin.

Simply press the select button to go up and down. (See pg. 12 under

"Wash Cycle Options" section for more details)

Wash Cycle Button: (4)

•"Wash Cycle" button will let you select your desired wash cycles. For your

convenience, there are four fabric care wash cycles programmed in this mode:

Normal, Synthetic, Gentle and Quick. (See pg. 11-12 under "Selecting Wash

Cycle" section for more details)

Delay Start Button: (5)

•This convenient feature lets you delay the start of the wash cycle between

2 to 24 hours. Press the "Delay Start" to choose the number of hours you

want to delay the start of the cycle. (See pg. 15 under "Delay Start Button"

section for more details)

Current Button: (6)

•This button allows you to select current level from Soft to Strong position for

selected cycles. Press the current button to go up and down the levels. (See pg. 12

under "Selecting Current Level" section for more details)

Water Level Button: (7)

•Press the button to go up and down to select the proper water level setting

option.For your convenience, you can select from 1 to 10 water level setting

depending upon the cycle type. (See pg. 13 under "Selecting Water Level"

section for more details)

Temperature Select Button: (8)

• You can select your desired temperature depending upon the fabric

types by simply pressing the "Temp Select" button to go up and down to

select the proper option. For your convenience, there are three temperature

options: Cold/Cold, Warm/Cold and Hot/Cold. (See pg. 14 under

"Selecting Wash/Rinse Temperature" section for more details)

Balance Display (Leveling Indicator): (9)

•Balance Display is located at the front top on the upper left corner. This display

shows if the washer is leveled properly. (See pg. 23 under "Balance Display"

section for more details)

XQB60-91BF MANUAL 10/22/01 11:42 AM Page 9

English

Understanding the Function Light Indicator:

•The function "display light" indicates selected feature is "ON" or the

cycle is about to begin.

• During the wash cycle, "flashing light" indicates current running program.

•Rapidly flashing light indicates that the washer is not operating properly.

Note: Refer to troubleshooting guide for "Error Code" explanation.

Loading the Washer:

• Load each item loosely.

•Separate the white and colored clothes. Separate heavy fabrics from light fabrics.

•Carefully check all pockets and cuffs for small items. They can easily slide in to the

tub and may damage the tub.

• Pre-treat all stains and heavily soiled areas for best results.

• Do not overload your washer.

•Close the door properly after loading the clothes.

•When loading wet items, keep water level high enough so items can float easily in

the water and unit may not go off balance.

Proper Use of Dispenser:

The detergent dispenser is located inside the washer at the upper middle center part

of the drum under the washer door. Open the dispenser by pulling it out. You will

see that there are two compartments.

Right Compartment: This is used for fabric softener.

Left Compartment: This is used for wash detergent.

Note: The detergent will be mixed with the water automatically during the

cycle at the proper time.

Right CompartmentLeft Compartment

XQB60-91BF MANUAL 10/22/01 11:42 AM Page 10

Other manuals for XQB60-91BF

Table of contents

Languages:

Other Haier Washer manuals

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Electrolux

Electrolux EWF1284EDW Service manual

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide
