Haier HWF95AN1 User manual

HWF95AN1

HWF85AN1

HWF75AN1

NZ AU

HWF85ANB1

HWF95ANB1

Thank You NZ AU

Legend

Warning – Important Safety information

General information and tips

Environmental information

Disposal

Thank you for purchasing a Haier Product.

Keep this manual in a convenient place so you can always refer to it for the safe and proper

use of the appliance.

If you sell the appliance, give it away, or leave it behind when you move house, make sure

you also pass this manual so that the new owner can become familiar with the appliance

and safety warnings.

WARNING!

of it. Remove the door catch to prevent children and pets to get closed in the appliance.

Please read these instructions carefully before using this appliance. The instructions

contain important information which will help you get the best out of the appliance and

ensure safe and proper installation, use and maintenance.

Help protect the environment and human health. Put

the packaging in applicable containers to recycle it.

Help to recycle waste of electrical and electronic

appliances.Donot dispose appliances marked with this

symbol with the household waste. Return the product

to your local recycling facility or contact your municipal

NZ AU Content

1-Safety information........................................................................................................................... 4

2-Product description......................................................................................................................... 7

3-Control panel .................................................................................................................................... 8

4- 11

6-Consumption..................................................................................................................................13

5-Programmes ..................................................................................................................................12

7-Daily use ...........................................................................................................................................14

8-Eco-friendly washing ....................................................................................................................19

9-Care and cleaning ..........................................................................................................................20

10-Troubleshooting .......................................................................................................................... 23

11-Installation.....................................................................................................................................26

12-Technical data...............................................................................................................................30

13-Customer service........................................................................................................................31

WiFi connection & Remote mode.............................................................................................

1-Safety information NZ AU

Bef -

ing safety hints!

WARNING!

Make sure there is no transport damage.

Make sure all transport bolts are removed.

Remove all packaging and keep out of children´s reach.

Handle the appliance always with at least two persons because it

is heavy.

Daily use

▶

Children shall not play with the appliance.

Do not let children or pets come close to the appliance when the

door is open.

Store washing agents out of reach of children.

prevent laundry from being entangled. If necessary, use an

bag or net.

Do not touch or use the appliance when barefoot or with wet or

damp hands or feet.

Do not cover or encase the appliance during operation or

to allow any moisture or dampness to evaporate.

Do not place heavy objects or sources of heat or damp on top of

the appliance.

Do not use or store ﬂammable detergent or dry cleaning agent in

close vicinity to the appliance.

Do not use any ﬂammable sprays in close vicinity to the appliance.

Do not wash any garments treated with solvents in the appliance

without having dried them previously in the air.

appropriate

afterwards

This appliance is not intended for use by persons (including child-

ren) with reduced physical,sensory or mental capabilities, or lack

of experience and knowledge, unless they have been given super-

vision or instruction concerning use of the appliance by a person

responsible for their safety.

Children should be supervised to ensure that they do not play with

the appliance.

NZ AU 1-Safety information

WARNING!

Daily use

▶Do not remove or insert the plug in the presence of ﬂammable

gas.

▶Do not hot wash foam rubber or sponge-like materials.

▶Do not wash any laundry which is polluted with ﬂour.

▶Do not open detergent drawer during any wash cycle.

▶Do not touch the door during the washing process, it gets hot.

▶Do not open the door if the water level is visibly over the porthole.

▶Do not force the door to open. The door is tted with a self-lock

device and will open shortly after the washing procedure is ended.

▶

undertaking any routine maintenance and disconnect the appli-

ance from the electrical supply to save electricity and for safety.

▶Hold the plug, not the cable, when unplugging the appliance.

Maintenance / cleaning

▶Make sure children are supervised if they carry out cleaning and

maintenance.

▶Disconnect the appliance from the electrical supply before

undertaking any routine maintenance.

▶Keep the lower part of the porthole clean and open door and

detergent drawer if appliance is not in use to prevent odours.

▶Do not use water spray or steam to clean the appliance.

▶

▶Do not try to repair the appliance by yourself. In case of repair

please contact our customer service.

Installation

▶The appliance should be placed in a well-ventilated place. Ensure

a location which allows opening the door fully.

▶Never install the appliance outdoors in a damp place, or in an area

which may be prone to water leaks such as under or near a sink

unit. In the event of a water leak cut power supply and allow the

machine to dry naturally.

Replace a damaged supply cord only by the manufacturer, its

ser

hazard.

1-Safety information NZ AU

Intended use

This appliance is intended for washing machine-washable laundry

only. Anytime follow the instructions given on the label of each

garment label. It is designed exclusively for domestic use inside the

house. It is not intended for commercial or industrial use.

use may cause hazards and loss of all warranty and liability claims.

WARNING!

Installation

▶Install or use the appliance only where the temperature is above

5 °C.

▶Do not place the appliance directly on a carpet, or close to a wall

or furniture.

▶Do not install the appliance in direct sunlight or in the near of heat

sources(e.g. stoves, heaters).

▶Make sure that the electrical information on the rating plate

agrees with the power supply. If

does

not, contact an

electrician.

▶Do not use multi-plug adapters and extension cables.

▶Make sure only the delivered electric cable and hose set are used.

▶Make sure not to damage the electric cable and the plug. If

damaged have it replaced by an electrician.

▶Use a separate earthed socket for the power supply which is easy

accessible after installation. The appliance must be earthed.

▶

no leakage.

▶The new hose-sets supplied with the appliance are to be used

and that old hose-sets should not be reused.

The manual are suitable for 7.5kg, 8.5kg, 9.5kg washing machines.

The applicable water pressure of the washing machine is 0.03MPa

to 1MPa.

▶

NZ AU 2-Product description

2.1 Picture of appliance

Front (Fig. 2-1): Rear side (Fig. 2-2):

2.2 Accessories

Check the accessories and literature in accordance with this list (Fig.2-3):

Note:

2-3

1 Detergent /

Softener drawer

2 Work top

3 Programme selector

4 Panel

5 Washer door

6 Service ﬂap

7 Adjustable feet

2-1 2-2

Inlet hose-

assembly 5 Blanking

plugs

Drain hose

bracket User manual

Warranty

card

Noise reduc-

tion pads

Stain removal

Delay

Steam

Extra Rinse

Speed

Temp.

Outdoor

Spin

Cotton Synthetics Wool

Express 15’

Refresh

MixBabycare

Duvet

Eco 40-60Cotton 20

Delicate

Fast

REFRESH

525DRUM

256

12 3 4

1 Transportation bolts

2 Back cover

3 Back cover screws

4 Power cord

5 W

Drain hose

ater inlet valve

T1 T2

T3 S1

S3 S5

Refresh

3-1

3-2

3-3

3-4

NZ AU

take HWF95AN1 as an example

Refresh

Press to turn the washer ON/OFF.

Press and hold the Power button for ﬁve seconds

until the power is turned on and the APP will be displ-

ayed on the screen to turn on the network function.

Temp: Select washing temperature

Soak: Select the number of soak

Sanitise: Select sanitise function

Speed up: Select diﬀerent speed as needed

ECO: Touch to select energy saving mode

Spin Speed: Touch to select diﬀerent speeds

3.5 Function buttons

lanoitiddaelbane)6-3.giF(snottubnoitcnufehT

options in the selected programme before programme

starts. The related indicators are displayed.

programme, all options are disabled.

If a button has multiple options, the desired option can

be selected by pressing the button sequentially.

By touching the buttons, when it is in dull light, the

function is unselected; when it is in bright light, the

function is selected.

3.5.1-Function button “TEMP. “

3.5.2 Function button “Soak”

Note: Factory settings

there is no special requirement default settings are recommended.

3.4 Detergent drawer

Open dispenser drawer,the following components can

be seen (Fig. 3-5):

1: compartment for powder or liquid detergent.

2: compartment for laundry aid products such as

powder stain removers and soaking agents.

3: compartment for softener.

4: lock tab, press it down to pull out dispenser drawer.

The recommendation on the type of detergents is

suitable for the various washing temperatures, please

refer to the manual of detergent (see P11).

Touch

this button (Fig. 3-8) to add a deep soak for to the wash. Select

the desired time by press soak, increase soak time(30min,60min,90min,

120min).

3.5.1 3.5.2 3.5.53.5.43.5.3

3-5

3-6

3-8

NE AU

MAX

3.5.6

3-7

Touch this button (Fig. 3-7) to change the washing temperature

of the programme. If no value is illuminated (the display"--°C")

the water will not be heated.

3-9

3.5.3 Function button “sanitise”

Touch this button (Fig. 3-9)

,sanitisation turns on during wash and rinses.

When selceting this function the temperature is set to 90°C .

Sanitisation

is by default ON in the Allergy programme.

By switching oﬀ the appliance or setting a new

3-Control panel NZ AU

3.7 Key lock

Press and hold Temp. and Soak combination

keys for

three seconds, the Keylock icon

(Fig. 3-14) lights up.

All buttons on control panel excepting the Power

buttons are disabled. Repeat the operation to release

the lock.

The display shows c oI

I- (Fig. 3-15) if a button is

pressed, when the key lock is activa

(Fig. 3-17).to acknowledge the

ted.

Speed

3-14

3-15

3.8 Favourite

Choosing a programme and then start,touch button“ Soak“

and ”Sanitise ” ( Fig .3-16) for 3 seconds simultaneously

to save personalised options for available programme, pa-

nel displays .

To return to the default options for the cycle,

dEf

Speed

3-16

3-17

Speed Up

3-10

Touch the button (

Fig. 3-11

) to reduce washing time.

3.5.4 Function button”Speed Up”

ECO

3-11

3.5.5 Function button”ECO”

Spin Speed

3-12

3.5.6 Function button”Spin Speed”

Touch the button (

Fig. 3-11

) to use the ECO option to

save water and energy.

Touch this button (Fig. 3-12) to change the spin speed

of the programme. If “ ” is selected, the laundry will

not spin.

3-13

3.6 “Start/Pause“ button

Touch this button (Fig. 3-13) gently to start or

the currently displayed programme. During programme

setting and during programme run the LED above the

button is shining, or if paused blinking.

When select” speed up” function, the weight of the laundry

is less than the normal weight.

press “Soak“ and “Sanitise“

for 3 seconds simultaneously,

the display will show “ ”

change.

pause

Other manuals for HWF95AN1

This manual suits for next models

Table of contents

Other Haier Washer manuals

Haier

Haier HA655TME User manual

Haier

Haier Thermocool HMS1000TVE User manual

Haier

Haier HW60-10636WNZP User manual

Haier

Haier HN800TX User guide

Haier

Haier HA600TX User manual

Haier

Haier HMS1002A User manual

Haier

Haier HWM55-26GS User manual

Haier

Haier XQS60-78H User manual

Haier

Haier HWM60-10866 User manual

Haier

Haier XQBM15-D User manual

Haier

Haier XPB60-113S User manual

Haier

Haier RWT350AW Assembly instructions

Haier

Haier B628TX Mounting instructions

Haier

Haier HLP21N Assembly instructions

Haier

Haier HWM90DD User manual

Haier

Haier HK1007TME User manual

Haier

Haier HWM108VA User manual

Haier

Haier HW80-F1401 User manual

Haier

Haier XPB55-23BS User guide

Haier

Haier XQB60-91AF User manual

Haier

Haier 39 Series User manual

Haier

Haier HLP23E - Electronic Touch Pulsator Ing Portable Washing... Assembly instructions

Haier

Haier Thermocool HMS1000TVE User manual

Haier

Haier HLP21E - Pulsator Wash With Tub User manual

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Electrolux

Electrolux EWF1284EDW Service manual

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide
