Haier HSU-09CU13 User manual

Edition:2006/1/18



Air Conditioner

OPERATION

Before disposing an old air conditioner that

goes out of use, please make sure it's

inoperative and safe.Unplug the air conditioner

in order to avoid the risk of child entrapment.

It must be noticed that air conditioner system

contains refrigerants, which require speciali-

zed waste disposal.The valuable materials

contained in an air conditioner can be recycled.

Contact your local waste disposal center for

proper disposal of an old air conditioner and

contact your local authority or your dealer if

you have any question.Please ensure that

the pipework of your air conditioner does not

get damagedprior to being picked up by the

relevant waste disposal center, and contribute

to environmental awareness by insisting on an

appropriate, anti-pollution method of disposal.

Disposal of the old air conditioner All these valuable materials may be taken to

a waste collecting center and used again after

adequate recycling.

Consult your local authorities for the name

and address of the waste materials collecting

centers and waste paper disposal services

nearest to your house.

Disposal of the packaging of your

new air conditioner

Safety Instructions andWarnings

Cautions

All the packaging materials employed in the

package of your new air conditioner may be

disposed without any danger to the

environment.

The cardboard box may be broken or cut into

smaller pieces and given to a waste paper

disposal service.The wrapping bag made of

polyethylene and the polyethylene foam pads

contain no fluorochloric hydrocarbon.

Before starting the air conditioner, read the

information given in the User's Guide caref-

ully.The User's Guide contains very impor-

tant observations relating to the assembly,

operation and maintenance of the air

conditioner.

The manufacturer does not accept respon-

sibility for any damages that may arise due

to non-observation of the following

instruction.

Damaged air conditioners are not to be

put into operation.In case of doubt, consult

your supplier.

Use of the air conditioner is to be carried

out in strict compliance with the relative

instructions set forth in the User's Guide.

Installation shall be done by professional

people, don't install unit by yourself.

Edition:2006/1/18

Air Conditioner

For the purpose of the safety,the air con-

ditioner must be properly grounded in acco-

rdance with specifications.

Always remember to unplug the air

conditioner before openning inlet grill. Never

unplug your air conditioner by pulling on

the power cord.Always grip plug firmly and

pull straight out from the outlet.

All electrical repairs must be carried out

by qualified electricians.Inadequate repairs

may result in a major source of danger for

the user of the air conditioner.

Do not damage any parts of the air

conditioner that carry refrigerant by piercing

or perforating the air conditioner's tubes

with sharp or pointed items, crushing or

twisting any tubes, or scraping the coatings

off the surfaces.If the refrigerant spurts

out and gets into eyes, it may result in

serious eye injuries.

Cautions

Do not obstruct or cover the ventilation

grille of the air conditoner.Do not put fingers

or any other things into the inlet/outlet and

swing louver.

Do not allow children to play with the air

conditioner.In no case should children be

allowed to sit on the outdoor unit.

The refrigerating circuit is leak-proof.

Remark per EMC Directive 89/336/EEC.

To prevent flicker impression during the

start of the compressor(Technical Process)

and the adversely influence caused by

the 2nd harmonies of compressor following

installation conditions do apply:

1.The power connection for air conditioner

has to be done at the main power

distribution.This distribution has to be of a

Iow impedance. Normally the required

impedance is reached at a 32A fusing point.

2.No other equipment has to be connected:

to this power line.

3.For the details installation acceptance

please refer to your contract with the power

supplier, if restrictions do apply for products:

like washing machines,air conditioners or

electrical ovens.

4.For the details of the power of air,

conditioner, please refer to the rating plate

of the product.

5.For any question contact your local dealer.

Specifications

Edition:2006/1/18

Air Conditioner

1.Applicable ambient temperature range:

The machine is adaptive in following situation

Cautions

3. If the fuse on PC board is broken please change it with the type of T. 3.15A/250V.

4. The distance between the indoor unit and the floor should be more than 2m.

5. The wiring method should be in line with the local wiring standard.

6. After installation, the power plug should be easily reached.

7. The waste battery should be disposed properly.

8. The appliance is not intended to use by young children or infirm persons without supervision.

9.Young children should be supervised ensure that they do not play with the appliance.

10.The appliance must be installed on strong enough supporter.

11 .The wiring diagram is attached inside the machine.

2. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent

or a similar qualified person. The type of connecting wire is H05RN-F or H07RN-F

Cooling

Heating

Indoor

Outdoor

Indoor

Outdoor

Maximum: D.B / W.B

Minimum: D.B / W.B

Maximum: D.B

Minimum: D.B

Maximum: D.B

Minimum: D.B

Maximum: D.B / W.B

Minimum: D.B / W.B

32oC/23oC

18oC/14oC

43oC/26oC

18oC

27oC

15oC

24oC/18oC

-7oC/-8oC

Edition:2006/1/18

Air Conditioner

Parts and Functions

CONNECTING PIPING AND ELECTRICAL WIRING

DRAIN HOSE

OUTLET

INLET

HSU-09CU13

Inlet Air Purifying Filter

Vertical flap

(adjust up and down air flow.

Don't adjust it manually)

Horizontal louver(inside)

Inlet grille

Power plug

(adjust left and right air flow)

(inside)

Outlet

Anion generator

(inside)

Air filter(inside)

display board

UV light degerming

device (inside) POWER TIMER HEALTHRUN

Indoor unit

Outdoor unit

Edition:2006/1/18

Air Conditioner

Edition:2006/1/18

Air Conditioner

POWER/SOFT

31 32 33 34 16

POWER TIMER HEALTHRUN

Parts and Functions

9. SWING button

Used for unit start and stop.

10. ON/OFF button

11.TIMER ON display

12. FAN SPEED display

LOW HI

MED AUTO

13. LOCK display

14. SWING UP/DOWN display

15. SLEEP display

16. HEALTH display

Used to select your desired temperature.

Operation mode AUTO FANCOOL DRY

Remote controller

17. Operation mode display

19. POWER/SOFT display

20. Left/right air flow display

Remote controller: to display the TEMP.setting.

21.TEMP display

22.TIMER OFF display

23. CLOCK display

24.TEMP button

Used to select fan speed:LOW,MED, HI, AUTO.

25. FAN button

Used to set the health airflow mode.

26. HEALTH AIRFLOW button

27. SLEEP button

Used to select up or down air sending direction.

Used to confirm timer and clock settings.

28. SET button

29. POWER/SOFT button

Use to set power/soft function.

Used to select CODE A or B with a press,A or B

will be displayed on LCD.

Please select A without special explanation.

1.CODE

When the remote controller appears abnormal,

use a sharp pointed article to press this button

to reset the remote controller normal.

2.RESET

Used to select TIMER ON, TIMER OFF,

TIMER ON-OFF.

4.TIMER button

Used to set correct time.

5. CLOCK button

6. HEALTH button

7. MODE button

AUTO COOL DRY FAN

Used to set clock and timer setting.

8. HOUR button

Used to lock buttons and LCD display. If pressed, the

other buttons will be disabled and the lock condition

display appears. Press it once again, lock will be

canceled and lock condition display disappears.

30. LOCK

Used to set healthy operation.

Used to select sleep mode.

31. Remote signal receiver

Lights up during compressor running.

Lights up when Timer operation is selected.

Lights up when unit starts.

32. Operation mode indicator

33. Timer mode indicator

34. Power indicator

NOTE: The following functions and related displays are not available: 20

18.Singal sending display

3.LIGHT button

Control the lightening and extinguishing of

the indoor LED display board.

Edition:2006/1/18

Air Conditioner

Remove the batteries in case unit won't be in usage for a long period. If there are any display

after taking-out, just need to press reset key.

Parts and Functions

Clock Set

When unit is started for the first time and after replacing batteries in

remote controller, clock should be adjusted as follows:

Remote controller's operation

3. After time setting is confirmed, press SET, "AM" or "PM" stop flashing,

while clock starts working.

2. Press or to set correct time.Each press will increase or decrease

1 min. If the button is kept depressed, time will change quickly.

1. Press CLOCK button,"AM" or "PM" flashes.

When in use, put the signal transmission head directly to the receiver hole on the indoor unit.

The distance between the signal transmission head and the receiver hole should be within

7m without any obstacle as well.

Don't throw or knock the remoter controller.

When electronic-started type fluorescent lamp or change-over type fluorescent lamp or

wireless telephone is installed in the room, the receiver is apt to be disturbed in receiving

the signals, so the distance to the indoor unit should be shorter.

Loading of the battery

Load the batteries as illustrated right

2 R-03 (7#) batteries

Remove the battery cover:

Slightly press" "area and push down the cover

as illustrated.

Load the battery:

Be sure that the loading is in line with the "+" / "-".

request as illustrated on the bottom of the case.

Put on the cover again.

Confirmation indicator:

After pressing power ON/OFF, if no display, reload the batteries.

Note:

Full display or unclear display during operation indicates the batteries have been used up.

Please change batteries.

Used two new same-typed batteries when loading.

If the remote controller can't run normally during operation, please remove the batteries and

reload several minutes later.

Hint:

POWER/SOFT

HEALTH

Edition:2006/1/18

Air Conditioner

Operation

Remote controller

POWER/SOFT

2.Health anion function

Air conditioner starts health anion function operation.

For twice press, disappears,the operation stops.

BRIEF INTRODUCTION TO HEALTH ANION FUCTION

UV light emitted by the UV light device of the indoor unit catalytically

activates the nano TiO2on the multi-lights touching intermediary,

and the degerming effect is highly efficient and lasting.

Note: when the function is running, don't open the inlet grille.

About UV light degerming function

Health function includes health anion function, UV light

degerming function.

The anion generator in the air conditioner can generate a lot of

anion effectively balance the quantity of position and anion in the

air and also to kill bacteria and speed up the dust sediment in

the room and finally clean the air in the room.

When the fan in the indoor unit does not work, the health lamp

lights up, but the anion generator does not release anion.

When indoor fan motor is running, it has healthy

process function. (It's available under any mode)

Press ON/OFF on the remote controller, unit starts.

Press HEALTH button.For each press, is displayed.

1.Unit start

HEALTH operation

Edition:2006/1/18

Air Conditioner

AUTO COOL DRY FAN

Auto Operation

Operation

Remote controller

POWER/SOFT

About Auto Operation

Under the mode of auto operation, air conditioner will

automatically select Cool or Heat operation according

to room temperature.

5.Unit stop

Press ON/OFF button, the unit stops.

1. Unit start

Press ON/OFF on the remote controller, unit starts.

2.Select operation mode

Press MODE button.For each press, operation mode

changes as follows:

Remote controller:

Then Select Auto operation

Press FAN button. For each press, fan speed changes as

follows:

Remote controller:

Press TEMP. button

Every time the button is pressed, temp.setting

increase 1oC,if kept depressed, it will increase

rapidly

Every time the button is pressed, temp.setting

decrease 1oC,if kept depressed, it will decrease

rapidly

Select a desired temperature.

4.Fan speed selection

3.Select temp.setting

Air conditioner is running under displayed fan speed.

When FAN is set to AUTO, the air conditioner

automatically adjusts the fan speed according to room

temperature.

LOW MED HI AUTO

Edition:2006/1/18

Air Conditioner

AUTO COOL DRY FAN

Cool Operation

Remote controller

2.Select operation mode

Press FAN button. For each press, fan speed changes as

Press MODE button. For each press, operation mode

changes as follows:

Remote controller:

Then Select COOL operation

Press TEMP. button

Every time the button is pressed, temp.setting

increase 1oC,if kept depressed, it will increase

rapidly

Every time the button is pressed, temp.setting

decrease 1oC,if kept depressed, it will decrease

rapidly

Select a desired temperature.

4.Fan speed selection

3.Select temp.setting

5.Unit stop

Air conditioner is running under displayed fan speed.

When FAN is set to AUTO, the air conditioner

automatically adjusts the fan speed according to room

temperature.

Press ON/OFF button, the unit stops.

LOW MED HI AUTO

1. Unit start

Press ON/OFF on the remote controller, unit starts.

Operation

POWER/SOFT

Table of contents

Other Haier Air Conditioner manuals

Haier

Haier AU142AAERA User manual

Haier

Haier AD09LS1ERA Installation and operating instructions

Haier

Haier ESA3057 - Window AC Cool Only BtuH 5200... User manual

Haier

Haier HW-07LN03 User manual

Haier

Haier AS09GN3ERA User manual

Haier

Haier ESA3105 - MANUAL 2 User manual

Haier

Haier AS25THMHRA-C User manual

Haier

Haier 1U35YESFRA-4 User manual

Haier

Haier HSU-24HEA03(T3) User manual

Haier

Haier HWR18VC5 User manual

Haier

Haier HPU-18CU13 User manual

Haier

Haier 1U50MEMFRA-C User manual

Haier

Haier H2SM-(9+12)HV03/R2 User manual

Haier

Haier 1U160S2SP1FB User manual

Haier

Haier HCFU-18CF03 User manual

Haier

Haier HW-18EM13 User manual

Haier

Haier MRVII-C ERV0260ANN User manual

Haier

Haier AD90S2SM3FA Installation and operating instructions

Haier

Haier HSU-09C03 User manual

Haier

Haier HSU-09C03 User manual

Haier

Haier HWS18VCA User manual

Haier

Haier AV10IMWEWA User manual

Haier

Haier HW-18CM03 User manual

Haier

Haier HSU-18CVY03 User manual

Popular Air Conditioner manuals by other brands

Spheros

Spheros CC 355 instructions

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE owner's manual

Panasonic

Panasonic CS-E12HKEW operating instructions

nedis

nedis ACMB1WT7 quick start guide

Samsung

Samsung AR KV Series User & installation manual

Daikin

Daikin FCFV50A Operation manual

Fujitsu

Fujitsu Inverter ASBA30JFC operating manual

Toshiba

Toshiba RAS-M10SMUV-E installation manual

Daikin

Daikin FXLQ20MAVE Operation manual

Hitachi

Hitachi RAS-E24CAK instruction manual

CIAT

CIAT Magister 2 Series Installation, Operation, Commissioning, Maintenance

Bestron

Bestron AAC6000 instruction manual

Hisense

Hisense 7K Use and Installation Instructions

Frigidaire

Frigidaire FFRE0533S1E0 Use & care guide

Samsung

Samsung AS09HM3N user manual

Frigidaire

Frigidaire CRA073PU11 use & care

Soleus Air

Soleus Air GB-PAC-08E4 operating instructions

McQuay

McQuay MCK020A Technical manual
