SERVICE MANUAL

Models

AS072XVERA

AS092XVERA

AS122XVERA

AU182XFERA

AU222XFERA

 Features

 High energy efficiency

 Newly designed V-appearance for wall mounted unit, step or stepless air flow

control

 New outdoor unit with valve cover plate, also the grille is changed from metal

one to plastic one

 Adjustable heating temperature compenstation

 Free combination, multiple connection types with different types of indoor

unit, total indoor load can be up to 135% than the standard match

 Infrared control type

 Central control and full automation, if connected with a central controller

 New friendly refrigerant R410a, zero ODP, environment protection

 Advanced technology, DC inverter control function

 Health airflow and sterilize function for wall mounted unit, more healthy

 Weekly timer (standard)

 Group control function

 Auto restart function

 Low ambient temperature heating (-15 degree) function

 Room card function

Manual code: SYJS-013-05REV.3Edition: 2007-04-14

Commercial Air Conditioner Model: AU18/222XFERA

AS072/092/122XVERA

CONTENTS

Contents………………………………………………………....2

1. Description of products& features………………………...3

2. Specification………………………………………………….6

3. Safety precaution……………………………………………10

4. Net dimension of indoor and outdoor……………………..12

5. Installation instructions………..……………………………13

6. Parts and functions………………………….………………36

7. Remote controller YR-H65...……………………………….37

8. Refrigerant diagram…………………………………………45

9. Electrical control functions………………………………….47

10. Diagnostic information and trouble shooting...………….59

11. Electrical data………………………………………………65

12. Performance curves.......................................................71

13. Noise level.....................................................................75

14. Air velocity distribution...................................................78

-2-

Commercial Air Conditioner Model: AU18/222XFERA

AS072/092/122XVERA

1.Description of products & features

1.1. Products code explanation

AU 18 2 X F E R A

Climate type: T1 (see table 1)

Design number (R stands for design sequence, DC inverter

type)

Product type: A stands for heat pump type, refrigerant is R22

B stands for heat pump type, refrigerant is R407C

E stands for heat pump type, refrigerant is R410A

N stands for cool only type, refrigerant is R407C

Appearance character

Product series: X stands for multi-split series

Applicable voltage: 2 stands for 220-230V/50Hz,

4 stands for 220V/60Hz，N stand for 380-400V/50Hz

Cooling / Heating capacity,18=18000BTU/h

Product type : “B” stands for cassette type, “C” stands for

convertible type, ”D” stands for duct, “S” stands for wall

mounted type, "E" stands for ceiling concealed type, “U”

stands for outdoor unit

Air Conditioner

1.2 Brief Introduction for T1、T2、T3 working condition

1.3 Operating Range of Air Conditioners

Working temperature range

Rated Maximum Minimum

Indoor DB℃27 32 18

WB℃19 23 14

outdoor DB℃35 43 10

Cooling

WB℃24 26 6

Indoor DB℃20 27 15

WB℃14.5 -- --

outdoor DB℃7 24 -15

Heating

WB℃6 18 --

Climate type

Type of Air

Conditioner T1 T2 T3

Cooling Only 18 ℃~43℃10℃~35℃21℃~52℃

Heat pump -7℃~43℃-7℃~35℃-7℃~52℃

Electricity Heating ~43℃~35℃~52℃

-3-

Commercial Air Conditioner Model: AU18/222XFERA

AS072/092/122XVERA

1.4 Product features

High efficienct, universal outdoor unit

The outdoor unit can match with wall mounted type, duct and cassette type indoor unit. One set

outdoor can match with multiple indoor units, up to 3 sets. Even when you have already installed

the air conditioner, if you want to add or reduce one unit, go ahead freely as long as your operation

complies with our design. Greatly convenient for designer and installer.

Total indoor load can be up to 135% than the standard match

The total capacity of all indoor units can be 135% more than the mominal cooling capacity, but the

total indoor cooling capacity will not be increased.

Newly designed V- appearance indoor unit

The wall mounted type indoor unit adopts the newly designed V appearance, more fashion, more

beautiful. The unit is designed with the health airflow and sterilize function, which will make the air

more healthy. Also the air blow direction can be set as step or stepless control, much convenient to

control.

Newly designed guarding plate of valve

In order to protect the valve against the dust, the rain or the snow, etc. we add a

guarding plate to the valve.

Adopt the much friendlier refrigerant R410a

The air conditioner system adopts the greatly friendly refrigerant R410a, which is protective for the

ozone layer and is good to avoid the earth getting warmer. Benefit for the environment.

Adopt the advanced DC inverter technology

The system adopts the advanced DC inverter technology, which can consume less power energy to

realize the equal efficiency, saving money for you.

With air inlet filter, enhance the air quality

The high efficiency filter can collect the dirt and remove the bacterium, which can be installed on the

easy-to-unload place, convenient to be cleaned.

Convenient infrared remote controller

This remote controller YR-H65 can realize the healthy air flow and sterilize function, it is mobile type

appearance, so smart and compact.

And the infrared controller can be equipped with the controller holder, convenient to fix

the remote controller.

-4-

Auto–restart function (optional)

All indoor units have auto-restart function. When the power supply cut off suddenly, the unit will

automatically recover the previous running mode once the power supply is on.

Self-diagnostic function

In the course of operation, if the failure occurs, the failure code will display on the wired controller or

on the operation panel. Then according to the failure code chart, you can eliminate the failure soon.

Central control function, if connected with a detector and a central controller

That is convenient for building management.

Weekly timing function, if connected with a detector and a weekly timer

Adjustable heating temperature compensation

In heating mode, the temperature compensation can be adjusted by the remote controller. If you do

not want the compensation, you can set the compensation as 0 degree.

-5-

Commercial Air Conditioner Model: AU18/222XFERA

AS072/092/122XVERA

OFF

When room card function is available,indoor will be controlled as below figure:

When room card is disconnected When room card is connected

2. Specification

-6-

—— Cooling Heating

W 5300 7000

W 1650 1800

W/W 3.21 3.88

W 1500 1800

W 500 500

W5800 7400

W2300 2300

——

A / A 10.2 10.2

—— 99% 99%

Model / Manufacture ——

Oil charge and type ——

Type ——

Number ——

Type × Number ——

Speed r/min

Motor output power W

Air-flows (H/M/L) m³/h

Type / Diameter mm

Face area m²

External mm

Package mm

——

Noise level H/M/L dB(A)

Weight Net / Shipping kg / kg

Type / Charge kg

No need to recharge m

Recharge g/m

Liquid mm

Gas mm

——

Drop between IU & OU m

Piping length between IU & OU m

Total liquid piping length m

Drop between indoor units m

Max.Drop between IU & OU m

Max.Drop between indoor units m

Max.Piping length between IU & m

Max.Total liquid piping length m

Power input

Minimum capacity

Power input

Power facor(under rating power input)

Max.Running current

Fan

Item Model AU182XFERA

Function

Power source 1PH, 220-230V~, 50Hz

Rating capacity

Maximum capacity

Power input

EER / COP

Fuse size (recommended size)

TNB175FLBM1 / MISTUBISHI ELEC.

Twin Rotary (DC inverter)

Outdoor unit

Compressor

Dimension

(L×W×H)

Heat exchanger

Crankcase heater power

Axial × 1

670CC, MEL 56

928/288/680

1015/405/760

850/ 700/ 500

about 3000

TP2M / 7.0

about 0.52

Refrigerant control method PMV

Defrosting method Automatic by reversible cycle

Pipe 3* Φ6.35

3* Φ9.52

≤10

≤5

≤30

10(indoor unit lower than outdoor unit)

15 (indoor unit higher than outdoor unit)

≤1

2. Large drop and long piping installation will obviously reduce the totao capacity.

1. The above performance data are from the combination of AU182XFERA+2*AS092XVERA+AS122XVERA.

51/-/-

54 / 60

Piping

Refrigerant R410A / 2.0

Connecting method Flared

Between I.D &O.D

Commercial Air Conditioner Model: AU18/222XFERA

AS072/092/122XVERA

—— Cooling Heating

W 6400 7300

W 2100 2000

A 9.3 8.9

W/W 3.04 3.65

W 1500 1800

W 500 500

W6800 7500

W2900 2900

——

A / A 12.9 12.9

—— 99% 99%

Model / Manufacture ——

Oil charge and type ——

Type ——

Number ——

Type × Number ——

Speed r/min

Motor output power W

Air-flows (H/M/L) m³/h

Type / Diameter mm

Face area m²

External mm

Package mm

——

Noise level H/M/L dB(A)

Weight Net / Shipping kg / kg

Type / Charge kg

No need to recharge m

Recharge g/m

Liquid mm

Gas mm

——

Drop between IU & OU m

Piping length between IU & OU m

Total liquid piping length m

Drop between indoor units m

Max.Drop between IU & OU m

Max.Drop between indoor units m

Max.Piping length between IU & m

Max.Total liquid piping length m

1. The above performance data are from the combination of AU222XFERA+AS092XVERA+2*AS122XVERA.

2. Large drop and long piping installation will obviously reduce the total capacity.

Connecting method Flared

Between I.D &O.D ≤5

≤10

≤30

≤1

10(indoor unit lower than outdoor unit)

15 (indoor unit higher than outdoor

55/-/-

54 / 60

Piping

Refrigerant R410A / 2.0

Pipe 3* Φ6.35

3* Φ9.52

Defrosting method Automatic by reversible cycle

Crankcase heater power 35

Dimension

(L×W×H)

928/288/680

1015/405/760

Refrigerant control method PMV

about 3200

Heat exchanger TP2M / 7.0

about 0.52

Outdoor unit

Compressor TNB175FLBM1 / MISTUBISHI

670CC, MEL 56

Twin Rotary (DC inverter)

Fan Axial × 1

960/ 700/ 500

Max.Running current

Power facor(under rating power input)

Fuse size (recommended size) 25

Maximum capacity

Power input

Power source 1PH, 220-230V~, 50Hz

Power input

EER / COP

Minimum capacity

Power input

Current input

Item Model AU222XFERA

Function

Rating capacity

Commercial Air Conditioner Model: AU18/222XFERA

AS072/092/122XVERA

-7-

-8-

—— Cooling Heating Cooling Heating

BTU/h 7000 8000 9000 10000

W2000 2300 2500 2900

——

10‐³×m³/h 1.0 / 1.0 /

N, V, Hz

A / A 0.15 0.15 0.15 0.15

Type × Number ——

Speed r/min

Motor output power W

Air-flows (H/M/L) m³/h

Type / Diameter mm

Total area m²

External mm

Package mm

Drainage pipe material, diameter mm

——

Noise level H/M/L dB(A)

Weight Net / Shipping kg / kg

Refrigerant Type ——

Liquid mm

Gas mm

——

BTU/h

10‐³×m³/h

——

N, V, Hz

A / A

Type × Number ——

Speed r/min

Motor output power W

Air-flows (H-M-L) m³/h

Type / Diameter mm

Total area m²

External mm

Package mm

Drainage pipe material, diameter mm

——

Noise level H/M/L dB(A)

Weight Net / Shipping kg / kg

Refrigerant Type ——

Liquid mm

Gas mm

——

R410A

6.35

9.52

Flared

1250/1150/1050

550/480/430

about 0.20

0.15 0.15

CROSS×1

AS122XVERA

Cooling

11000

3200

1.6

Heating

13000

3800

Piping

Pipe

Connecting method

39/36/33

7.6/10.6

PVC, 11.4/16.4

Controller type Infrared (YR-H65)

Refrigerant control PMV on outdoor unit

Dimension

(L×W×H)

795×197×265

880×315×330

Heat exchanger TP2M / 7×0.35

Power source 1, 220~230, 50

Running current

Fan

Power cable 3 × (1.0~1.5mm2)

Communication cable 2x(0.75~1.25mm2

), must be shielded

Function

Capacity

Dehumidifying capacity

Flared

Item

Piping

R410A R410A

Pipe 6.35 6.35

9.52 9.52

Connecting method Flared

PMV on outdoor unit

36/33/30 38/34/31

7.6/10.6 7.6/10.6

795×197×265

880×315×330 880×315×330

PVC, 11.4/16.4

520/450/390

Heat exchanger TP2M / 7×0.35

about 0.15 about 0.15

CROSS×1

1150/1050/950 1200/1100/1000

27 27

Running current

Fan CROSS×1

480/430/380

Dimension

(L×W×H)

795*197*265

Controller type Infrared (YR-H65)

Refrigerant control

Communication cable 2x(0.75~1.25mm2

), must be shielded

Dehumidifying capacity

Power source 1,220-230~, 50

Capacity

Power cable 3 × (1.0~1.5mm2)

Item Model AS072XVERA AS092XVERA

Function

Commercial Air Conditioner Model: AU18/222XFERA

AS072/092/122XVERA

Norminal condition: indoor temperature (cooling): 27℃DB/19℃WB, indoor temperature (heating): 20℃

Outdoor temperature(cooling): 35℃DB/24℃WB, outdoor temperature(heating): 7℃DB/6℃WB

The noise level will be measured in the third octave band limited values, using a Real Time Analyser

calibrated sound intensity meter. It is a sound pressure noise level. The detailed method please refer to

the following information:

Installation state: the unit should be placed on the flat floor or be mounted in horizontal direction.

Testing method:

outdoor unit:

1.air outlet from side: the noise level is the average sound pressure level measured from front, left, right

directions.

2.air outlet from top: the noise level is the average sound pressure level measured from front, back, left, right

directions.

measured point:

H ( height to the ground) = (h (unit height) + 1m) /2

and, it is 1m to each side.

mounting-on-wall unit:

Note: ⊙is the real time analyser position

0.8m

-9-

Commercial Air Conditioner Model: AU18/222XFERA

AS072/092/122XVERA

3. Safety precaution

Carefully read the following information in order to operate the airconditioner correctly .

Below are listed three kinds of Safety Cautions and Suggestions.

WARNING!

CAUTION! Incorrect operations may result in injuries or machine damages; in some cases may

cause serious consequences.

Incorrect operations may result in severe consequences of death or serious injuries.

INSTRUCTIONS: These information can ensure the correct operation of the machine.

Be sure to conform with the following important Safety Cautions.

The Safety Cautions should be at hand so that they can be checked at any time when needed.

If the conditioner is transferred to the new user, this manual should be as well transferred to the new user.

WARNING!

If any abnormal phenomena is found

(e. g.smell of firing), please cut off the

power supply immediately , and contact

the dealer to find out the handling

method.

Don't dismantle the outlet of the

outdoor unit.

The exposed fan is very dangerous

which may harm human beings.

switch

off

In such case, to continue using the

conditioner will damage the conditioner,

and may cause electrical shock or fire

hazard.

Incorrect maintenance and repairment

may cause water leak, electrical shock

and fire hazard.

When the unit needs maintenance and

repairment, please call dealer to handle it.

After the unit being used for a long time,

the base should be checked for any

damages.

If the damaged base is not repaired, the

unit may fall down and cause accidents.

-10-

Commercial Air Conditioner Model: AU18/222XFERA

AS072/092/122XVERA

Other manuals for AS072XVERA

This manual suits for next models

Table of contents

Other Haier Air Conditioner manuals

Haier

Haier HM-09CB03/R1 User manual

Haier

Haier GE NS23AM User manual

Haier

Haier AS25XCHHRA-NR User manual

Haier

Haier HSU-09/12HA103/R2(DB) Installation and user guide

Haier

Haier AB182ACBHA User manual

Haier

Haier HWR18VCA User manual

Haier

Haier HSU-05LE03 User manual

Haier

Haier AB35S2SC1FA Installation and operating instructions

Haier

Haier AD362AHERA Administrator Guide

Haier

Haier HWF05XCL User manual

Haier

Haier HSU-24LEA03 User manual

Haier

Haier H-MRV AE072FCBKA Specification sheet

Haier

Haier HSU-10HM03 User manual

Haier

Haier AS07GS2ERA - User manual

Haier

Haier ESA3159 User manual

Haier

Haier HPU-18CU13 User manual

Haier

Haier HTWR08XCK Assembly instructions

Haier

Haier ESA3109 User manual

Haier

Haier HSU-09HB03/R1 User manual

Haier

Haier HSU-12HEB03 User manual

Haier

Haier ESA3055 User manual

Haier

Haier AU282FHERA(H) User manual

Haier

Haier AB092ACBHA Specification sheet

Haier

Haier HSU-12HX03 User manual

Popular Air Conditioner manuals by other brands

Spheros

Spheros CC 355 instructions

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE owner's manual

Panasonic

Panasonic CS-E12HKEW operating instructions

nedis

nedis ACMB1WT7 quick start guide

Samsung

Samsung AR KV Series User & installation manual

Daikin

Daikin FCFV50A Operation manual

Fujitsu

Fujitsu Inverter ASBA30JFC operating manual

Toshiba

Toshiba RAS-M10SMUV-E installation manual

Daikin

Daikin FXLQ20MAVE Operation manual

Hitachi

Hitachi RAS-E24CAK instruction manual

CIAT

CIAT Magister 2 Series Installation, Operation, Commissioning, Maintenance

Bestron

Bestron AAC6000 instruction manual

Hisense

Hisense 7K Use and Installation Instructions

Frigidaire

Frigidaire FFRE0533S1E0 Use & care guide

Samsung

Samsung AS09HM3N user manual

Frigidaire

Frigidaire CRA073PU11 use & care

Soleus Air

Soleus Air GB-PAC-08E4 operating instructions

McQuay

McQuay MCK020A Technical manual
