Haier AS072XHERA Specification sheet

WALL MOUTED TYPE INDOOR UNITS

AS072XHERA

AS092XHERA

AS122XHERA

R410A MULTI SPLIT SERIES ROOM AIR CONDITIONER

OPERATION & INSTALLATION MANUAL

No.0010577054

Please read this manual carefully before using this air conditioner.

Please keep this manual safely for future use.

Contents

Cautions .............................................................................................

Safety precautions...............................................................................

Parts and Functions ...........................................................................

Operation.........................................................................................

Notes for safety ...................................................................................

Operation and Maintenance .................................................................

Trouble shooting .............................................................................

Customer Need-to-know .....................................................................

Instructions to installation...............................................................

When trouble happens..........................................................................

Failure code .........................................................................................

1-2

3-5

6-7

8-18

21-22

24-28

Cautions

Disposal of the old air conditioner

Before disposing an old air conditioner

that goes out of use, please make sure it's

inoperative and safe. Unplug the air

conditioner in order to avoid the risk of

child entrapment.

It must be noticed that air conditioner

system contains refrigerants, which require

specialized waste disposal. The valuable

materials contained in a air conditioner can

be recycled. Contact your local waste

disposal center for proper disposal of an

old air conditioner and contact your local

authority or your dealer if you have any

question. Please ensure that the pipework

of your air conditioner does not get

damaged prior to being picked up by the

relevant waste disposal center, and

contribute to environmental awareness by

insisting on an appropriate, anti-pollution

method of disposal.

Disposal of the packaging of your new

air conditioner

All the packaging materials employed in

the package of your new air conditioner

may be disposed without any danger to the

environment.

The cardboard box may be broken or cut

into smaller pieces and given to a waste

paper disposal service. The wrapping bag

made of polyethylene and the polyethylene

foam pads contain no fluorochloric

hydrocarbon.

Consult your local authorities for the name and

address of the waste materials collecting

centers and waste paper disposal services

nearest to your house.

Safety Instructions and Warnings

Before starting the air conditioner, read the

information given in the User's Guide

carefully. The User's Guide contains very

important observations relating to the

assembly, operation and maintenance of the

air conditioner.

The manufacturer does not accept

responsibility for any damage that may arise

due to non-observation of the following

instructions.

Damaged air conditioners are not to be

put into operation. In case of doubt, consult

your supplier.

Use of the air conditioner is to be carried

out in strict compliance with the relative

instructions set forth in the User's Guide.

Installation shall be done by professional

people, and don't install the unit by yourself.

All these valuable materials may be taken to a

waste collecting center and used again after

adequate recycling.

For the purpose of safety, the air

conditioner must be properly grounded in

accordance with specifications.

Always remember not to operate the air

conditioner before opening its inlet grill.

4. The wiring method should be in line with

the local wiring standard.

5. The power cable and connecting cable are

self-provided.

The requirement of the connecting cable:

All the cables shall have got the Local

authentication certificate.

6. The breaker of the air conditioner should

be all-pole switch; and the distance between

its two contacts should be no less than 3mm.

Such means for disconnection must be

incorporation in the fixed wiring.

7. The waste battery shall be disposed

properly.

8. The indoor unit installation height is at

least 2m.

9. The appliance is not intended for ase

young children or infirm persons without

super vision.

10. Young children should be super vised to

ensure that they do not play with the

applience.

All electrical repairs must be carried out

by qualified electricians. Inadequate repairs

may result in a major source of danger for

the user of the air conditioner.

Do not damage any parts of the air

conditioner that carry refrigerant by

piercing or perforating the air conditioner's

tubes with sharp or pointed items, crushing

or twisting any tubes, or scraping the

coatings off the surfaces. If the refrigerant

spurts out and gets into eyes, it may result

in serious eye injuries.

Do not obstruct or cover the ventilation

grille of the air conditioner. Do not put

fingers or any other things into the

inlet/outlet and swing louver.

Do not allow children to play with the air

conditioner. In no case should children be

allowed to sit on the outdoor unit.

Specifications

The refrigerating circuit is leak-proof.

1. Applicable ambient temperature range:

The machine is adaptive in following

situation

2. If the supply cord is damaged, it must be

replaced by the manufacturer or its service

agent or a similar qualified person.

3. If the fuse on PC board is broken, please

change it with the type of T 3.15A /250VAC

Cooling

Heating

Indoor

outdoor

Rated Maximum Minimum

27 32 18

19 23 14

35 43 10

24 26 6

20 27 15

14.5 -- --

7 24 -15

6 18 --

DB C

WB C

DB C

WB C

Indoor

outdoor DB C

WB C

DB C

WB C

Cautions

Model

H05RN-F 3G 2.5mm2

AS072XHERA

AS092XHERA

AS122XHERA

Connecting cable(sheilded wire)

H05RN-F 2X1.5mm2

WARNING!

Carefully read the following information in order to operate the air conditioner correctly.

Below are listed three kinds of Safety Cautions and Suggestions.

INSTRUCTIONS: These information can ensure the correct operation of the machine.

Be sure to conform with the following important Safety Cautions.

The Safety Cautions should be at hand so that they can be checked at any time when needed.

If the conditioner is transferred to the new user, this manual should be as well transferred to the new user.

Safety precautions

Otherwise the one will feel unpleasant

or harm ones' health.

If any abnormal phenomena is found (e. g.

smell of firing), please cut off the power

supply immediately, and contact the dealer

to find out the handling method.

In such case, to continue

using the conditioner will

damage the conditioner,

and may cause electrical

shock or fire hazard.

When need maintenance and repairment,

call dealer to handle it.

Incorrect mainten-

ance and repairment

may cause water

leak, electrical shock

and fire hazard.

switch

off

Please let the dealer be responsible for installing

the conditioner.

Incorrect installation may cause water leak, elec-

trical shock and fire hazard.

Don't put fingers or any other things into the

inlet/outlet and swing louver while the condi-

tioner is in operation.

Because the highspeed fan is very dangerous

and may cause injuries.

Call the dealer to take measures to prevent the

refrigerant from leaking.

If conditioner is installed in a small room, be sure

to take every measure in order to prevent suffoca-

tion accident even in case of refrigerant leakage.

When conditioner is deinstalled or reinstalled

dealer should be responsible for them.

Incorrect installation may cause water leaking,

electrical shock and fire hazard.

Don't blow the human body with the cooling

air too long, and don't let the room tempera-

ture decrease too low either.

WARNING! Incorrect operations may result in severe consequences of death or serious injuries.

CAUTION! Incorrect operations may result in injuries or machine damages; in some cases may

cause serious consequences.

CAUTIONS!

Conditioner should not be used for any other

purpose other than airconditioning.

Don't use air-conditioner for any other special

purposes, e.g. the preservation and protection

of food, animals, plants, pecision apparatus as

well as work of art, otherwise the qualities

of these stuffs may be damaged.

Don't dismantle the outlet of the outdoor unit.

The exposure of fan is

very dangerous which

may harm human be-

ings.

When air-conditioner is co-used with other

heat-radiator the frequent replacement of

room atmosphere should be required.

Inefficient venti-

lation may cause

suffocation.

After a long time use of air-conditioner the

base should be checked for any damages.

If the damaged base is

not repaired, the unit

may fall down and

cause accidents.

No goods or nobody is permitted to placed on

or stand on outdoor unit.

The falling of goods and

people may cause acci-

dents.

Pets and plants should not be blowed directly

in the air flow.

Otherwise will suffer damage.

Don't operate the air-conditioner with damp

hands.

Otherwise will be shocked.

Only use correctly-typed fuse.

May not use wire or any other materials

replacing fuse, otherwise may cause faults or

fire accidents.

Don't place any burning unit

in the air flow of

air-conditioner,

which may cause incomplete

combustion.

No inflammable spray fluid should be

permitted to be placed or used near to

airconditioner other wise may cause fire

accidents.

Air-conditioner should be cleaned only after

power supply is cut off to keep from shock or

hurt.

Don't clean air-conditioner with water.

Otherwise may cause shock.

Otherwise the poisonous chemicals may settle

in air-conditioner which harm the health of

chemical-allergic people.

When use the fumigating insecticide don't

open air-conditioner.

Safety precautions

CAUTION !

Please ask the dealer or specialist to install, never try by the users themselves. After the installation please

be sure of the following conditions.

Safety precautions

Incorrect installation may cause water leaking, shock and fire hazard.

Please call dealer to install the air-conditioner.

CAUTIONS ON INSTALLATION

Air-conditioner can't be installed in the envi-

ronment with inflammable gases because the

inflammable gases near to air-conditioner may

cause fire hazard.

Installed electrical-leaking circuit breaker.

Connect earthing wire.

Use discharge pipe correctly to ensure efficient

discharge.

It easily cause electrical shock without circuit

breaker.

Earthing wire should not be con-

nected to the gas pipe, water pipe,

lightning rod or phone line, in-

correct earthing may cause shock.

Incorrect pipe use may cause water leaking.

Earthing

[Location]

[Wiring]

[Operating noise]

Air-conditioner should be located in well-vented

and easily-accessible place.

Air-conditioner should not be located in the

following places:

(a) Places with machine oils or other oil vapours.

(b) Seaside with high salt content in the air.

gases.

(d) Area with frequent fluctuation of voltage e.g.

factory, etc.

(e) In vehicles or ships.

(f) Kitchen with heavy oil vapour or humidity.

(g) Near to the machine emitting electric-magnetic

waves.

(h) Places with acid, alkali vapuor.

TV, radio, acoustic appliances etc are at least 1 m

far away to the indoor unit, outdoor unit, power

supply wire, connecting wire, pipes, otherwise

images may be disturbed or noises be created.

As required, take measures against heavy snow.

Air-conditioner should be equipped with special

power supply wire.

Chose the following locations:

(a) Capable of supporting air-conditioner weight,

don't increase operating noise and vibration.

(b) Hot vapour from outdoor unit outlet and ope-

rating noise don't disturb neighbour.

No obstacles around the outdoor unit outlet.

Parts and Functions

Front panel

Air inlet grille

Louver

LED board

INDOOR UNIT FRONT VIEW

INDOOR UNIT BACK VIEW

Signal receiver

Mounting plate

Heat preservation pipe

Connecting pipes

Drainage pipes

*HEALTH LED DISPLAY:PRESS HEALTH/FRESH/STERILIZE BUTTON

LED board

OPERATE COOL DRY HEAT TIMERHEALTH

Parts and Functions

REMOTE CONTROLLER

MODE

CLOCK

Used to set correct time.

TIMER

LIGHT

Used to set temp.,temp.

range:16 C~30 C

SLEEP

Used to select sleep

mode

HOUR

Used to set clock and

timer setting.

RESET

Used to reset the

controller back to

normal condition.

LOCK

Used to select

TIMER ON, TIMER

OFF, TIMER

ON/OFF.

Used to lock buttons

and LCD display.

OFF

TEMP

HEALTH FAN

MODE

SLEEP SWING

CLOCK

TIMER

SET

LOCK

LIGHT

RESET

Power ON/OFF

Used for unit start and stop.

Used to selectAUTO run,

COOL, DRY, HEAT and

FAN operation.

SET

Used to confirm

Timer and Clock

setting.

TEMP

HEALTH

Control the light up and go out

of the control panel's

background light source and

control the switch of the buzzer.

Used to set Health operation

function

FAN

Used to select fan speed: AUTO,

LOW FAN, MED FAN, HIGH

FAN.

Used to set UP/DOWN air

sending and RIGHT/LEFT air

sending direction.

Health display

Display when set Health

operation function.

Battery Capacity display

Display when the electric power

of the battery is insufficient.

Timer ON/OFF display

Fan speed and air sending

direction display

Swing direction display

Room temperature display

Sterilize display

(This function is optional)

Humidifying display

Clock display

Temperature display

Used to display the set

temperature

Lock state display

Sleep state display

Electric Heating display

SWING

STERILIZE

Fresh Air state display

(This function is optional)

HEALTH AIRFLOW

FRESH

STERILIZE

CODE

LOW MID HIGH AUTO

16 17

Note: This model does not have the following related display and function

18 21

HEALTHAIRFLOW

Used to set healthairflow

CODE A/B selection

For this unit, please set to code A

23 27

MODE

SLEEP SWING

CLOCK

TIMER

SET

LOCK

LIGHT

RESET

STERILIZE

123

HEALTH AIRFLOW

FRESH

CODE

Operation

Clock set

When unit is started for the first time

and after replacing batteries in remote

controller, clock should be adjusted as follows:

Press CLOCK button, "AM"or "PM" flashes.

Press or to set correct time. Each press will increase

or decrease 1 min . If the button is kept pressed, time will

change quickly.

After time setting is confirmed, press SET, "AM" and "PM"

stop flashing, while clock starts working.

Remote controller's operation

When in use, put the signal transmission

head directly to the receiver hole on the

indoor unit

The distance between the signal transmission

head and the receiver hole should be within

7m without any obsacles as well.

Don't throw the controller, prevent it from

being damaged.

When electronic-started type fluorescent

lamp or change-over type fluorescent lamp

or wireless telephone is installed in the room,

the receiver is apt to be disturbed in receiving

the signal so the distance to the indoor unit

should be shorter.

2R-03 dry batteries

MINUTES

Confirmation indicator:

In disorderation, reload the batteries or load the new batteries

after 5 mins.

Note:The waster batteries should be disposed properly,use two

new same-type batteries when loading.

If the remote controller can’t function normally or doesn’t work at

all,use a sharp-pointed item to press the reset key.

Hint:Remove the batteries in case unit won’t be in usage for a long period.

If there are any displays after taking-out just need to press reset key.

When throw away the waste batteries, please perform in accordance with the local regulation.

Loading of the battery

Slightly press " " and push down the cover.

Load the batteries as illustrated.

2 R-03 dry batteries, (cylinder)

Be sure that the loading is in line with the "+"/"-" pole

request as illustrated.

Put on the cover again.

This manual suits for next models

Table of contents

Other Haier Air Conditioner manuals

Haier

Haier HWE08XCN User manual

Haier

Haier Novel HSU09VHGDB-W User manual

Haier

Haier H2SM- User manual

Haier

Haier HBU-28CF03 User manual

Haier

Haier HSU-18LEK03-Y2 User manual

Haier

Haier T-Series User manual

Haier

Haier HSU-12HV13 User manual

Haier

Haier HSM12HEKC03 User manual

Haier

Haier HW-09CF03 User manual

Haier

Haier HW-24CE03 User manual

Haier

Haier AB182ACBHA User manual

Haier

Haier AE182FCAHA User manual

Haier

Haier ESAD4089 User manual

Haier

Haier HSM0912HEA03/R2 User manual

Haier

Haier AB072XCBAA Instruction Manual

Haier

Haier HSU-09LE04 User manual

Haier

Haier AP48DS1ERA Installation and operating instructions

Haier

Haier AS072AZBAA User manual

Haier

Haier AD71S2SM5FA User manual

Haier

Haier HPN10XCM User manual

Haier

Haier AB212XCEAA Specification sheet

Haier

Haier H2SU-18TK/R2-OUT User manual

Haier

Haier AP48KS1ERA Specification sheet

Haier

Haier HSU-09RS03/R2 User manual

Popular Air Conditioner manuals by other brands

Spheros

Spheros CC 355 instructions

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE owner's manual

Panasonic

Panasonic CS-E12HKEW operating instructions

nedis

nedis ACMB1WT7 quick start guide

Samsung

Samsung AR KV Series User & installation manual

Daikin

Daikin FCFV50A Operation manual

Fujitsu

Fujitsu Inverter ASBA30JFC operating manual

Toshiba

Toshiba RAS-M10SMUV-E installation manual

Daikin

Daikin FXLQ20MAVE Operation manual

Hitachi

Hitachi RAS-E24CAK instruction manual

CIAT

CIAT Magister 2 Series Installation, Operation, Commissioning, Maintenance

Bestron

Bestron AAC6000 instruction manual

Hisense

Hisense 7K Use and Installation Instructions

Frigidaire

Frigidaire FFRE0533S1E0 Use & care guide

Samsung

Samsung AS09HM3N user manual

Frigidaire

Frigidaire CRA073PU11 use & care

Soleus Air

Soleus Air GB-PAC-08E4 operating instructions

McQuay

McQuay MCK020A Technical manual
