GW Instek PFR-100 Series Operating instructions

Programmable DC Power Supply

PFR-100 Series

PROGRAMMING MANUAL

ISO-9001 CERTIFIED MANUFACTURER

This manual contains proprietary information, which is protected by

photocopied, reproduced or translated to another language without

prior written consent of Good Will company.

The information in this manual was correct at the time of printing.

However, Good Will continues to improve products and reserves the

rights to change specification, equipment, and maintenance

procedures at any time without notice.

Good Will Instrument Co., Ltd.

No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.

Table of Contents

SAFETY INSTRUCTIONS ................................................... 4

GETTING STARTED ........................................................... 8

PFR-100 Series Overview........................9

Appearance .......................................... 12

Configuration Settings ......................... 19

REMOTE CONTROL ........................................................ 26

Interface Configuration ........................ 28

Socket Server Examples ....................... 53

Command Syntax ................................. 57

Command List ..................................... 61

Status Register Overview ................... 113

Error List ........................................... 127

APPENDIX .....................................................................136

PFR-100 Default Settings ................... 136

Error Messages & Messages .............. 138

LED ASCII Table Character Set ........... 139

INDEX............................................................................140

PFR-100 Programming Manual

SAFETY INSTRUCTIONS

This chapter contains important safety

instructions that you must follow during

operation and storage. Read the following before

any operation to insure your safety and to keep

the instrument in the best possible condition.

Safety Symbols

These safety symbols may appear in this manual or on the

instrument.

WARNING

Warning: Identifies conditions or practices that

could result in injury or loss of life.

CAUTION

Caution: Identifies conditions or practices that

could result in damage to the PFR-100 or to other

properties.

DANGER High Voltage

Attention Refer to the Manual

Protective Conductor Terminal

Earth (ground) Terminal

SAFETY INSTRUCTIONS

Do not dispose electronic equipment as unsorted

municipal waste. Please use a separate collection

facility or contact the supplier from which this

instrument was purchased.

Safety Guidelines

General

Guideline

CAUTION

Do not place any heavy object on the PFR-100.

Avoid severe impact or rough handling that

leads to damaging the PFR-100.

Do not discharge static electricity to the PFR-

100.

Use only mating connectors, not bare wires, for

the terminals.

Do not disassemble the PFR-100 unless you are

qualified.

(Measurement categories) EN61010-1:2010 and EN61010-2-030

specifies the measurement categories and their requirements as

follows. The PFR-100 falls under category II.

Measurement category IV is for measurement performed at the

source of low-voltage installation.

Measurement category III is for measurement performed in the

building installation.

Measurement category II is for measurement performed on the

circuits directly connected to the low voltage installation.

0 is for measurements performed on circuits not directly

connected to Mains.

Power Supply

WARNING

AC Input Voltage: 100Vac-240Vac

Frequency: 47Hz to 63Hz

To avoid electrical shock connect the protective

grounding conductor of the AC power cord to

an earth ground.

PFR-100 Programming Manual

Cleaning the PFR-

100

Disconnect the power cord before cleaning.

Use a soft cloth dampened in a solution of mild

detergent and water. Do not spray any liquid.

Do not use chemicals containing harsh material

such as benzene, toluene, xylene, and acetone.

Operation

Environment

Location: Indoor, no direct sunlight, dust free,

almost non-conductive pollution (Note below)

Relative Humidity: 20%~ 80% (no condensation)

Altitude: < 2000m

Temperature: 0°C to 40°C

(Pollution Degree) EN61010-1:2010 and EN61010-2-030 specifies

the pollution degrees and their requirements as follows. The PFR-

100 falls under degree 2.

Pollution refers to “addition of foreign matter, solid, liquid, or

gaseous (ionized gases), that may produce a reduction of dielectric

strength or surface resistivity”.

Pollution degree 1: No pollution or only dry, non-conductive

pollution occurs. The pollution has no influence.

Pollution degree 2: Normally only non-conductive pollution

occurs. Occasionally, however, a temporary conductivity caused

by condensation must be expected.

Pollution degree 3: Conductive pollution occurs, or dry, non-

conductive pollution occurs which becomes conductive due to

condensation which is expected. In such conditions, equipment

is normally protected against exposure to direct sunlight,

precipitation, and full wind pressure, but neither temperature

nor humidity is controlled.

Storage

environment

Location: Indoor

Temperature: -20°C to 70°C

Relative Humidity: 20 to 85%(no condensation)

Disposal

Do not dispose this instrument as unsorted

municipal waste. Please use a separate collection

facility or contact the supplier from which this

instrument was purchased. Please make sure

discarded electrical waste is properly recycled to

reduce environmental impact.

SAFETY INSTRUCTIONS

Power cord for the United Kingdom

When using the power supply in the United Kingdom, make sure

the power cord meets the following safety instructions.

NOTE: This lead/appliance must only be wired by competent persons

WARNING: THIS APPLIANCE MUST BE EARTHED

IMPORTANT: The wires in this lead are coloured in accordance with the

following code:

Green/ Yellow:

Earth

Blue:

Neutral

Brown:

Live (Phase)

As the colours of the wires in main leads may not correspond with

the coloured marking identified in your plug/appliance, proceed

as follows:

The wire which is coloured Green & Yellow must be connected to

the Earth terminal marked with either the letter E, the earth symbol

or coloured Green/Green & Yellow.

The wire which is coloured Blue must be connected to the terminal

which is marked with the letter N or coloured Blue or Black.

The wire which is coloured Brown must be connected to the

terminal marked with the letter L or P or coloured Brown or Red.

If in doubt, consult the instructions provided with the equipment

or contact the supplier.

This cable/appliance should be protected by a suitably rated and

approved HBC mains fuse: refer to the rating information on the

equipment and/or user instructions for details. As a guide, a cable

of 0.75mm2should be protected by a 3A or 5A fuse. Larger

conductors would normally require 13A types, depending on the

connection method used.

Any exposed wiring from a cable, plug or connection that is

engaged in a live socket is extremely hazardous. If a cable or plug is

deemed hazardous, turn off the mains power and remove the cable,

any fuses and fuse assemblies. All hazardous wiring must be

immediately destroyed and replaced in accordance to the above

standard.

PFR-100 Programming Manual

GETTING STARTED

This chapter describes the power supply in a

nutshell, including its main features and front /

rear panel introduction. After going through the

overview, please read the theory of operation to

become familiar with the operating modes,

protection modes and other safety considerations.

PFR-100 Series Overview ...........................................9

Series lineup ..................................................................................... 9

Main Features .................................................................................. 9

Accessories.....................................................................................10

Appearance..............................................................12

Front Panel..................................................................................... 12

Display Area................................................................................... 15

Rear Panel.......................................................................................17

Configuration Settings .............................................19

Setting Normal Function Settings............................................... 19

Setting Power On Configuration Settings..................................21

Configuration Table......................................................................22

GETTING STARTED

PFR-100 Series Overview

Series lineup

The PFR-100 series consists of 2 models, covering a number of

different current, voltage and power capacities:

Model name

Operation Voltage

Operation Current

Rated Power

PFR-100L

0-50V

0-10A

100W

PFR-100M

0-250V

0-2A

100W

Main Features

Performance

Variable voltage and current combinations with

5 times.

Natural convection cooling.

Supporting universal input voltage.

Features

Preset memory function.

Output ON/OFF delay function.

CV, CC priority start function. (prevents

overshoot with output ON)

Adjustable voltage and current slew rates.

Bleeder circuit ON/OFF setting. (to prevent

over-discharging of batteries)

OVP, OCP, AC FAIL and OTP protection.

Supports test scripts.

Web server monitoring and control.

Analog monitor output.

Remote sensing function.

PFR-100 Programming Manual

Interface

Built-in USB and RS-232/485 interface.

External analog control function.

Optional LAN and GPIB interface.

Accessories

Before using the PFR-100 power supply unit, check the package

contents to make sure all the standard accessories are included.

Standard

Accessories

Part number

Description

Qty.

CD-ROM

User manual, Programming manual

Power Cord

GTL-134

Test leads for rear panel, 1.2m, 10A,

16AWG

PFR-001

Binding Posts Terminal Accessory Kit

(Output terminal cover × 1, Output

terminal × 1, Socket × 1, Protection

Cover × 2, Short Bar × 1)

GTL-104A

Test leads for PFR-100L (Binding

Posts Terminal), 1m, 10A

PFR-002

European Type Jack Terminal

Accessory Kit (Output terminal cover

× 1, Output terminal × 1, Socket × 1,

Protection Cover × 2, Short Wire × 1)

GTL-105A

Test leads for PFR-100M, 1m, 3A

GTL-204A

Test leads for PFR-100L (European

Type Jack Terminal), 1m, 10A

Optional

Accessories

Part number

Description

GRA-431-J-100

Rack mount adapter (JIS) with AC 100V

GRA-431-J-200

Rack mount adapter (JIS) with AC 200V

GRA-431-E-100

Rack mount adapter (EIA) with AC 100V

GRA-431-E-200

Rack mount adapter (EIA) with AC 200V

Other manuals for PFR-100 Series

This manual suits for next models

Table of contents

Other GW Instek Power Supply manuals

GW Instek

GW Instek GPP-3323 User manual

GW Instek

GW Instek PEL-3000A Series User manual

GW Instek

GW Instek PSW 30-72 Owner's manual

GW Instek

GW Instek PSS-3203 User manual

GW Instek

GW Instek GPP-1326 User manual

GW Instek

GW Instek PEL-3021 User manual

GW Instek

GW Instek PSB-2000 series User manual

GW Instek

GW Instek SPD-3606 User manual

GW Instek

GW Instek SPD-3606 User manual

GW Instek

GW Instek PFR-100MGP User manual

GW Instek

GW Instek ASD Series User manual

GW Instek

GW Instek PPX Series User manual

GW Instek

GW Instek PHX 60-100 User manual

GW Instek

GW Instek PSP-603 User manual

GW Instek

GW Instek GPE-1326 Series User manual

GW Instek

GW Instek PSH-1070AGP User manual

GW Instek

GW Instek PSH series User manual

GW Instek

GW Instek PEL-500 Series User manual

GW Instek

GW Instek PSU 60-25 User manual

GW Instek

GW Instek PEL-300 User manual

GW Instek

GW Instek SPS-1230 User manual

GW Instek

GW Instek GPE-1326 Series User manual

GW Instek

GW Instek PSW Series User manual

GW Instek

GW Instek PSM-2010 User manual

Popular Power Supply manuals by other brands

Monacor

Monacor PS-12CCD instruction manual

VOLTIMA

VOLTIMA MagicBox 15 Installation and operating instructions

Agilent Technologies

Agilent Technologies 6032A Service manual

Miller

Miller Auto Deltaweld 452 owner's manual

BCP

BCP PUOUBK How to install

HC 2210 manual

Puls

Puls CT5.241 installation manual

OCZ

OCZ ZX1250W Technical specifications

iseg

iseg ECH 238 manual

Power

Power XXL A Series instruction manual

Agilent Technologies

Agilent Technologies 6631B Service manual

Renogy

Renogy PHOENIX 300 user guide

HP 6200B Operating and service manual

Epson

Epson Stylus Scan 2500 Product information sheet

Pulsar

Pulsar GREEN POWER CCTV PoE POE044816 manual

Puls

Puls MiniLine ML50.100 instruction manual

Puls

Puls AS-Interface SLA4.100 installation manual

Kenwood

Kenwood PS-60 instruction manual
