Grundig GD-CI-AT3637V User manual

Quick Guide

About this guide

The guide includes instructions for using and managing the product.

Pictures, charts, images and all other information hereinafter are for

description and explanation only. The information contained in the

guide is subject to change, without notice, due to firmware updates

or other reasons.

Please find the latest version at WWW.GRUNDIG-SECURITY.COM

Legal Disclaimer

REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF

PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. OUR COMPANY

SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION,

PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER

ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET

SECURITY RISKS; HOWEVER, OUR COMPANY WILL PROVIDE TIMELY

TECHNICAL SUPPORT IF REQUIRED.

SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL

RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS

PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE

APPLICABLE LAW. OUR COMPANY SHALL NOT BE LIABLE IN THE

EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.

IN THE EVENT OF ANY CONFLICTS BETWEEN THIS GUIDE AND THE

APPLICABLE LAW, THE LATER PREVAILS.

QG-GD-CI-AT3637V-2018-01-06-V1-EN ©ABETECHS GMBH, DÜSSELDORF, GERMANY

Regulatory Information

FCC Information

Please take attention that changes or modification not expressly

approved by the party responsible for compliance could void the

user’s authority to operate the equipment.

FCC compliance: This equipment has been tested and found to

comply with the limits for a Class B digital device, pursuant to part 15

of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following measures:

—Reorient or relocate the receiving antenna.

—Increase the separation between the equipment and receiver.

—Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

—Consult the dealer or an experienced radio/TV technician for help.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is

subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including

interference that may cause undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied

accessories too are marked with "CE" and comply

therefore with the applicable harmonized European

standards listed under the EMC Directive 2014/30/EU, the RoHS

Directive 2011/65/EU.

2012/19/EU (WEEE directive): Products marked with

this symbol cannot be disposed of as unsorted

municipal waste in the European Union. For proper

recycling, return this product to your local supplier

upon the purchase of equivalent new equipment, or dispose of it at

designated collection points. For more information see:

www.recyclethis.info

2006/66/EC (battery directive): This product contains

a battery that cannot be disposed of as unsorted

municipal waste in the European Union. See the

product documentation for specific battery

information. The battery is marked with this symbol,

which may include lettering to indicate cadmium (Cd), lead (Pb), or

mercury (Hg). For proper recycling, return the battery to your supplier

or to a designated collection point. For more information see:

www.recyclethis.info

Industry Canada ICES-003 Compliance

This device meets the CAN ICES-3 (B)/NMB-3(B) standards

requirements.

Safety Instruction

These instructions are intended to ensure that user can use the

product correctly to avoid danger or property loss.

The precaution measure is divided into “Warnings” and “Cautions”

Warnings: Serious injury or death may occur if any of the warnings

are neglected.

Cautions: Injury or equipment damage may occur if any of the

cautions are neglected.

Warnings

●Proper configuration of all passwords and other security settings

is the responsibility of the installer and/or end-user.

●In the use of the product, you must be in strict compliance with

the electrical safety regulations of the nation and region. Please

refer to technical specifications for detailed information.

Warnings Follow these

safeguards to prevent

serious injury or death.

Cautions Follow these precautions

to prevent potential injury or

material damage.

●Input voltage should meet both the SELV (Safety Extra Low

Voltage) and the Limited Power Source with 24 VAC or 12 VDC

according to the IEC60950-1 standard. Please refer to technical

specifications for detailed information.

●Do not connect several devices to one power adapter as adapter

overload may cause over-heating or a fire hazard.

●Please make sure that the plug is firmly connected to the power

socket. When the product is mounted on wall or ceiling, the

device shall be firmly fixed.

●If smoke, odor or noise rise from the device, turn off the power

at once and unplug the power cable, and then please contact

the service center.

Cautions

●Make sure the power supply voltage is correct before using the

camera.

●Do not drop the camera or subject it to physical shock.

●Do not touch sensor modules with fingers. If cleaning is

necessary, use clean cloth with a bit of ethanol and wipe it

gently. If the camera will not be used for an extended period,

please replace the lens cap to protect the sensor from dirt.

●Do not aim the camera at the sun or extra bright places.

Blooming or smearing may occur otherwise (which is not a

malfunction), and affect the endurance of sensor at the same

time.

●The sensor may be burned out by a laser beam, so when any

laser equipment is in using, make sure that the surface of sensor

will not be exposed to the laser beam.

●Do not place the camera in extremely hot, cold (the operating

temperature shall be-30°C ~+60°C, or -40°C ~ +60°C if the

camera model has an “H” in its suffix), dusty or damp locations,

and do not expose it to high electromagnetic radiation.

●To avoid heat accumulation, good ventilation is required for

operating environment.

●Keep the camera away from liquid while in use.

●While in delivery, the camera shall be packed in its original

packing, or packing of the same texture.

●Regular part replacement: a few parts (e.g. electrolytic

capacitor) of the equipment shall be replaced regularly

according to their average enduring time. The average time

varies because of differences between operating environment

and using history, so regular checking is recommended for all the

users. Please contact with your dealer for more details.

●Improper use or replacement of the battery may result in hazard

of explosion. Replace with the same or equivalent type only.

Dispose of used batteries according to the instructions provided

by the battery manufacturer.

●If the product does not work properly, please contact your

dealer or the nearest service center. Never attempt to

disassemble the camera yourself. (We shall not assume any

responsibility for problems caused by unauthorized repair or

maintenance.)

Table of Contents

1 Appearance Description ................................................................. 8

1.1 Components.................................................................... 9

1.2 Cables ........................................................................... 11

2 Installation.................................................................................... 13

2.1 Preparation ................................................................... 14

2.1.1 Disassembling..................................................... 14

2.1.2 Memory Card Installation................................... 15

2.2 Mounting ...................................................................... 16

2.2.1 Ceiling Mounting ................................................ 16

2.2.2 Wall Mounting.................................................... 20

2.2.3 Pendant Mouting ............................................... 23

2.3 Installation of Network Cable Water-proof Jacket

(Optional) ................................................................................. 26

2.4 Installation of Water-proof Tape (Optional)................... 28

3 Setting the Network Camera over the LAN .................................. 32

3.1 Wiring ........................................................................... 32

3.2 Activating the Camera................................................... 33

3.2.1 Activation via Web Browser................................ 33

3.2.2 Activation via SADP Software ............................. 34

3.3 Modifying the IP Address .............................................. 36

4 Accessing via Web Browser .......................................................... 38

Network Dome Camera·Quick Start Guide

1Appearance Description

The overview of the dome camera is shown below:

Overview

Network Dome Camera·Quick Start Guide

1.1 Components

Camera Components (1)

Table of contents
