Gisteq AS-10 User manual
GPS-GSM Auto Security Solution
Cellular/GPS Vehicle Control and Tracking System
GuardianTM AS-10
NO
Service Plans
Required
SMS
Security SMS Alert Geo-FencingReal Time TrackingRemote Keyless Entry
Key Feature Highlights
s6IEW2EAL4IME,OCATIONIN'OOGLE-APONYOUR
-OBILE0HONES
s3ECURITY3YSTEM3-3!LERTS"ATTERY$ISCONNECTION
,OW"ATTERY5NAUTHORIZEDMOVEMENT
#AR!LARM
s'EO&ENCING
s2EMOTELY,OCK5NLOCK$OORSWITH-OBILE0HONES
s)NTERNAL"ACKUP"ATTERY
s(IGH3ENSITIVITY'032ECEIVER"UILTIN
s.O-ONTHLY3UBSCRIPTION&EES
s%ASYTO)NSTALL/PERATE
GiSTEQTM
1. Read Instruction Manual 2. Hard-wire to Vehicle 3. Install Mobile Application 4. Start Tracking
Easy Installation
Usage Requirements:
• Mobile Phones - Blackberry, Java,Windows Mobile,Symbian
• GPRS data plan is required for mobile devices.
• GSM SIM Card for Guardian (GPRS Data Plan Optional)
• SIM cards from the same service providers are recommended
to avoid incompatibility issues.
• Qualified car mechanics are highly recommended for
Guardian installation.
Package Includes
• Guardian AS-10
• User’s Manual
• Software CD
• External Antenna
• USB Cable
• Car Kits
© 2007 GiSTEQ Corp. All rights reserved. All specifications are subject to
change without prior notice. All other trademarks, product and company
names are the property of their respective owners.
GiSTEQTM
GiSTEQ Corp.
911 Mariner Street, Brea, CA 92821
www.gisteq.com
Hardware Specification
• Dimension: 60(W) x 27(H) x 77(D)
• Weight: 100g
• GPS Features:
-Built-in 32 channels high sensitivity GPS receiver;
-Chipset: MTK; Sensitivity: -159dBm;
-Cold Start/Warm Start/Hot Start: 36/33/1 Seconds
• GSM: Supports 850/900/1800/1900 MHz frequency, communication type:SMS, GPRS UDP/TCP
• Power Source: DC 8-35V; Back-up Battery: 950mA,3.7V
• Power Consumption:
< 80mA @ DC 12V (GPS on, GSM on)
< 40mA @ DC 12V in standby mode (GPS off, GSM in listening mode)
< 1 mA @ DC 12V (GPS off,GSM off, vibration / IO sensors on)
• Serial port: 1 mini-USB, for data exchanging or back-up battery charging
• Input port: 4 digital input ports, with 2 positive triggering, 2 negative triggering
• Output port: 4 digital output ports, with 4 negative triggering
• External SMA Connectors: L type GSM and GPS Active Antenna
• Memory: built-in 4MB flash memory
* Check our website for complete compatibility information.
Mobile Phone Requirement
• Windows Mobile Based Phone
• BlackBerry Phone
• Java (J2ME) Based Phone
• symbian OS Based Phone
• GPRS Data Plan Requires
Minimum PC Requirement
• Windows XP or Vista
• Intel Pentium P III 500 Mhz
• 256 MB RAM
• 30 MB hard-disk space
• USB 1.1 Port
The Guardian AS-10 is an easy-to-use and economical GPS-GSM vehicle security
system.The AS-10 is mainly designed for vehicle security and it is a system needs
to be hard-wired to your car. It has NO monthly subscription fees.You can use
Guardian real time tracking solution pay-as-you-go. Utilizing the GSM network,
Guardian AS-10 lets you monitor your vehicle as well as unlocking the car door
wherever you are. It comes with extensive mobile applications that help you to
manage your vehicle remotely.You will receive alerts if your vehicle has any
status changes such as unauthorized movement or car alarm is triggered, etc.
You will be able to view vehicle location on Google maps with your mobile
phones as well as geo-fencing, changing settings, etc.The Guardian AS-10 is the
simple vehicle tracking solution that everyone can use and afford.
