Clifford 3606X User manual
OWNER’S GUIDE MODEL
3606X
©2013 Directed, All rights reserved.
The company behind Clifford®Auto Security
Systems is Directed.
Since its inception, Directed has had one purpose, to
provide consumers with the finest vehicle security and
accessories available. The recipient of nearly 100 pat-
ents and Innovations Awards in the field of advanced
electronic technology.
Quality Directed products are sold and serviced
throughout North America and around the world.
Call (800) 876-0800 for more information about our
products and services.
Directed is committed to delivering world class
quality products and services that excite and
delight our customers.
THE SCIENCE OF SECURITY™
QRG3606X 2013 07
Vista, CA 92081
www.clifford.com
Congratulations
Congratulations on the purchase of your state-of-the-art security system.
Reading this Owner’s Guide prior to using your system will help maxi-
mize the use of your system and its many features. For any additional
questions please contact your authorized Directed dealer or contact
Directed at 1-800-753-0600.
Additional Guide Information
Only basic commands, features and essential information are covered
in this compact guide. Your product has many advanced features
which are not discussed here, please consult the expanded online ver-
sion for these on the website listed on the back cover. Most sections in
this guide also contain additional information which can be found in
the expanded online version.
Important information
Government Regulations and Safety information
Read the Government Regulations and Warning! Safety
First sections of this manual prior to operating this system.
Warning! Failure to heed this information can result in
death, personal injury or property damage and may also
result in the illegal use of the system beyond its intended
purpose.
Optional Remote Controls
A choice of two optional remote controls with additional features is
also available for use with your system. These remote control choices
are: LED 2-way (P/N 7856) and LCD 2-way (P/N 7756). See your
authorized dealer for purchasing details. Once purchased, please
go online to our website (listed on the back cover) and use system
model number 3806 or 3706 respectively to search for the appropri-
ate owner’s guide, which provides instructions on how to use these
remote controls.
Replacement Remote Controls
Please see your authorized dealer or visit us at www.directedstore.
com to order additional remote controls , or the optional LED and LCD
remote controls. Remote control part numbers are found on the back
of the device.
Your Warranty
Your system comes with a warranty. The warranty terms are detailed at
the end of this guide. Make sure that you receive the proof of purchase
from your dealer, indicating the product was installed by an autho-
rized Directed dealer.
Contents
Remote Control ................................................................................................... 3
Control Center .................................................................................................... 3
Using your System............................................................................................... 4
Commanding the system....................................................................... 4
Performing Commands ......................................................................... 4
Remote Control Command table ............................................................ 5
Basic Commands (Direct Access) .......................................................................... 6
Arm ................................................................................................... 6
Disarm ............................................................................................... 6
Remote Start/Aux 1/Aux 4................................................................... 7
AUX/Trunk.......................................................................................... 7
Battery Information.............................................................................................. 8
Battery Disposal .................................................................................. 8
Patent Information ............................................................................................... 8
Government Regulations ...................................................................................... 9
Warning! Safety First......................................................................................... 11
Installation ........................................................................................ 11
Interference....................................................................................... 11
Upgrades ......................................................................................... 11
Water/Heat Resistance ...................................................................... 11
Limited lifetime consumer warranty ..................................................................... 12
3
© 2013 Directed. All rights reserved.
Remote Control
Feature Description
Internal Antenna Used for transmitting information
Transmit LED Active when transmitting information
Command buttons (4)
A U X
A U X
A U X
A U X
Used to perform arming, disarming, and auxiliary channel
commands
Function button
A U X
Used to access function levels for commands, configuration
menus for programming and Car Selection
Control Center
Control CenterLED Button
The Control Center, typically located on the upper part of the front
windshield. It consists of:
• The In-vehicle system antenna.
• The Status LED, as a visual indicator of the system’s status.
• The Control button, for placing the system into Valet Mode* and
to perform the Emergency Override* operation.
* See online guide for details.
4© 2013 Directed. All rights reserved.
Using your System
Commanding the system
Commands, Basic or Advanced, are used to activate system features
and are performed by pressing one of the Command buttons. Basic
commands control the most often used security and remote start fea-
tures while Advanced commands control more specialized features.
Confirmations for Basic or Advanced commands are indicated
by siren chirps and parking light flashes. A description of each feature
confirmation is found in the following Basic command and Advanced
command sections.
Performing Commands
Perform Basic commands by pressing a Command button.
Perform Advanced Commands by first accessing Levels 1-4 using the
AUX
button and then by pressing a Command button while within a
level.
Advanced command example: Silent Arm
1. Press the
AUX
button once to access Function Level 1, The trans-
mit LED single flashes for 3 seconds.
2. Press the
AUX
AUX
button while the transmit LED is still flashing to
perform the Silent Arm command.
3. The system will arm, lock the doors and flash the parking lights
without siren chirps.
5
© 2013 Directed. All rights reserved.
Remote Control Command table
Button
Level Direct Access
A U X
x 1
LEVEL 1
A U X
x 2
LEVEL 2
A U X
x 3
LEVEL 3
A U X
x 4
LEVEL 4
A U X
Arm/Lock
(Panic)
Silent Arm Sensor
Bypass
Sensor Silent
Arm
Full Silent
Arm
A U X
Disarm/Unlock Silent Disarm Remote Valet Car Finder
A U X
Remote Start*/
Aux 1/4**
AUX Aux/Trunk AUX 1 AUX 2 AUX 3 AUX 4
A U X
Advance Level,
Enter program-
ming (8 sec)
* Available only with optional Remote Start module installation
** This button can command either Aux 1 or Aux 4 if turned on by
an authorized Directed dealer.
6© 2013 Directed. All rights reserved.
Basic Commands (Direct Access)
Arm
Press and release
AUX
AUX
The alarm arms, doors lock (if connected), and the siren chirps and
parking lights flash once. If Valet mode* is On, the doors lock without
siren chirps, the alarm is disabled. Exit Valet mode to arm the alarm
normally.
If a trigger zone fault is detected the siren chirps once again and the
control center LED generates a Trigger Zone Fault report*.
To Arm and Panic
Press and hold
AUX
AUX
The alarm Arms (or Locks in Valet) and, after two seconds, sounds
the siren and flashes the parking lights. Press the
AUX
AUX
or
AUX
AUX
button
to stop the output.
Disarm
Press and release
AUX
AUX
The alarm disarms, doors unlock (if connected), and the siren chirps
and parking lights flash twice.
An Alarm Report* alert of four or five siren chirps will replace the
normal disarm chirps if the alarm was triggered.
7
© 2013 Directed. All rights reserved.
Remote Start/Aux 1/Aux 4
Press and release
AUX
AUX
Remote Start **
Activates (or if On, deactivates) the remote starter. The engine
and parking lights turn On, or the engine and parking lights turn
Off accordingly.
AUX1/AUX4 ***
Activates (or if on, deactivates) the aux 1or aux 4 output.
AUX/Trunk
Press and hold
AUX
The Trunk opens (if connected) when this button is pressed for 2 sec-
onds.
* See online guide for details.
** Available only with optional Remote Start module installation.
*** This feature must be turned on by an authorized Directed dealer.
